微服务API安全机制详解：从底层逻辑到实战落地

// pom.xml依赖配置
<dependency>
    <groupId>org.springframework.boot</groupId>
    <artifactId>spring-boot-starter-web</artifactId>
    <version>3.2.0</version>
</dependency>
<dependency>
    <groupId>org.springframework.boot</groupId>
    <artifactId>spring-boot-starter-security</artifactId>
    <version>3.2.0</version>
</dependency>
<dependency>
    <groupId>org.projectlombok</groupId>
    <artifactId>lombok</artifactId>
    <version>1.18.30</version>
    <scope>provided</scope>
</dependency>

// ApiKey认证过滤器
package com.jam.demo.security;

import jakarta.servlet.FilterChain;
import jakarta.servlet.ServletException;
import jakarta.servlet.http.HttpServletRequest;
import jakarta.servlet.http.HttpServletResponse;
import lombok.extern.slf4j.Slf4j;
import org.springframework.security.authentication.UsernamePasswordAuthenticationToken;
import org.springframework.security.core.context.SecurityContextHolder;
import org.springframework.security.core.userdetails.User;
import org.springframework.security.core.userdetails.UserDetails;
import org.springframework.web.filter.OncePerRequestFilter;
import org.springframework.util.StringUtils;

import java.io.IOException;
import java.util.Collections;

/**
 * API Key认证过滤器
 * 作者：ken
 */
@Slf4j
publicclass ApiKeyAuthFilter extends OncePerRequestFilter {

    privatestaticfinal String API_KEY_HEADER = "X-API-Key";
    privatestaticfinal String VALID_API_KEY = "valid-api-key-123456"; // 实际应存储在配置中心或数据库

    @Override
    protected void doFilterInternal(HttpServletRequest request, HttpServletResponse response,
                                   FilterChain filterChain) throws ServletException, IOException {
        try {
            String apiKey = request.getHeader(API_KEY_HEADER);

            if (!StringUtils.hasText(apiKey)) {
                thrownew IllegalArgumentException("API Key不能为空");
            }

            if (!VALID_API_KEY.equals(apiKey)) {
                thrownew IllegalArgumentException("无效的API Key");
            }

            // 认证通过，设置SecurityContext
            UserDetails userDetails = User.withUsername("api-client")
                    .password("")
                    .authorities(Collections.emptyList())
                    .build();
            UsernamePasswordAuthenticationToken authentication =
                new UsernamePasswordAuthenticationToken(userDetails, null, userDetails.getAuthorities());
            SecurityContextHolder.getContext().setAuthentication(authentication);

        } catch (Exception e) {
            log.error("API Key认证失败", e);
            response.setStatus(HttpServletResponse.SC_UNAUTHORIZED);
            response.getWriter().write("认证失败：" + e.getMessage());
            return;
        }

        filterChain.doFilter(request, response);
    }
}

// Security配置类
package com.jam.demo.config;

import com.jam.demo.security.ApiKeyAuthFilter;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.security.config.annotation.web.builders.HttpSecurity;
import org.springframework.security.config.annotation.web.configuration.EnableWebSecurity;
import org.springframework.security.config.http.SessionCreationPolicy;
import org.springframework.security.web.SecurityFilterChain;
import org.springframework.security.web.authentication.UsernamePasswordAuthenticationFilter;

/**
 * 安全配置类
 * 作者：ken
 */
@Configuration
@EnableWebSecurity
publicclass SecurityConfig {

    @Bean
    public SecurityFilterChain filterChain(HttpSecurity http) throws Exception {
        http
            .csrf(csrf -> csrf.disable()) // API场景下通常禁用CSRF
            .sessionManagement(session -> session.sessionCreationPolicy(SessionCreationPolicy.STATELESS))
            .authorizeHttpRequests(auth -> