吃透OSI七层模型：从底层逻辑到实战落地，一文打通网络通信任督二脉

<dependency>
    <groupId>net.java.dev.jna</groupId>
    <artifactId>jna</artifactId>
    <version>5.14.0</version>
</dependency>
<dependency>
    <groupId>net.java.dev.jna</groupId>
    <artifactId>jna-platform</artifactId>
    <version>5.14.0</version>
</dependency>

import com.sun.jna.Library;
import com.sun.jna.Native;
import com.sun.jna.Structure;
import com.sun.jna.platform.win32.WinDef;
import com.sun.jna.win32.W32APIOptions;

import java.util.Arrays;
import java.util.List;

/**
 * 物理层实战：判断Windows网卡物理连接状态
 */
publicclass PhysicalLayerStatusChecker {
    // 定义Windows系统的IP Helper库接口
    publicinterface IpHlpApi extends Library {
        IpHlpApi INSTANCE = Native.load("iphlpapi", IpHlpApi.class, W32APIOptions.DEFAULT_OPTIONS);

        // 网卡状态结构体
        class MIB_IFROW extends Structure {
            public WinDef.DWORD dwIndex;
            publicbyte[] bDescr = newbyte[256];
            publicbyte[] bPhysAddr = newbyte[8];
            public WinDef.DWORD dwPhysAddrLen;
            public WinDef.DWORD dwType;
            public WinDef.DWORD dwMtu;
            public WinDef.DWORD dwSpeed;
            public WinDef.DWORD dwFlags;
            public WinDef.DWORD dwOperStatus; // 操作状态：1=Up，2=Down，3=Testing...

            @Override
            protected List<String> getFieldOrder() {
                return Arrays.asList("dwIndex", "bDescr", "bPhysAddr", "dwPhysAddrLen", "dwType", "dwMtu", "dwSpeed", "dwFlags", "dwOperStatus");
            }
        }

        // 获取指定索引的网卡信息
        int GetIfEntry(MIB_IFROW pIfRow);
    }

    public static void main(String[] args) {
        // 遍历网卡索引（1~100，实际可根据系统调整范围）
        for (int index = 1; index <= 100; index++) {
            IpHlpApi.MIB_IFROW ifRow = new IpHlpApi.MIB_IFROW();
            ifRow.dwIndex = new WinDef.DWORD(index);
            int result = IpHlpApi.INSTANCE.GetIfEntry(ifRow);

            if (result == 0) { // 成功获取网卡信息
                String descr = new String(ifRow.bDescr).trim(); // 网卡描述（如"以太网"）
                String physAddr = bytesToMac(ifRow.bPhysAddr, ifRow.dwPhysAddrLen.intValue()); // MAC地址
                int operStatus = ifRow.dwOperStatus.intValue(); // 操作状态
                String statusDesc = getStatusDesc(operStatus);

                // 过滤掉虚拟网卡（如VPN、虚拟机网卡），只关注物理网卡
                if (!descr.contains("Virtual") && !descr.contains("VPN") && !descr.contains("VMware")) {
                    System.out.printf("网卡描述：%s%n", descr);
                    System.out.printf("MAC地址：%s%n", physAddr);
                    System.out.printf("物理连接状态：%s（%d）%n", statusDesc, operStatus);
                    System.out.println("----------------------------------------");
                }
            }
        }
    }

    // 将字节数组转换为MAC地址字符串（如00:1A:2B:3C:4D:5E）
    private static String bytesToMac(byte[] bytes, int len) {
        if (len <= 0 || len > bytes.length) {
            return"";
        }
        StringBuilder sb = new StringBuilder();
        for (int i = 0; i < len; i++) {
            sb.append(String.format("%02X", bytes[i]));
            if (i < len - 1) {
                sb.append(":");
            }
        }
        return sb.toString();
    }

    // 解析操作状态描述
    private static String getStatusDesc(int status) {
        switch (status) {
            case1:
                return"已连接（Up）- 物理链路正常";
            case2:
                return"已断开（Down）- 物理链路中断（如未插网线）";
            case3:
                return"测试中（Testing）";
            case4:
                return"未知（Unknown）";
            case5:
                return"休眠（Dormant）";
            case6:
                return"未就绪（NotPresent）";
            case7:
                return"低功率（LowerLayerDown）";
            default:
                return"未定义状态";
        }
    }
}

import java.nio.ByteBuffer;
import java.nio.charset.StandardCharsets;

/**
 * 数据链路层实战：以太网帧的封装与解析
 */
publicclass EthernetFrameDemo {
    // 以太网帧字段长度常量（单位：字节）
    privatestaticfinalint PREAMBLE_LENGTH = 7;
    privatestaticfinalint SFD_LENGTH = 1;
    privatestaticfinalint MAC_ADDRESS_LENGTH = 6;
    privatestaticfinalint TYPE_LENGTH = 2;
    privatestaticfinalint FCS_LENGTH = 4;
    privatestaticfinalint MIN_DATA_LENGTH = 46;
    privatestaticfinalint MAX_DATA_LENGTH = 1500;

    // 协议类型常量
    publicstaticfinalshort PROTOCOL_IP = 0x0800;   // IP协议
    publicstaticfinalshort PROTOCOL_ARP = 0x0806;  // ARP协议

    /**
     * 封装以太网帧
     * @param srcMac 源MAC地址（如"00:1A:2B:3C:4D:5E"）
     * @param destMac 目的MAC地址（如"FF:FF:FF:FF:FF:FF"）
     * @param protocolType 上层协议类型（PROTOCOL_IP/PROTOCOL_ARP）
     * @param data 网络层数据（数据包）
     * @return 完整的以太网帧字节数组
     */
    publicstaticbyte[] encapsulateEthernetFrame(String srcMac, String destMac, short protocolType, byte[] data) {
        // 1. 验证数据长度（不足46字节填充，超过1500字节报错）
        byte[] dataFilled = newbyte[Math.max(data.length, MIN_DATA_LENGTH)];
        System.arraycopy(data, 0, dataFilled, 0, data.length);
        if (data.length > MAX_DATA_LENGTH) {
            thrownew IllegalArgumentException("数据长度超过MTU（1500字节）");
        }

        // 2. 计算帧总长度
        int frameTotalLength = PREAMBLE_LENGTH + SFD_LENGTH + MAC_ADDRESS_LENGTH * 2 + TYPE_LENGTH + dataFilled.length + FCS_LENGTH;
        ByteBuffer frameBuffer = ByteBuffer.allocate(frameTotalLength);

        // 3. 写入前导码（0x55重复7次，即10101010交替）
        for (int i = 0; i < PREAMBLE_LENGTH; i++) {
            frameBuffer.put((byte) 0x55);
        }

        // 4. 写入帧起始定界符（0xD5，即10101011）
        frameBuffer.put((byte) 0xD5);

        // 5. 写入目的MAC地址
        frameBuffer.put(macStringToBytes(destMac));

        // 6. 写入源MAC地址
        frameBuffer.put(macStringToBytes(srcMac));

        // 7. 写入协议类型（大端序，网络字节序）
        frameBuffer.putShort(protocolType);

        // 8. 写入数据（填充后的数据）
        frameBuffer.put(dataFilled);

        // 9. 计算并写入FCS（CRC-32校验码）
        byte[] frameWithoutFcs = newbyte[frameBuffer.position()];
        frameBuffer.rewind();
        frameBuffer.get(frameWithoutFcs);
        int crc = calculateCRC32(frameWithoutFcs);
        frameBuffer.putInt(crc);

        return frameBuffer.array();
    }

    /**
     * 解封装以太网帧
     * @param frame 完整的以太网帧字节数组
     * @return 解封装后的结果（包含源MAC、目的MAC、协议类型、数据）
     */
    public static EthernetFrameDecapsulateResult decapsulateEthernetFrame(byte[] frame) {
        ByteBuffer frameBuffer = ByteBuffer.wrap(frame);

        // 1. 跳过前导码和SFD
        frameBuffer.position(PREAMBLE_LENGTH + SFD_LENGTH);

        // 2. 读取目的MAC地址
        byte[] destMacBytes = newbyte[MAC_ADDRESS_LENGTH];
        frameBuffer.get(destMacBytes);
        String destMac = macBytesToString(destMacBytes);

        // 3. 读取源MAC地址
        byte[] srcMacBytes = newbyte[MAC_ADDRESS_LENGTH];
        frameBuffer.get(srcMacBytes);
        String srcMac = macBytesToString(srcMacBytes);

        // 4. 读取协议类型（大端序）
        short protocolType = frameBuffer.getShort();

        // 5. 读取数据（排除FCS）
        int dataLength = frame.length - (PREAMBLE_LENGTH + SFD_LENGTH + MAC_ADDRESS_LENGTH * 2 + TYPE_LENGTH + FCS_LENGTH);
        byte[] data = newbyte[dataLength];
        frameBuffer.get(data);

        // 6. 读取并验证FCS
        int fcs = frameBuffer.getInt();
        byte[] frameWithoutFcs = newbyte[frame.length - FCS_LENGTH];
        System.arraycopy(frame, 0, frameWithoutFcs, 0, frameWithoutFcs.length);
        int calculatedCrc = calculateCRC32(frameWithoutFcs);
        boolean isFrameValid = (calculatedCrc == fcs);

        returnnew EthernetFrameDecapsulateResult(srcMac, destMac, protocolType, data, isFrameValid);
    }

    /**
     * MAC地址字符串转字节数组（如"00:1A:2B:3C:4D:5E" -> 字节数组）
     */
    privatestaticbyte[] macStringToBytes(String mac) {
        String[] macParts = mac.split(":");
        if (macParts.length != 6) {
            thrownew IllegalArgumentException("无效的MAC地址格式");
        }
        byte[] macBytes = newbyte[6];
        for (int i = 0; i < 6; i++) {
            macBytes[i] = (byte) Integer.parseInt(macParts[i], 16);
        }
        return macBytes;
    }

    /**
     * MAC地址字节数组转字符串（如字节数组 -> "00:1A:2B:3C:4D:5E"）
     */
    private static String macBytesToString(byte[] macBytes) {
        if (macBytes.length != 6) {
            thrownew IllegalArgumentException("无效的MAC地址字节数组长度");
        }
        StringBuilder sb = new StringBuilder();
        for (int i = 0; i < 6; i++) {
            sb.append(String.format("%02X", macBytes[i]));
            if (i < 5) {
                sb.append(":");
            }
        }
        return sb.toString();
    }

    /**
     * 计算CRC-32校验码（符合以太网FCS标准）
     */
    private static int calculateCRC32(byte[] data) {
        int crc = 0xFFFFFFFF; // 初始值
        for (byte b : data) {
            crc ^= (b & 0xFF);
            for (int i = 0; i < 8; i++) {
                if ((crc & 0x00000001) != 0) {
                    crc = (crc >> 1) ^ 0xEDB88320; // 多项式
                } else {
                    crc >>= 1;
                }
            }
        }
        return ~crc; // 取反
    }

    /**
     * 解封装结果封装类
     */
    publicstaticclass EthernetFrameDecapsulateResult {
        privatefinal String srcMac;
        privatefinal String destMac;
        privatefinalshort protocolType;
        privatefinalbyte[] data;
        privatefinalboolean isFrameValid;

        public EthernetFrameDecapsulateResult(String srcMac, String destMac, short protocolType, byte[] data, boolean isFrameValid) {
            this.srcMac = srcMac;
            this.destMac = destMac;
            this.protocolType = protocolType;
            this.data = data;
            this.isFrameValid = isFrameValid;
        }

        // getter方法
        public String getSrcMac() { return srcMac; }
        public String getDestMac() { return destMac; }
        public short getProtocolType() { return protocolType; }
        publicbyte[] getData() { return data; }
        public boolean isFrameValid() { return isFrameValid; }
    }

    // 测试方法
    public static void main(String[] args) {
        try {
            // 1. 准备测试数据（模拟网络层IP数据包，这里用字符串模拟）
            String ipDataStr = "This is a test IP packet data.";
            byte[] ipData = ipDataStr.getBytes(StandardCharsets.UTF_8);

            // 2. 封装以太网帧
            String srcMac = "00:1A:2B:3C:4D:5E";
            String destMac = "FF:FF:FF:FF:FF:FF"; // 广播地址
            byte[] ethernetFrame = encapsulateEthernetFrame(srcMac, destMac, PROTOCOL_IP, ipData);
            System.out.println("以太网帧封装完成，帧总长度：" + ethernetFrame.length + "字节");

            // 3. 解封装以太网帧
            EthernetFrameDecapsulateResult result = decapsulateEthernetFrame(ethernetFrame);
            System.out.println("\n以太网帧解封装结果：");
            System.out.println("源MAC地址：" + result.getSrcMac());
            System.out.println("目的MAC地址：" + result.getDestMac());
            System.out.println("上层协议类型：" + (result.getProtocolType() == PROTOCOL_IP ? "IP协议（0x0800）" : "其他协议"));
            System.out.println("帧有效性：" + (result.isFrameValid() ? "有效（CRC校验通过）" : "无效（CRC校验失败）"));
            System.out.println("解封装后的数据（网络层数据包）：" + new String(result.getData(), StandardCharsets.UTF_8).trim());

            // 4. 测试CRC校验失败场景（修改帧数据）
            ethernetFrame[10] = (byte) 0xAA; // 篡改目的MAC地址的一个字节
            EthernetFrameDecapsulateResult invalidResult = decapsulateEthernetFrame(ethernetFrame);
            System.out.println("\n篡改帧数据后的解封装结果：");
            System.out.println("帧有效性：" + (invalidResult.isFrameValid() ? "有效" : "无效（CRC校验失败）"));
        } catch (Exception e) {
            e.printStackTrace();
        }
    }
}

<dependency>
    <groupId>org.pcap4j</groupId>
    <artifactId>pcap4j-core</artifactId>
    <version>1.8.2</version>
</dependency>
<dependency>
    <groupId>org.pcap4j</groupId>
    <artifactId>pcap4j-packet</artifactId>
    <version>1.8.2</version>
</dependency>
<dependency>
    <groupId>org.pcap4j</groupId>
    <artifactId>pcap4j-nio</artifactId>
    <version>1.8.2</version>
</dependency>

import org.pcap4j.core.*;
import org.pcap4j.packet.ArpPacket;
import org.pcap4j.packet.EthernetPacket;
import org.pcap4j.packet.Packet;
import org.pcap4j.packet.namednumber.ArpHardwareType;
import org.pcap4j.packet.namednumber.ArpOperation;
import org.pcap4j.packet.namednumber.EtherType;
import org.pcap4j.util.ByteArrays;
import org.pcap4j.util.MacAddress;

import java.net.Inet4Address;
import java.net.InetAddress;
import java.net.UnknownHostException;
import java.util.concurrent.TimeoutException;

/**
 * 数据链路层实战：ARP协议实现（IP地址解析为MAC地址）
 */
publicclass ArpProtocolDemo {
    // 超时时间（单位：毫秒）
    privatestaticfinalint TIMEOUT = 5000;
    // 发送ARP请求的次数
    privatestaticfinalint SEND_COUNT = 3;

    /**
     * 发送ARP请求，解析目标IP对应的MAC地址
     * @param ifName 网卡名称（如Windows的"以太网"，Linux的"eth0"）
     * @param srcIp 本地IP地址
     * @param srcMac 本地MAC地址
     * @param targetIp 目标IP地址（需要解析的IP）
     * @return 目标IP对应的MAC地址，若解析失败返回null
     * @throws PcapNativeException
     * @throws NotOpenException
     * @throws InterruptedException
     * @throws TimeoutException
     */
    public static MacAddress sendArpRequest(String ifName, Inet4Address srcIp, MacAddress srcMac, Inet4Address targetIp)
            throws PcapNativeException, NotOpenException, InterruptedException, TimeoutException {
        // 1. 获取网卡设备
        PcapNetworkInterface nif = Pcaps.getDevByName(ifName);
        if (nif == null) {
            thrownew IllegalArgumentException("未找到网卡：" + ifName);
        }

        // 2. 打开网卡，设置快照长度（抓取帧的最大长度）和超时时间
        int snapLen = 65536;
        PcapHandle handle = nif.openLive(snapLen, PcapNetworkInterface.PromiscuousMode.PROMISCUOUS, TIMEOUT);

        try {
            // 3. 构建ARP请求包
            // 3.1 构建ARP头部
            ArpPacket.ArpHeader arpHeader = new ArpPacket.ArpHeader.Builder()
                    .hardwareType(ArpHardwareType.ETHERNET) // 硬件类型：以太网
                    .protocolType(EtherType.IPV4) // 协议类型：IPV4
                    .hardwareAddrLength((byte) MacAddress.SIZE_IN_BYTES) // MAC地址长度：6字节
                    .protocolAddrLength((byte) ByteArrays.INET4_ADDRESS_SIZE_IN_BYTES) // IP地址长度：4字节
                    .operation(ArpOperation.REQUEST) // 操作类型：请求
                    .senderHardwareAddr(srcMac) // 发送方MAC地址
                    .senderProtocolAddr(srcIp) // 发送方IP地址
                    .targetHardwareAddr(MacAddress.ETHER_BROADCAST_ADDRESS) // 目标MAC地址（广播）
                    .targetProtocolAddr(targetIp) // 目标IP地址
                    .build();

            // 3.2 构建以太网帧头部（目的MAC为广播地址）
            EthernetPacket.EthernetHeader etherHeader = new EthernetPacket.EthernetHeader.Builder()
                    .dstAddr(MacAddress.ETHER_BROADCAST_ADDRESS) // 广播地址
                    .srcAddr(srcMac) // 发送方MAC地址
                    .type(EtherType.ARP) // 帧类型：ARP
                    .build();

            // 3.3 构建完整的ARP数据包（以太网帧 + ARP包）
            Packet arpPacket = new EthernetPacket.Builder()
                    .header(etherHeader)
                    .payload(new ArpPacket.Builder().header(arpHeader).build())
                    .build();

            // 4. 发送ARP请求
            for (int i = 0; i < SEND_COUNT; i++) {
                handle.sendPacket(arpPacket);
                System.out.printf("第%d次发送ARP请求：目标IP=%s，广播地址=%s%n",
                        i + 1, targetIp.getHostAddress(), MacAddress.ETHER_BROADCAST_ADDRESS);
                Thread.sleep(1000); // 间隔1秒发送一次
            }

            // 5. 捕获ARP响应包
            long startTime = System.currentTimeMillis();
            while (System.currentTimeMillis() - startTime < TIMEOUT) {
                Packet packet = handle.getNextPacketEx(); // 捕获下一个包
                if (packet.contains(ArpPacket.class) && packet.contains(EthernetPacket.class)) {
                    // 解析ARP包
                    ArpPacket receivedArpPacket = packet.get(ArpPacket.class);
                    ArpPacket.ArpHeader receivedArpHeader = receivedArpPacket.getHeader();

                    // 验证是否是目标IP的ARP响应
                    if (receivedArpHeader.getOperation() == ArpOperation.REPLY
                            && receivedArpHeader.getSenderProtocolAddr().equals(targetIp)
                            && receivedArpHeader.getTargetProtocolAddr().equals(srcIp)) {
                        MacAddress targetMac = receivedArpHeader.getSenderHardwareAddr();
                        System.out.printf("ARP解析成功：目标IP=%s 对应的MAC地址=%s%n",
                                targetIp.getHostAddress(), targetMac);
                        return targetMac;
                    }
                }
            }

            // 超时未收到响应
            System.out.println("ARP解析失败：超时未收到目标IP的响应");
            returnnull;
        } finally {
            handle.close(); // 关闭PcapHandle
        }
    }

    // 测试方法
    public static void main(String[] args) {
        try {
            // 1. 配置参数（需根据实际环境修改）
            String ifName = "以太网"; // 网卡名称（Windows系统）
            Inet4Address srcIp = (Inet4Address) InetAddress.getByName("192.168.1.100"); // 本地IP
            MacAddress srcMac = MacAddress.getByName("00:1A:2B:3C:4D:5E"); // 本地MAC
            Inet4Address targetIp = (Inet4Address) InetAddress.getByName("192.168.1.1"); // 目标IP（如路由器IP）

            // 2. 发送ARP请求，解析MAC地址
            MacAddress targetMac = sendArpRequest(ifName, srcIp, srcMac, targetIp);
            if (targetMac != null) {
                System.out.println("最终解析结果：" + targetIp.getHostAddress() + " -> " + targetMac);
            } else {
                System.out.println("解析失败");
            }
        } catch (UnknownHostException e) {
            System.err.println("无效的IP地址：" + e.getMessage());
        } catch (PcapNativeException e) {
            System.err.println("Pcap库调用失败：" + e.getMessage());
        } catch (NotOpenException e) {
            System.err.println("网卡未打开：" + e.getMessage());
        } catch (InterruptedException e) {
            System.err.println("线程中断：" + e.getMessage());
        } catch (TimeoutException e) {
            System.err.println("捕获数据包超时：" + e.getMessage());
        } catch (Exception e) {
            e.printStackTrace();
        }
    }
}

import java.nio.ByteBuffer;
import java.nio.charset.StandardCharsets;
import java.net.Inet4Address;
import java.net.InetAddress;
import java.net.UnknownHostException;

/**
 * 网络层实战：IPv4数据包的封装与解析
 */
publicclass Ipv4PacketDemo {
    // IPv4头部字段长度常量（单位：字节）
    privatestaticfinalint VERSION_IHL_LENGTH = 1;
    privatestaticfinalint TOS_LENGTH = 1;
    privatestaticfinalint TOTAL_LENGTH_LENGTH = 2;
    privatestaticfinalint IDENTIFICATION_LENGTH = 2;
    privatestaticfinalint FLAGS_FRAG_OFFSET_LENGTH = 2;
    privatestaticfinalint TTL_LENGTH = 1;
    privatestaticfinalint PROTOCOL_LENGTH = 1;
    privatestaticfinalint HEADER_CHECKSUM_LENGTH = 2;
    privatestaticfinalint IP_ADDRESS_LENGTH = 4;
    privatestaticfinalint MIN_HEADER_LENGTH = 20; // 无选项字段的最小头部长度
    privatestaticfinalint MAX_HEADER_LENGTH = 60; // 有选项字段的最大头部长度

    // 协议类型常量（对应上层协议）
    publicstaticfinalbyte PROTOCOL_TCP = 6;   // TCP协议
    publicstaticfinalbyte PROTOCOL_UDP = 17;  // UDP协议
    publicstaticfinalbyte PROTOCOL_ICMP = 1;  // ICMP协议

    // 版本常量
    privatestaticfinalbyte VERSION_IPV4 = 4;

    /**
     * 封装IPv4数据包
     * @param srcIp 源IP地址（如"192.168.1.100"）
     * @param destIp 目的IP地址（如"192.168.1.1"）
     * @param protocol 上层协议类型（PROTOCOL_TCP/PROTOCOL_UDP/PROTOCOL_ICMP）
     * @param ttl 生存时间（跳数，如64）
     * @param identification 标识字段（用于分片重组，如12345）
     * @param flags 标志字段（3位，如0x00表示允许分片）
     * @param fragOffset 片偏移（单位：8字节，不分片时为0）
     * @param options 选项字段（可为null，长度需为4的倍数）
     * @param data 传输层数据（段/数据报）
     * @return 完整的IPv4数据包字节数组
     * @throws UnknownHostException 无效IP地址异常
     */
    publicstaticbyte[] encapsulateIpv4Packet(String srcIp, String destIp, byte protocol, int ttl,
                                              int identification, short flags, int fragOffset, byte[] options, byte[] data)
            throws UnknownHostException {
        // 1. 验证参数有效性
        Inet4Address srcInetIp = (Inet4Address) InetAddress.getByName(srcIp);
        Inet4Address destInetIp = (Inet4Address) InetAddress.getByName(destIp);

        // 计算头部长度（IHL）：单位为32位字（4字节），最小值5（20字节）
        int headerLength = MIN_HEADER_LENGTH;
        if (options != null && options.length > 0) {
            // 选项长度必须是4的倍数，否则填充
            int optionsLength = (options.length + 3) / 4 * 4;
            headerLength += optionsLength;
            if (headerLength > MAX_HEADER_LENGTH) {
                thrownew IllegalArgumentException("IPv4头部长度超过最大值60字节");
            }
        }
        byte ihl = (byte) (headerLength / 4); // 转换为32位字单位

        // 验证标志和片偏移（标志3位，片偏移13位，组合为2字节）
        if ((flags & 0xFFF8) != 0) { // 标志仅低3位有效
            thrownew IllegalArgumentException("标志字段超出3位有效范围");
        }
        if (fragOffset > 0x1FFF) { // 片偏移仅13位有效
            thrownew IllegalArgumentException("片偏移超出13位有效范围");
        }
        short flagsFragOffset = (short) ((flags << 13) | fragOffset);

        // 2. 计算总长度（头部长度 + 数据长度）
        int totalLength = headerLength + (data != null ? data.length : 0);
        if (totalLength > 65535) { // 总长度16位，最大值65535
            thrownew IllegalArgumentException("IPv4数据包总长度超过最大值65535字节");
        }

        // 3. 构建IPv4头部字节缓冲区
        ByteBuffer headerBuffer = ByteBuffer.allocate(headerLength);

        // 3.1 版本 + 头部长度（1字节）：版本4（高4位），IHL（低4位）
        headerBuffer.put((byte) ((VERSION_IPV4 << 4) | (ihl & 0x0F)));

        // 3.2 服务类型（TOS，1字节）：默认0（普通服务）
        headerBuffer.put((byte) 0x00);

        // 3.3 总长度（2字节，大端序）
        headerBuffer.putShort((short) totalLength);

        // 3.4 标识（2字节，大端序）
        headerBuffer.putShort((short) identification);

        // 3.5 标志 + 片偏移（2字节，大端序）
        headerBuffer.putShort(flagsFragOffset);

        // 3.6 生存时间（TTL，1字节）
        headerBuffer.put((byte) ttl);

        // 3.7 协议类型（1字节）
        headerBuffer.put(protocol);

        // 3.8 头部校验和（先填0，后续计算）
        headerBuffer.putShort((short) 0x0000);

        // 3.9 源IP地址（4字节）
        headerBuffer.put(srcInetIp.getAddress());

        // 3.10 目的IP地址（4字节）
        headerBuffer.put(destInetIp.getAddress());

        // 3.11 选项字段（可选）
        if (options != null && options.length > 0) {
            headerBuffer.put(options);
            // 填充至32位字倍数（若需）
            int paddingLength = headerLength - headerBuffer.position();
            for (int i = 0; i < paddingLength; i++) {
                headerBuffer.put((byte) 0x00);
            }
        }

        // 4. 计算头部校验和
        headerBuffer.rewind();
        byte[] headerBytes = newbyte[headerLength];
        headerBuffer.get(headerBytes);
        short checksum = calculateIpChecksum(headerBytes);

        // 5. 重新写入校验和
        headerBuffer.rewind();
        headerBuffer.position(HEADER_CHECKSUM_LENGTH + VERSION_IHL_LENGTH + TOS_LENGTH + TOTAL_LENGTH_LENGTH + IDENTIFICATION_LENGTH + FLAGS_FRAG_OFFSET_LENGTH + TTL_LENGTH + PROTOCOL_LENGTH);
        headerBuffer.putShort(checksum);

        // 6. 组合头部和数据，形成完整IPv4数据包
        ByteBuffer packetBuffer = ByteBuffer.allocate(totalLength);
        packetBuffer.put(headerBuffer.array());
        if (data != null) {
            packetBuffer.put(data);
        }

        return packetBuffer.array();
    }

    /**
     * 解封装IPv4数据包
     * @param ipPacket 完整的IPv4数据包字节数组
     * @return 解封装后的结果（包含源IP、目的IP、协议类型、数据等）
     * @throws UnknownHostException IP地址解析异常
     */
    public static Ipv4PacketDecapsulateResult decapsulateIpv4Packet(byte[] ipPacket) throws UnknownHostException {
        ByteBuffer packetBuffer = ByteBuffer.wrap(ipPacket);

        // 1. 读取版本 + 头部长度（1字节）
        byte versionIhl = packetBuffer.get();
        byte version = (byte) ((versionIhl >> 4) & 0x0F);
        if (version != VERSION_IPV4) {
            thrownew IllegalArgumentException("非IPv4数据包");
        }
        int headerLength = ((versionIhl & 0x0F)) * 4; // 转换为字节单位
        if (headerLength < MIN_HEADER_LENGTH || headerLength > MAX_HEADER_LENGTH || headerLength > ipPacket.length) {
            thrownew IllegalArgumentException("无效的IPv4头部长度");
        }

        // 2. 读取服务类型（TOS，1字节）
        byte tos = packetBuffer.get();

        // 3. 读取总长度（2字节，大端序）
        short totalLength = packetBuffer.getShort();
        if (totalLength != ipPacket.length) {
            thrownew IllegalArgumentException("数据包总长度不匹配");
        }

        // 4. 读取标识（2字节，大端序）
        short identification = packetBuffer.getShort();

        // 5. 读取标志 + 片偏移（2字节，大端序）
        short flagsFragOffset = packetBuffer.getShort();
        byte flags = (byte) ((flagsFragOffset >> 13) & 0x07); // 低3位为标志
        int fragOffset = flagsFragOffset & 0x1FFF; // 低13位为片偏移

        // 6. 读取生存时间（TTL，1字节）
        byte ttl = packetBuffer.get();

        // 7. 读取协议类型（1字节）
        byte protocol = packetBuffer.get();

        // 8. 读取并验证头部校验和（2字节，大端序）
        short checksum = packetBuffer.getShort();
        // 复制头部字节，计算校验和
        byte[] headerBytes = newbyte[headerLength];
        System.arraycopy(ipPacket, 0, headerBytes, 0, headerLength);
        // 临时将校验和字段置0，重新计算
        ByteBuffer tempHeaderBuffer = ByteBuffer.wrap(headerBytes);
        tempHeaderBuffer.position(HEADER_CHECKSUM_LENGTH + VERSION_IHL_LENGTH + TOS_LENGTH + TOTAL_LENGTH_LENGTH + IDENTIFICATION_LENGTH + FLAGS_FRAG_OFFSET_LENGTH + TTL_LENGTH + PROTOCOL_LENGTH);
        tempHeaderBuffer.putShort((short) 0x0000);
        short calculatedChecksum = calculateIpChecksum(headerBytes);
        boolean isHeaderValid = (calculatedChecksum == checksum);

        // 9. 读取源IP地址（4字节）
        byte[] srcIpBytes = newbyte[IP_ADDRESS_LENGTH];
        packetBuffer.get(srcIpBytes);
        Inet4Address srcIp = (Inet4Address) InetAddress.getByAddress(srcIpBytes);

        // 10. 读取目的IP地址（4字节）
        byte[] destIpBytes = newbyte[IP_ADDRESS_LENGTH];
        packetBuffer.get(destIpBytes);
        Inet4Address destIp = (Inet4Address) InetAddress.getByAddress(destIpBytes);

        // 11. 跳过选项和填充字段
        packetBuffer.position(headerLength);

        // 12. 读取数据部分
        int dataLength = totalLength - headerLength;
        byte[] data = newbyte[dataLength];
        if (dataLength > 0) {
            packetBuffer.get(data);
        }

        returnnew Ipv4PacketDecapsulateResult(
                version, headerLength, tos, totalLength, identification, flags, fragOffset,
                ttl, protocol, isHeaderValid, srcIp.getHostAddress(), destIp.getHostAddress(), data
        );
    }

    /**
     * 计算IPv4头部校验和（遵循RFC 1071标准）
     * @param header 待计算校验和的IPv4头部字节数组
     * @return 校验和（16位）
     */
    private static short calculateIpChecksum(byte[] header) {
        int sum = 0;
        int i = 0;
        // 按16位（2字节）为单位累加
        while (i < header.length) {
            sum += ((header[i] & 0xFF) << 8) | (header[i + 1] & 0xFF);
            i += 2;
        }
        // 处理累加溢出（高16位与低16位相加）
        while ((sum >> 16) != 0) {
            sum = (sum & 0xFFFF) + (sum >> 16);
        }
        // 取反得到校验和
        return (short) ~sum;
    }

    /**
     * 解封装结果封装类
     */
    publicstaticclass Ipv4PacketDecapsulateResult {
        privatefinalbyte version;
        privatefinalint headerLength;
        privatefinalbyte tos;
        privatefinalshort totalLength;
        privatefinalshort identification;
        privatefinalbyte flags;
        privatefinalint fragOffset;
        privatefinalbyte ttl;
        privatefinalbyte protocol;
        privatefinalboolean isHeaderValid;
        privatefinal String srcIp;
        privatefinal String destIp;
        privatefinalbyte[] data;

        public Ipv4PacketDecapsulateResult(byte version, int headerLength, byte tos, short totalLength,
                                           short identification, byte flags, int fragOffset, byte ttl, byte protocol,
                                           boolean isHeaderValid, String srcIp, String destIp, byte[] data) {
            this.version = version;
            this.headerLength = headerLength;
            this.tos = tos;
            this.totalLength = totalLength;
            this.identification = identification;
            this.flags = flags;
            this.fragOffset = fragOffset;
            this.ttl = ttl;
            this.protocol = protocol;
            this.isHeaderValid = isHeaderValid;
            this.srcIp = srcIp;
            this.destIp = destIp;
            this.data = data;
        }

        // getter方法
        public byte getVersion() { return version; }
        public int getHeaderLength() { return headerLength; }
        public byte getTos() { return tos; }
        public short getTotalLength() { return totalLength; }
        public short getIdentification() { return identification; }
        public byte getFlags() { return flags; }
        public int getFragOffset() { return fragOffset; }
        public byte getTtl() { return ttl; }
        public byte getProtocol() { return protocol; }
        public boolean isHeaderValid() { return isHeaderValid; }
        public String getSrcIp() { return srcIp; }
        public String getDestIp() { return destIp; }
        publicbyte[] getData() { return data; }
    }

    // 测试方法
    public static void main(String[] args) {
        try {
            // 1. 准备测试数据（模拟传输层TCP数据）
            String tcpDataStr = "This is a test TCP segment data.";
            byte[] tcpData = tcpDataStr.getBytes(StandardCharsets.UTF_8);

            // 2. 封装IPv4数据包
            String srcIp = "192.168.1.100";
            String destIp = "192.168.1.1";
            byte protocol = PROTOCOL_TCP;
            int ttl = 64;
            int identification = 12345;
            short flags = 0x00; // 允许分片，无更多分片
            int fragOffset = 0; // 不分片
            byte[] options = null; // 无选项字段

            byte[] ipv4Packet = encapsulateIpv4Packet(srcIp, destIp, protocol, ttl, identification,
                    flags, fragOffset, options, tcpData);
            System.out.println("IPv4数据包封装完成，总长度：" + ipv4Packet.length + "字节");

            // 3. 解封装IPv4数据包
            Ipv4PacketDecapsulateResult result = decapsulateIpv4Packet(ipv4Packet);
            System.out.println("\nIPv4数据包解封装结果：");
            System.out.println("IP版本：IPv" + result.getVersion());
            System.out.println("头部长度：" + result.getHeaderLength() + "字节");
            System.out.println("源IP地址：" + result.getSrcIp());
            System.out.println("目的IP地址：" + result.getDestIp());
            System.out.println("上层协议类型：" + (result.getProtocol() == PROTOCOL_TCP ? "TCP协议（6）" : "其他协议"));
            System.out.println("生存时间（TTL）：" + result.getTtl() + "跳");
            System.out.println("标识：" + result.getIdentification());
            System.out.println("标志：" + result.getFlags() + "（0=允许分片）");
            System.out.println("片偏移：" + result.getFragOffset() + "（不分片）");
            System.out.println("头部有效性：" + (result.isHeaderValid() ? "有效（校验和通过）" : "无效（校验和失败）"));
            System.out.println("解封装后的数据（传输层数据）：" + new String(result.getData(), StandardCharsets.UTF_8));

            // 4. 测试校验和失败场景（篡改头部数据）
            ipv4Packet[10] = (byte) 0xAA; // 篡改源IP地址的一个字节
            Ipv4PacketDecapsulateResult invalidResult = decapsulateIpv4Packet(ipv4Packet);
            System.out.println("\n篡改头部数据后的解封装结果：");
            System.out.println("头部有效性：" + (invalidResult.isHeaderValid() ? "有效" : "无效（校验和失败）"));
        } catch (Exception e) {
            e.printStackTrace();
        }
    }
}

<dependency>
    <groupId>org.pcap4j</groupId>
    <artifactId>pcap4j-core</artifactId>
    <version>1.8.2</version>
</dependency>
<dependency>
    <groupId>org.pcap4j</groupId>
    <artifactId>pcap4j-packet</artifactId>
    <version>1.8.2</version>
</dependency>
<dependency>
    <groupId>org.pcap4j</groupId>
    <artifactId>pcap4j-nio</artifactId>
    <version>1.8.2</version>
</dependency>

import org.pcap4j.core.*;
import org.pcap4j.packet.*;
import org.pcap4j.packet.namednumber.EtherType;
import org.pcap4j.packet.namednumber.IpNumber;
import org.pcap4j.packet.namednumber.IpVersion;
import org.pcap4j.util.Inet4AddressUtils;
import org.pcap4j.util.MacAddress;

import java.net.Inet4Address;
import java.net.InetAddress;
import java.net.UnknownHostException;
import java.util.concurrent.TimeoutException;

/**
 * 网络层实战：ICMP协议实现（模拟ping命令）
 */
publicclass IcmpProtocolDemo {
    // 超时时间（单位：毫秒）
    privatestaticfinalint TIMEOUT = 3000;
    // 发送ICMP请求的次数
    privatestaticfinalint SEND_COUNT = 4;
    // ICMP Echo Request/Reply 类型码
    privatestaticfinalbyte ICMP_ECHO_REQUEST_TYPE = 8;
    privatestaticfinalbyte ICMP_ECHO_REPLY_TYPE = 0;
    privatestaticfinalbyte ICMP_ECHO_CODE = 0;

    /**
     * 发送ICMP Echo Request，接收Echo Reply（模拟ping）
     * @param ifName 网卡名称（如Windows的"以太网"，Linux的"eth0"）
     * @param srcIp 本地IPv4地址
     * @param destIp 目标IPv4地址（需要ping的IP）
     * @param sequence 序列号（用于匹配请求和响应）
     * @param id 标识（通常为进程ID，用于区分不同ping实例）
     */
    public static void ping(String ifName, Inet4Address srcIp, Inet4Address destIp, short sequence, int id) {
        PcapHandle handle = null;
        try {
            // 1. 获取网卡设备并打开
            PcapNetworkInterface nif = Pcaps.getDevByName(ifName);
            if (nif == null) {
                thrownew IllegalArgumentException("未找到网卡：" + ifName);
            }
            int snapLen = 65536;
            handle = nif.openLive(snapLen, PcapNetworkInterface.PromiscuousMode.PROMISCUOUS, TIMEOUT);

            // 2. 构建ICMP Echo Request包
            for (int i = 0; i < SEND_COUNT; i++) {
                // 2.1 构建ICMP头部（Echo Request）
                IcmpV4CommonPacket.IcmpV4CommonHeader icmpHeader = new IcmpV4CommonPacket.IcmpV4CommonHeader.Builder()
                        .type(ICMP_ECHO_REQUEST_TYPE) // 类型：Echo Request
                        .code(ICMP_ECHO_CODE) // 代码：0
                        .checksum((short) 0) // 先填0，后续计算
                        .id((short) id) // 标识
                        .sequence(sequence) // 序列号
                        .build();

                // 2.2 构建ICMP payload（可选，通常为时间戳）
                long timestamp = System.currentTimeMillis();
                byte[] payloadData = String.valueOf(timestamp).getBytes();
                Packet icmpPayload = new SimplePacket.Builder().payload(ByteBuffer.wrap(payloadData)).build();

                // 2.3 构建完整ICMP包（计算校验和）
                IcmpV4CommonPacket icmpPacket = new IcmpV4CommonPacket.Builder()
                        .header(icmpHeader)
                        .payload(icmpPayload)
                        .build();
                // 计算ICMP校验和（需组合ICMP头部和payload）
                short checksum = calculateIcmpChecksum(icmpPacket);
                icmpPacket = new IcmpV4CommonPacket.Builder(icmpPacket)
                        .header(new IcmpV4CommonPacket.IcmpV4CommonHeader.Builder(icmpPacket.getHeader())
                                .checksum(checksum)
                                .build())
                        .build();

                // 2.4 构建IPv4头部（协议类型为ICMP）
                IpV4Packet.IpV4Header ipHeader = new IpV4Packet.IpV4Header.Builder()
                        .version(IpVersion.IPV4)
                        .ihl((byte) 5) // 头部长度20字节
                        .tos((byte) 0)
                        .totalLength((short) (20 + icmpPacket.getRawData().length)) // IP头部20字节 + ICMP包长度
                        .identification((short) (id + i)) // 标识递增
                        .ttl((byte) 64) // 生存时间64跳
                        .protocol(IpNumber.ICMPV4) // 协议类型：ICMP
                        .srcAddr(srcIp)
                        .dstAddr(destIp)
                        .checksum((short) 0) // 先填0，后续计算
                        .build();

                // 2.5 构建完整IPv4数据包（计算校验和）
                IpV4Packet ipPacket = new IpV4Packet.Builder()
                        .header(ipHeader)
                        .payload(icmpPacket)
                        .build();
                short ipChecksum = calculateIpChecksum(ipPacket.getHeader().getRawData());
                ipPacket = new IpV4Packet.Builder(ipPacket)
                        .header(new IpV4Packet.IpV4Header.Builder(ipPacket.getHeader())
                                .checksum(ipChecksum)
                                .build())
                        .build();

                // 2.6 构建以太网帧（通过ARP获取目的MAC，此处简化为广播或已知MAC，实际需调用ARP解析）
                MacAddress srcMac = MacAddress.getByInetAddress(srcIp); // 获取本地IP对应的MAC
                MacAddress destMac = getDestMacByArp(handle, srcIp, srcMac, destIp); // ARP解析目的MAC
                if (destMac == null) {
                    System.err.println("ARP解析目的MAC失败，无法发送ICMP请求");
                    continue;
                }

                EthernetPacket.EthernetHeader etherHeader = new EthernetPacket.EthernetHeader.Builder()
                        .dstAddr(destMac)
                        .srcAddr(srcMac)
                        .type(EtherType.IPV4)
                        .build();

                Packet finalPacket = new EthernetPacket.Builder()
                        .header(etherHeader)
                        .payload(ipPacket)
                        .build();

                // 3. 发送ICMP请求
                long sendTime = System.currentTimeMillis();
                handle.sendPacket(finalPacket);
                System.out.printf("发送ICMP Echo Request：目标IP=%s，序列号=%d，发送时间=%dms%n",
                        destIp.getHostAddress(), sequence, sendTime);

                // 4. 捕获并解析ICMP Echo Reply
                captureIcmpReply(handle, srcIp, destIp, sequence, id, sendTime);

                sequence++;
                Thread.sleep(1000); // 间隔1秒发送一次
            }
        } catch (PcapNativeException | NotOpenException | InterruptedException | TimeoutException e) {
            e.printStackTrace();
        } finally {
            if (handle != null) {
                handle.close();
            }
        }
    }

    /**
     * 捕获并解析ICMP Echo Reply
     */
    private static void captureIcmpReply(PcapHandle handle, Inet4Address srcIp, Inet4Address destIp,
                                        short sequence, int id, long sendTime) throws TimeoutException {
        try {
            Packet packet = handle.getNextPacketEx();
            // 过滤：仅处理IPv4 + ICMP包
            if (packet.contains(IpV4Packet.class) && packet.contains(IcmpV4CommonPacket.class)) {
                IpV4Packet ipPacket = packet.get(IpV4Packet.class);
                IcmpV4CommonPacket icmpPacket = packet.get(IcmpV4CommonPacket.class);

                // 验证：是否为目标IP的ICMP Echo Reply，且标识和序列号匹配
                if (ipPacket.getHeader().getSrcAddr().equals(destIp)
                        && ipPacket.getHeader().getDstAddr().equals(srcIp)
                        && icmpPacket.getHeader().getType() == ICMP_ECHO_REPLY_TYPE
                        && icmpPacket.getHeader().getCode() == ICMP_ECHO_CODE
                        && icmpPacket.getHeader().getId() == (short) id
                        && icmpPacket.getHeader().getSequence() == sequence) {

                    long receiveTime = System.currentTimeMillis();
                    long delay = receiveTime - sendTime;
                    System.out.printf("收到ICMP Echo Reply：来自IP=%s，序列号=%d，接收时间=%dms，延迟=%dms%n",
                            destIp.getHostAddress(), sequence, receiveTime, delay);
                }
            }
        } catch (TimeoutException e) {
            System.err.printf("未收到ICMP Echo Reply：目标IP=%s，序列号=%d，超时%dms%n",
                    destIp.getHostAddress(), sequence, TIMEOUT);
            throw e;
        } catch (PcapNativeException | NotOpenException e) {
            e.printStackTrace();
        }
    }

    /**
     * 调用ARP解析目的IP对应的MAC地址（复用3.2.6的ARP逻辑）
     */
    private static MacAddress getDestMacByArp(PcapHandle handle, Inet4Address srcIp, MacAddress srcMac, Inet4Address targetIp) {
        try {
            // 构建ARP请求包
            ArpPacket.ArpHeader arpHeader = new ArpPacket.ArpHeader.Builder()
                    .hardwareType(ArpHardwareType.ETHERNET)
                    .protocolType(EtherType.IPV4)
                    .hardwareAddrLength((byte) MacAddress.SIZE_IN_BYTES)
                    .protocolAddrLength((byte) 4)
                    .operation(ArpOperation.REQUEST)
                    .senderHardwareAddr(srcMac)
                    .senderProtocolAddr(srcIp)
                    .targetHardwareAddr(MacAddress.ETHER_BROADCAST_ADDRESS)
                    .targetProtocolAddr(targetIp)
                    .build();

            EthernetPacket.EthernetHeader etherHeader = new EthernetPacket.EthernetHeader.Builder()
                    .dstAddr(MacAddress.ETHER_BROADCAST_ADDRESS)
                    .srcAddr(srcMac)
                    .type(EtherType.ARP)
                    .build();

            Packet arpPacket = new EthernetPacket.Builder()
                    .header(etherHeader)
                    .payload(new ArpPacket.Builder().header(arpHeader).build())
                    .build();

            // 发送ARP请求
            handle.sendPacket(arpPacket);

            // 捕获ARP响应
            long startTime = System.currentTimeMillis();
            while (System.currentTimeMillis() - startTime < TIMEOUT) {
                Packet packet = handle.getNextPacketEx();
                if (packet.contains(ArpPacket.class)) {
                    ArpPacket receivedArp = packet.get(ArpPacket.class);
                    if (receivedArp.getHeader().getOperation() == ArpOperation.REPLY
                            && receivedArp.getHeader().getSenderProtocolAddr().equals(targetIp)
                            && receivedArp.getHeader().getTargetProtocolAddr().equals(srcIp)) {
                        return receivedArp.getHeader().getSenderHardwareAddr();
                    }
                }
            }
        } catch (Exception e) {
            e.printStackTrace();
        }
        returnnull;
    }

    /**
     * 计算ICMP校验和（遵循RFC 1071）
     */
    private static short calculateIcmpChecksum(IcmpV4CommonPacket icmpPacket) {
        byte[] data = icmpPacket.getRawData();
        int sum = 0;
        int i = 0;
        while (i < data.length) {
            sum += ((data[i] & 0xFF) << 8) | (data[i + 1] & 0xFF);
            i += 2;
        }
        // 处理奇数长度（ICMP包长度为偶数，此处备用）
        if (data.length % 2 != 0) {
            sum += (data[data.length - 1] & 0xFF) << 8;
        }
        while ((sum >> 16) != 0) {
            sum = (sum & 0xFFFF) + (sum >> 16);
        }
        return (short) ~sum;
    }

    /**
     * 计算IPv4头部校验和
     */
    private static short calculateIpChecksum(byte[] ipHeaderData) {
        int sum = 0;
        int i = 0;
        while (i < ipHeaderData.length) {
            sum += ((ipHeaderData[i] & 0xFF) << 8) | (ipHeaderData[i + 1] & 0xFF);
            i += 2;
        }
        while ((sum >> 16) != 0) {
            sum = (sum & 0xFFFF) + (sum >> 16);
        }
        return (short) ~sum;
    }

    // 测试方法
    public static void main(String[] args) {
        try {
            // 配置参数（需根据实际环境修改）
            String ifName = "以太网"; // 网卡名称
            Inet4Address srcIp = (Inet4Address) InetAddress.getByName("192.168.1.100"); // 本地IP
            Inet4Address destIp = (Inet4Address) InetAddress.getByName("192.168.1.1"); // 目标IP（如路由器）
            short sequence = 1; // 初始序列号
            int id = ProcessHandle.current().pid() > Short.MAX_VALUE ? (int) (ProcessHandle.current().pid() % Short.MAX_VALUE) : (int) ProcessHandle.current().pid(); // 标识（进程ID）

            System.out.printf("开始ping %s（本地进程ID：%d）%n", destIp.getHostAddress(), id);
            ping(ifName, srcIp, destIp, sequence, id);
        } catch (UnknownHostException e) {
            System.err.println("无效的IP地址：" + e.getMessage());
        }
    }
}

import java.io.*;
import java.net.ServerSocket;
import java.net.Socket;

/**
 * 传输层实战：TCP服务端（可靠连接与数据传输）
 */
publicclass TcpServerDemo {
    privatestaticfinalint PORT = 8888; // 监听端口
    privatestaticfinalint BUFFER_SIZE = 1024; // 缓冲区大小

    public static void main(String[] args) {
        ServerSocket serverSocket = null;
        try {
            // 1. 创建ServerSocket，绑定端口，开始监听客户端连接
            serverSocket = new ServerSocket(PORT);
            System.out.println("TCP服务端启动成功，监听端口：" + PORT + "，等待客户端连接...");

            // 循环监听，支持多客户端（简化版，单线程处理一个客户端）
            while (true) {
                // 2. 等待客户端连接（阻塞方法，直到有客户端连接）
                Socket clientSocket = serverSocket.accept();
                System.out.println("客户端连接成功：" + clientSocket.getInetAddress() + ":" + clientSocket.getPort());

                // 3. 处理客户端数据（输入流读取数据，输出流响应数据）
                try (InputStream inputStream = clientSocket.getInputStream();
                     OutputStream outputStream = clientSocket.getOutputStream();
                     BufferedReader reader = new BufferedReader(new InputStreamReader(inputStream, "UTF-8"));
                     PrintWriter writer = new PrintWriter(new OutputStreamWriter(outputStream, "UTF-8"), true)) {

                    String receivedData;
                    // 读取客户端发送的数据（按行读取，直到客户端关闭连接）
                    while ((receivedData = reader.readLine()) != null) {
                        System.out.println("收到客户端[" + clientSocket.getPort() + "]数据：" + receivedData);

                        // 响应客户端（确认收到数据）
                        String response = "服务端已收到：" + receivedData;
                        writer.println(response);
                        System.out.println("向客户端[" + clientSocket.getPort() + "]发送响应：" + response);
                    }

                    System.out.println("客户端[" + clientSocket.getPort() + "]断开连接");
                } catch (IOException e) {
                    System.err.println("处理客户端[" + clientSocket.getPort() + "]数据异常：" + e.getMessage());
                } finally {
                    // 关闭客户端连接
                    clientSocket.close();
                }
            }
        } catch (IOException e) {
            System.err.println("TCP服务端启动失败：" + e.getMessage());
        } finally {
            if (serverSocket != null) {
                try {
                    serverSocket.close();
                } catch (IOException e) {
                    e.printStackTrace();
                }
            }
        }
    }
}

import java.io.*;
import java.net.Socket;

/**
 * 传输层实战：TCP客户端（可靠连接与数据传输）
 */
publicclass TcpClientDemo {
    privatestaticfinal String SERVER_IP = "127.0.0.1"; // 服务端IP
    privatestaticfinalint SERVER_PORT = 8888; // 服务端端口
    privatestaticfinalint BUFFER_SIZE = 1024; // 缓冲区大小

    public static void main(String[] args) {
        Socket socket = null;
        try {
            // 1. 创建Socket，发起连接（三次握手在此过程中完成）
            socket = new Socket(SERVER_IP, SERVER_PORT);
            System.out.println("TCP客户端连接服务端成功：" + SERVER_IP + ":" + SERVER_PORT);

            // 2. 向服务端发送数据（输出流），并接收响应（输入流）
            try (OutputStream outputStream = socket.getOutputStream();
                 InputStream inputStream = socket.getInputStream();
                 PrintWriter writer = new PrintWriter(new OutputStreamWriter(outputStream, "UTF-8"), true);
                 BufferedReader reader = new BufferedReader(new InputStreamReader(inputStream, "UTF-8"))) {

                // 发送测试数据
                String[] testData = {"Hello TCP Server!", "This is a reliable data transfer test.", "I'm TCP Client."};
                for (String data : testData) {
                    writer.println(data);
                    System.out.println("向服务端发送数据：" + data);

                    // 接收服务端响应（阻塞方法，直到收到响应）
                    String response = reader.readLine();
                    System.out.println("收到服务端响应：" + response);

                    Thread.sleep(1000); // 间隔1秒发送一次
                }

                // 发送结束标志
                writer.println("exit");
                System.out.println("向服务端发送结束标志：exit");
            }
        } catch (IOException | InterruptedException e) {
            System.err.println("TCP客户端通信异常：" + e.getMessage());
        } finally {
            if (socket != null) {
                try {
                    // 关闭Socket（四次挥手在此过程中完成）
                    socket.close();
                    System.out.println("TCP客户端断开连接");
                } catch (IOException e) {
                    e.printStackTrace();
                }
            }
        }
    }
}

import java.net.DatagramPacket;
import java.net.DatagramSocket;
import java.net.InetAddress;

/**
 * 传输层实战：UDP服务端（高效数据传输）
 */
publicclass UdpServerDemo {
    privatestaticfinalint PORT = 9999; // 监听端口
    privatestaticfinalint BUFFER_SIZE = 1024; // 缓冲区大小

    public static void main(String[] args) {
        DatagramSocket datagramSocket = null;
        try {
            // 1. 创建DatagramSocket，绑定端口（UDP无需监听连接，仅绑定端口即可）
            datagramSocket = new DatagramSocket(PORT);
            System.out.println("UDP服务端启动成功，监听端口：" + PORT + "，等待接收数据...");

            // 2. 创建接收缓冲区和DatagramPacket（用于接收数据）
            byte[] receiveBuffer = newbyte[BUFFER_SIZE];
            DatagramPacket receivePacket = new DatagramPacket(receiveBuffer, receiveBuffer.length);

            // 循环接收数据（UDP无连接，无需建立连接，直接接收）
            while (true) {
                // 3. 接收UDP数据报（阻塞方法，直到收到数据）
                datagramSocket.receive(receivePacket);

                // 4. 解析接收的数据
                String receivedData = new String(receivePacket.getData(), 0, receivePacket.getLength(), "UTF-8");
                InetAddress clientIp = receivePacket.getAddress();
                int clientPort = receivePacket.getPort();
                System.out.printf("收到客户端[%s:%d]数据：%s%n", clientIp.getHostAddress(), clientPort, receivedData);

                // 5. 可选：响应客户端（UDP无确认机制，需手动发送响应）
                if ("exit".equals(receivedData)) {
                    System.out.printf("客户端[%s:%d]请求退出，服务端停止接收该客户端数据%n", clientIp.getHostAddress(), clientPort);
                    String response = "服务端已收到退出请求";
                    byte[] responseBuffer = response.getBytes("UTF-8");
                    DatagramPacket responsePacket = new DatagramPacket(responseBuffer, responseBuffer.length, clientIp, clientPort);
                    datagramSocket.send(responsePacket);
                    continue;
                }

                String response = "服务端已收到：" + receivedData;
                byte[] responseBuffer = response.getBytes("UTF-8");
                // 创建响应数据报（指定客户端IP和端口）
                DatagramPacket responsePacket = new DatagramPacket(responseBuffer, responseBuffer.length, clientIp, clientPort);
                // 发送响应
                datagramSocket.send(responsePacket);
                System.out.printf("向客户端[%s:%d]发送响应：%s%n", clientIp.getHostAddress(), clientPort, response);

                // 清空接收缓冲区（避免残留数据）
                receivePacket.setLength(receiveBuffer.length);
            }
        } catch (Exception e) {
            System.err.println("UDP服务端运行异常：" + e.getMessage());
        } finally {
            if (datagramSocket != null && !datagramSocket.isClosed()) {
                datagramSocket.close();
                System.out.println("UDP服务端关闭");
            }
        }
    }
}

import java.net.DatagramPacket;
import java.net.DatagramSocket;
import java.net.InetAddress;

/**
 * 传输层实战：UDP客户端（高效数据传输）
 */
publicclass UdpClientDemo {
    privatestaticfinal String SERVER_IP = "127.0.0.1"; // 服务端IP
    privatestaticfinalint SERVER_PORT = 9999; // 服务端端口
    privatestaticfinalint BUFFER_SIZE = 1024; // 缓冲区大小

    public static void main(String[] args) {
        DatagramSocket datagramSocket = null;
        try {
            // 1. 创建DatagramSocket（UDP无需指定端口，系统自动分配动态端口）
            datagramSocket = new DatagramSocket();
            System.out.println("UDP客户端启动成功，系统分配端口：" + datagramSocket.getLocalPort());

            // 2. 准备发送的数据
            String[] testData = {"Hello UDP Server!", "This is an efficient data transfer test.", "I'm UDP Client."};
            InetAddress serverIp = InetAddress.getByName(SERVER_IP);

            for (String data : testData) {
                // 3. 封装UDP数据报（指定服务端IP、端口和数据）
                byte[] sendBuffer = data.getBytes("UTF-8");
                DatagramPacket sendPacket = new DatagramPacket(sendBuffer, sendBuffer.length, serverIp, SERVER_PORT);

                // 4. 发送UDP数据报（无连接，直接发送，无需建立连接）
                datagramSocket.send(sendPacket);
                System.out.printf("向服务端[%s:%d]发送数据：%s%n", SERVER_IP, SERVER_PORT, data);

                // 5. 接收服务端响应（UDP无确认，需手动接收，非阻塞可设置超时）
                byte[] receiveBuffer = newbyte[BUFFER_SIZE];
                DatagramPacket receivePacket = new DatagramPacket(receiveBuffer, receiveBuffer.length);
                datagramSocket.setSoTimeout(2000); // 设置接收超时2秒
                try {
                    datagramSocket.receive(receivePacket);
                    String response = new String(receivePacket.getData(), 0, receivePacket.getLength(), "UTF-8");
                    System.out.printf("收到服务端[%s:%d]响应：%s%n", receivePacket.getAddress().getHostAddress(), receivePacket.getPort(), response);
                } catch (Exception e) {
                    System.err.printf("未收到服务端响应，超时2秒：%s%n", e.getMessage());
                }

                Thread.sleep(1000); // 间隔1秒发送一次
            }

            // 发送退出标志
            String exitData = "exit";
            byte[] exitBuffer = exitData.getBytes("UTF-8");
            DatagramPacket exitPacket = new DatagramPacket(exitBuffer, exitBuffer.length, serverIp, SERVER_PORT);
            datagramSocket.send(exitPacket);
            System.out.printf("向服务端[%s:%d]发送退出标志：%s%n", SERVER_IP, SERVER_PORT, exitData);

            // 接收退出响应
            byte[] exitResponseBuffer = newbyte[BUFFER_SIZE];
            DatagramPacket exitResponsePacket = new DatagramPacket(exitResponseBuffer, exitResponseBuffer.length);
            datagramSocket.receive(exitResponsePacket);
            String exitResponse = new String(exitResponsePacket.getData(), 0, exitResponsePacket.getLength(), "UTF-8");
            System.out.printf("收到服务端退出响应：%s%n", exitResponse);

        } catch (Exception e) {
            System.err.println("UDP客户端运行异常：" + e.getMessage());
        } finally {
            if (datagramSocket != null && !datagramSocket.isClosed()) {
                datagramSocket.close();
                System.out.println("UDP客户端关闭");
            }
        }
    }
}

import java.io.*;
import java.net.ServerSocket;
import java.net.Socket;
import java.util.HashMap;
import java.util.Map;

/**
 * 会话层实战：同步点与断点续传（基于TCP）
 */
publicclass SessionLayerBreakpointResumeDemo {
    // 同步点间隔（每传输1024字节插入一个同步点）
    privatestaticfinalint CHECKPOINT_INTERVAL = 1024;
    // 会话存储：key=会话ID，value=已传输字节数（同步点）
    privatestaticfinal Map<String, Long> sessionCheckpoints = new HashMap<>();

    /**
     * 服务端：接收文件，支持断点续传
     */
    staticclass FileServer {
        privatestaticfinalint PORT = 8080;

        public void start() {
            ServerSocket serverSocket = null;
            try {
                serverSocket = new ServerSocket(PORT);
                System.out.println("文件服务端启动，监听端口：" + PORT);

                while (true) {
                    Socket clientSocket = serverSocket.accept();
                    System.out.println("客户端连接：" + clientSocket.getInetAddress());
                    // 处理文件传输会话
                    new Thread(() -> handleFileSession(clientSocket)).start();
                }
            } catch (IOException e) {
                e.printStackTrace();
            } finally {
                if (serverSocket != null) {
                    try {
                        serverSocket.close();
                    } catch (IOException e) {
                        e.printStackTrace();
                    }
                }
            }
        }

        private void handleFileSession(Socket clientSocket) {
            try (InputStream in = clientSocket.getInputStream();
                 OutputStream out = clientSocket.getOutputStream();
                 DataInputStream dataIn = new DataInputStream(in);
                 DataOutputStream dataOut = new DataOutputStream(out)) {

                // 1. 接收会话ID和文件名（会话标识）
                String sessionId = dataIn.readUTF();
                String fileName = dataIn.readUTF();
                System.out.printf("会话[%s]：开始接收文件[%s]%n", sessionId, fileName);

                // 2. 检查同步点（断点），返回已传输字节数
                long checkpoint = sessionCheckpoints.getOrDefault(sessionId, 0L);
                dataOut.writeLong(checkpoint);
                dataOut.flush();
                System.out.printf("会话[%s]：已传输字节数（同步点）：%d%n", sessionId, checkpoint);

                // 3. 接收文件数据（从同步点开始）
                File file = new File("server_" + fileName);
                try (RandomAccessFile raf = new RandomAccessFile(file, "rw")) {
                    raf.seek(checkpoint); // 定位到同步点位置
                    byte[] buffer = newbyte[1024];
                    int len;
                    long totalReceived = checkpoint;

                    while ((len = dataIn.read(buffer)) != -1) {
                        // 传输完成标志（len=0表示结束）
                        if (len == 0) break;

                        raf.write(buffer, 0, len);
                        totalReceived += len;

                        // 插入同步点（每CHECKPOINT_INTERVAL字节更新一次）
                        if (totalReceived % CHECKPOINT_INTERVAL == 0) {
                            sessionCheckpoints.put(sessionId, totalReceived);
                            System.out.printf("会话[%s]：更新同步点：%d字节%n", sessionId, totalReceived);
                        }
                    }

                    // 传输完成，清除会话同步点
                    sessionCheckpoints.remove(sessionId);
                    System.out.printf("会话[%s]：文件[%s]传输完成，总大小：%d字节%n", sessionId, fileName, totalReceived);
                }

            } catch (IOException e) {
                System.err.printf("会话异常：%s%n", e.getMessage());
            } finally {
                try {
                    clientSocket.close();
                } catch (IOException e) {
                    e.printStackTrace();
                }
            }
        }
    }

    /**
     * 客户端：发送文件，支持断点续传
     */
    staticclass FileClient {
        privatefinal String serverIp;
        privatefinalint serverPort;

        public FileClient(String serverIp, int serverPort) {
            this.serverIp = serverIp;
            this.serverPort = serverPort;
        }

        /**
         * 发送文件
         * @param sessionId 唯一会话ID
         * @param filePath 本地文件路径
         */
        public void sendFile(String sessionId, String filePath) {
            Socket socket = null;
            try {
                socket = new Socket(serverIp, serverPort);
                File file = new File(filePath);
                if (!file.exists()) {
                    System.err.println("文件不存在：" + filePath);
                    return;
                }

                try (OutputStream out = socket.getOutputStream();
                     InputStream in = socket.getInputStream();
                     DataOutputStream dataOut = new DataOutputStream(out);
                     DataInputStream dataIn = new DataInputStream(in);
                     RandomAccessFile raf = new RandomAccessFile(file, "r")) {

                    // 1. 发送会话ID和文件名
                    dataOut.writeUTF(sessionId);
                    dataOut.writeUTF(file.getName());
                    dataOut.flush();

                    // 2. 接收服务端的同步点（已传输字节数）
                    long checkpoint = dataIn.readLong();
                    System.out.printf("会话[%s]：从同步点开始传输：%d字节%n", sessionId, checkpoint);

                    // 3. 从同步点开始发送文件数据
                    raf.seek(checkpoint);
                    byte[] buffer = newbyte[1024];
                    int len;
                    long totalSent = checkpoint;

                    while ((len = raf.read(buffer)) != -1) {
                        dataOut.write(buffer, 0, len);
                        dataOut.flush();
                        totalSent += len;

                        // 模拟传输中断（每传输2个同步点中断一次，测试断点续传）
                        if (totalSent % (CHECKPOINT_INTERVAL * 2) == 0 && checkpoint == 0) {
                            System.out.println("模拟传输中断！");
                            thrownew IOException("手动中断传输");
                        }
                    }

                    // 发送结束标志（空数据）
                    dataOut.write(buffer, 0, 0);
                    dataOut.flush();
                    System.out.printf("会话[%s]：文件传输完成，总大小：%d字节%n", sessionId, totalSent);

                } catch (IOException e) {
                    System.err.printf("传输中断，已发送：%d字节，可断点续传%n", totalSent);
                    // 重新发送（断点续传）
                    System.out.println("尝试断点续传...");
                    sendFile(sessionId, filePath);
                }

            } catch (IOException e) {
                e.printStackTrace();
            } finally {
                if (socket != null) {
                    try {
                        socket.close();
                    } catch (IOException e) {
                        e.printStackTrace();
                    }
                }
            }
        }
    }

    // 测试方法
    public static void main(String[] args) {
        // 启动服务端线程
        new Thread(() -> new SessionLayerBreakpointResumeDemo().new FileServer().start()).start();

        // 等待服务端启动
        try {
            Thread.sleep(1000);
        } catch (InterruptedException e) {
            e.printStackTrace();
        }

        // 客户端发送文件（会话ID=test_session_001，文件路径需修改为本地文件）
        FileClient client = new SessionLayerBreakpointResumeDemo().new FileClient("127.0.0.1", 8080);
        client.sendFile("test_session_001", "test_file.txt"); // 替换为实际本地文件路径
    }
}

<!-- JSON序列化：Jackson -->
<dependency>
    <groupId>com.fasterxml.jackson.core</groupId>
    <artifactId>jackson-databind</artifactId>
    <version>2.15.2</version>
</dependency>
<!-- 加密工具：BouncyCastle（增强加密算法支持） -->
<dependency>
    <groupId>org.bouncycastle</groupId>
    <artifactId>bcprov-jdk18on</artifactId>
    <version>1.76</version>
</dependency>

import com.fasterxml.jackson.core.JsonProcessingException;
import com.fasterxml.jackson.databind.ObjectMapper;
import org.bouncycastle.jce.provider.BouncyCastleProvider;

import javax.crypto.Cipher;
import javax.crypto.spec.SecretKeySpec;
import java.io.ByteArrayInputStream;
import java.io.ByteArrayOutputStream;
import java.io.IOException;
import java.util.Base64;
import java.util.zip.GZIPInputStream;
import java.util.zip.GZIPOutputStream;
import java.security.Security;

/**
 * 表示层实战：序列化（JSON）+ 加密（AES）+ 压缩（GZIP）
 */
publicclass PresentationLayerDemo {
    // 初始化加密提供者
    static {
        Security.addProvider(new BouncyCastleProvider());
    }

    // AES加密配置（128位密钥，ECB模式，PKCS7填充）
    privatestaticfinal String AES_ALGORITHM = "AES/ECB/PKCS7Padding";
    privatestaticfinal String AES_KEY = "1234567890ABCDEF"; // 16字节密钥（128位）

    // JSON序列化工具
    privatestaticfinal ObjectMapper OBJECT_MAPPER = new ObjectMapper();

    /**
     * 表示层发送端处理：对象→JSON序列化→AES加密→GZIP压缩
     * @param data 待传输的业务对象
     * @return 处理后的字节流（可直接通过传输层发送）
     * @throws Exception 处理异常
     */
    publicstaticbyte[] sendSideProcess(Object data) throws Exception {
        // 1. 第一步：JSON序列化（对象→JSON字符串→字节流）
        String jsonStr = OBJECT_MAPPER.writeValueAsString(data);
        byte[] jsonBytes = jsonStr.getBytes("UTF-8");
        System.out.println("表示层-序列化：" + jsonStr);

        // 2. 第二步：AES加密（保护敏感数据）
        byte[] encryptedBytes = aesEncrypt(jsonBytes);
        String encryptedBase64 = Base64.getEncoder().encodeToString(encryptedBytes);
        System.out.println("表示层-加密后（Base64）：" + encryptedBase64);

        // 3. 第三步：GZIP压缩（减少传输量）
        byte[] compressedBytes = gzipCompress(encryptedBytes);
        System.out.println("表示层-压缩后字节数：" + compressedBytes.length);

        return compressedBytes;
    }

    /**
     * 表示层接收端处理：GZIP解压缩→AES解密→JSON反序列化→对象
     * @param receivedBytes 传输层接收的字节流
     * @param clazz 目标对象类型
     * @return 解析后的业务对象
     * @throws Exception 处理异常
     */
    publicstatic <T> T receiveSideProcess(byte[] receivedBytes, Class<T> clazz) throws Exception {
        // 1. 第一步：GZIP解压缩
        byte[] decompressedBytes = gzipDecompress(receivedBytes);
        System.out.println("表示层-解压缩后字节数：" + decompressedBytes.length);

        // 2. 第二步：AES解密
        byte[] decryptedBytes = aesDecrypt(decompressedBytes);
        String decryptedJson = new String(decryptedBytes, "UTF-8");
        System.out.println("表示层-解密后（JSON）：" + decryptedJson);

        // 3. 第三步：JSON反序列化（字节流→JSON字符串→对象）
        T data = OBJECT_MAPPER.readValue(decryptedJson, clazz);
        System.out.println("表示层-反序列化：" + data);

        return data;
    }

    /**
     * AES加密
     */
    privatestaticbyte[] aesEncrypt(byte[] data) throws Exception {
        SecretKeySpec keySpec = new SecretKeySpec(AES_KEY.getBytes("UTF-8"), "AES");
        Cipher cipher = Cipher.getInstance(AES_ALGORITHM);
        cipher.init(Cipher.ENCRYPT_MODE, keySpec);
        return cipher.doFinal(data);
    }

    /**
     * AES解密
     */
    privatestaticbyte[] aesDecrypt(byte[] encryptedData) throws Exception {
        SecretKeySpec keySpec = new SecretKeySpec(AES_KEY.getBytes("UTF-8"), "AES");
        Cipher cipher = Cipher.getInstance(AES_ALGORITHM);
        cipher.init(Cipher.DECRYPT_MODE, keySpec);
        return cipher.doFinal(encryptedData);
    }

    /**
     * GZIP压缩
     */
    privatestaticbyte[] gzipCompress(byte[] data) throws IOException {
        try (ByteArrayOutputStream bos = new ByteArrayOutputStream();
             GZIPOutputStream gzipOut = new GZIPOutputStream(bos)) {
            gzipOut.write(data);
            gzipOut.finish(); // 完成压缩，确保所有数据写入
            return bos.toByteArray();
        }
    }

    /**
     * GZIP解压缩
     */
    privatestaticbyte[] gzipDecompress(byte[] compressedData) throws IOException {
        try (ByteArrayInputStream bis = new ByteArrayInputStream(compressedData);
             GZIPInputStream gzipIn = new GZIPInputStream(bis);
             ByteArrayOutputStream bos = new ByteArrayOutputStream()) {
            byte[] buffer = newbyte[1024];
            int len;
            while ((len = gzipIn.read(buffer)) != -1) {
                bos.write(buffer, 0, len);
            }
            return bos.toByteArray();
        }
    }

    // 测试用业务对象（模拟应用层数据）
    staticclass UserData {
        private String username;
        private String password; // 敏感数据，需加密
        privateint age;
        private String address;

        // 无参构造（Jackson反序列化必需）
        public UserData() {}

        public UserData(String username, String password, int age, String address) {
            this.username = username;
            this.password = password;
            this.age = age;
            this.address = address;
        }

        // Getter & Setter
        public String getUsername() { return username; }
        public void setUsername(String username) { this.username = username; }
        public String getPassword() { return password; }
        public void setPassword(String password) { this.password = password; }
        public int getAge() { return age; }
        public void setAge(int age) { this.age = age; }
        public String getAddress() { return address; }
        public void setAddress(String address) { this.address = address; }

        @Override
        public String toString() {
            return"UserData{" +
                    "username='" + username + '\'' +
                    ", password='" + password + '\'' +
                    ", age=" + age +
                    ", address='" + address + '\'' +
                    '}';
        }
    }

    // 测试方法
    public static void main(String[] args) {
        try {
            // 1. 应用层数据（模拟待传输的业务对象）
            UserData sendData = new UserData("zhangsan", "12345678", 25, "北京市海淀区");
            System.out.println("应用层原始数据：" + sendData);

            // 2. 发送端表示层处理
            byte[] sendBytes = sendSideProcess(sendData);
            System.out.println("----------------------------------------");

            // 3. 模拟传输层传输（直接传递字节流，无额外处理）
            byte[] receivedBytes = sendBytes;

            // 4. 接收端表示层处理
            UserData receivedData = receiveSideProcess(receivedBytes, UserData.class);
            System.out.println("----------------------------------------");
            System.out.println("应用层最终接收数据：" + receivedData);

            // 验证数据一致性
            System.out.println("数据传输一致性：" + sendData.toString().equals(receivedData.toString()));

        } catch (Exception e) {
            System.err.println("表示层处理异常：" + e.getMessage());
            e.printStackTrace();
        }
    }
}

import java.io.*;
import java.net.ServerSocket;
import java.net.Socket;
import java.util.Date;

/**
 * 应用层实战：基于Socket实现简单HTTP服务端
 */
publicclass HttpServerDemo {
    privatestaticfinalint PORT = 80; // HTTP默认端口

    public static void main(String[] args) {
        try (ServerSocket serverSocket = new ServerSocket(PORT)) {
            System.out.println("HTTP服务端启动成功，监听端口：" + PORT);
            System.out.println("请在浏览器中访问：http://127.0.0.1");

            // 循环接收浏览器请求
            while (true) {
                // 等待客户端连接（浏览器发起连接）
                Socket clientSocket = serverSocket.accept();
                System.out.println("收到客户端连接：" + clientSocket.getInetAddress());

                // 多线程处理请求（支持并发）
                new Thread(() -> handleHttpRequest(clientSocket)).start();
            }

        } catch (IOException e) {
            System.err.println("HTTP服务端启动失败：" + e.getMessage());
            e.printStackTrace();
        }
    }

    /**
     * 处理HTTP请求，返回HTTP响应
     */
    private static void handleHttpRequest(Socket clientSocket) {
        try (InputStream in = clientSocket.getInputStream();
             OutputStream out = clientSocket.getOutputStream();
             BufferedReader reader = new BufferedReader(new InputStreamReader(in, "UTF-8"));
             PrintWriter writer = new PrintWriter(new OutputStreamWriter(out, "UTF-8"), true)) {

            // 1. 读取HTTP请求行（第一行）
            String requestLine = reader.readLine();
            if (requestLine == null) {
                return;
            }
            System.out.println("HTTP请求行：" + requestLine);

            // 2. 读取HTTP请求头（直到空行结束）
            String headerLine;
            while ((headerLine = reader.readLine()) != null && !headerLine.isEmpty()) {
                System.out.println("HTTP请求头：" + headerLine);
            }
            System.out.println("----------------------------------------");

            // 3. 构造HTTP响应（响应行 + 响应头 + 响应体）
            // 3.1 响应行（HTTP/1.1 200 OK）
            String responseLine = "HTTP/1.1 200 OK";

            // 3.2 响应头（Date、Content-Type、Content-Length等）
            String dateHeader = "Date: " + new Date();
            String contentTypeHeader = "Content-Type: text/html; charset=UTF-8";
            String serverHeader = "Server: MySimpleHttpServer/1.0";

            // 3.3 响应体（HTML内容，浏览器展示用）
            String htmlBody = "<!DOCTYPE html>" +
                              "<html>" +
                              "<head><title>简单HTTP服务端</title></head>" +
                              "<body>" +
                              "<h1>Hello, HTTP Application Layer!</h1>" +
                              "<p>这是基于Java Socket实现的应用层HTTP服务端</p>" +
                              "<p>请求时间：" + new Date() + "</p>" +
                              "</body>" +
                              "</html>";

            // 3.4 响应体长度（字节数）
            String contentLengthHeader = "Content-Length: " + htmlBody.getBytes("UTF-8").length;

            // 4. 发送HTTP响应（响应行→响应头→空行→响应体）
            writer.println(responseLine);
            writer.println(dateHeader);
            writer.println(contentTypeHeader);
            writer.println(serverHeader);
            writer.println(contentLengthHeader);
            writer.println(); // 空行（响应头与响应体的分隔符）
            writer.println(htmlBody);

            System.out.println("HTTP响应发送完成");
            System.out.println("----------------------------------------");

        } catch (IOException e) {
            System.err.println("处理HTTP请求异常：" + e.getMessage());
            e.printStackTrace();
        } finally {
            // 关闭客户端连接
            try {
                clientSocket.close();
            } catch (IOException e) {
                e.printStackTrace();
            }
        }
    }
}

import java.net.DatagramPacket;
import java.net.DatagramSocket;
import java.net.InetAddress;
import java.nio.ByteBuffer;

/**
 * 应用层实战：基于UDP实现简单DNS解析客户端
 */
publicclass DnsClientDemo {
    // DNS服务器IP（公共DNS：阿里云223.5.5.5）
    privatestaticfinal String DNS_SERVER_IP = "223.5.5.5";
    // DNS默认端口（UDP 53）
    privatestaticfinalint DNS_SERVER_PORT = 53;
    // 缓冲区大小
    privatestaticfinalint BUFFER_SIZE = 1024;

    public static void main(String[] args) {
        // 待解析的域名
        String domain = "www.baidu.com";
        try {
            System.out.println("开始解析域名：" + domain);
            String ip = resolveDomain(domain);
            System.out.println("域名[" + domain + "]解析结果：" + ip);

        } catch (Exception e) {
            System.err.println("DNS解析异常：" + e.getMessage());
            e.printStackTrace();
        }
    }

    /**
     * 解析域名：发送DNS查询请求，接收并解析响应
     */
    private static String resolveDomain(String domain) throws Exception {
        try (DatagramSocket socket = new DatagramSocket()) {
            socket.setSoTimeout(3000); // 超时3秒

            // 1. 构造DNS查询请求字节流
            byte[] requestData = buildDnsRequest(domain);

            // 2. 发送DNS查询请求（UDP）
            InetAddress dnsServerAddr = InetAddress.getByName(DNS_SERVER_IP);
            DatagramPacket sendPacket = new DatagramPacket(requestData, requestData.length, dnsServerAddr, DNS_SERVER_PORT);
            socket.send(sendPacket);
            System.out.println("已向DNS服务器[" + DNS_SERVER_IP + ":" + DNS_SERVER_PORT + "]发送查询请求");

            // 3. 接收DNS响应
            byte[] receiveBuffer = newbyte[BUFFER_SIZE];
            DatagramPacket receivePacket = new DatagramPacket(receiveBuffer, receiveBuffer.length);
            socket.receive(receivePacket);
            System.out.println("收到DNS服务器响应，长度：" + receivePacket.getLength());

            // 4. 解析DNS响应，提取IP地址
            return parseDnsResponse(receivePacket.getData());
        }
    }

    /**
     * 构造DNS查询请求
     * DNS头部（12字节）：ID(2)+Flags(2)+QDCOUNT(2)+ANCOUNT(2)+NSCOUNT(2)+ARCOUNT(2)
     */
    privatestaticbyte[] buildDnsRequest(String domain) {
        ByteBuffer buffer = ByteBuffer.allocate(512);

        // 1. 头部（12字节）
        buffer.putShort((short) 0x1234); // ID（随机数，用于匹配请求与响应）
        buffer.putShort((short) 0x0100); // Flags：标准查询（0x0000）+ 递归查询（0x0100）
        buffer.putShort((short) 1);      // QDCOUNT：查询问题数=1
        buffer.putShort((short) 0);      // ANCOUNT：回答数=0
        buffer.putShort((short) 0);      // NSCOUNT：权威服务器数=0
        buffer.putShort((short) 0);      // ARCOUNT：附加记录数=0

        // 2. 查询问题：域名（按点分割，每个部分前加长度）+ 类型（A记录，2字节）+ 类（IN，2字节）
        String[] domainParts = domain.split("\\.");
        for (String part : domainParts) {
            byte[] partBytes = part.getBytes();
            buffer.put((byte) partBytes.length); // 每个域名片段的长度
            buffer.put(partBytes);               // 域名片段字节
        }
        buffer.put((byte) 0); // 域名结束标志（0x00）
        buffer.putShort((short) 1);  // QTYPE：1=A记录（IPv4地址）
        buffer.putShort((short) 1);  // QCLASS：1=IN（互联网地址）

        // 压缩缓冲区，返回有效字节
        byte[] requestData = newbyte[buffer.position()];
        System.arraycopy(buffer.array(), 0, requestData, 0, buffer.position());
        return requestData;
    }

    /**
     * 解析DNS响应，提取IPv4地址
     */
    private static String parseDnsResponse(byte[] responseData) {
        ByteBuffer buffer = ByteBuffer.wrap(responseData);

        // 1. 跳过头部（12字节）
        buffer.position(12);

        // 2. 跳过查询问题（先读取域名，直到0x00结束）
        while (true) {
            byte len = buffer.get();
            if (len == 0) {
                break;
            }
            buffer.position(buffer.position() + len); // 跳过当前域名片段
        }
        buffer.position(buffer.position() + 4); // 跳过QTYPE（2）和QCLASS（2）

        // 3. 解析回答资源记录（ANCOUNT≥1）
        // 先读取ANCOUNT（回答数）
        buffer.position(6); // ANCOUNT位于头部第7-8字节（索引6-7）
        short anCount = buffer.getShort();
        if (anCount == 0) {
            thrownew RuntimeException("DNS响应中无回答记录");
        }

        // 解析每个回答记录
        for (int i = 0; i < anCount; i++) {
            // 跳过NAME（可能是压缩格式，简化处理：直接跳过2字节）
            buffer.position(buffer.position() + 2);

            // 读取TYPE（2字节）：1=A记录
            short type = buffer.getShort();
            // 读取CLASS（2字节）：1=IN
            short clazz = buffer.getShort();
            // 跳过TTL（4字节）
            buffer.position(buffer.position() + 4);
            // 读取数据长度（2字节）
            short dataLen = buffer.getShort();

            // 若为A记录，提取IP地址
            if (type == 1 && clazz == 1) {
                byte[] ipBytes = newbyte[dataLen];
                buffer.get(ipBytes);
                // 转换为点分十进制IP
                return String.format("%d.%d.%d.%d",
                        ipBytes[0] & 0xFF,
                        ipBytes[1] & 0xFF,
                        ipBytes[2] & 0xFF,
                        ipBytes[3] & 0xFF);
            } else {
                // 非A记录，跳过数据部分
                buffer.position(buffer.position() + dataLen);
            }
        }

        thrownew RuntimeException("未找到IPv4地址记录（A记录）");
    }
}
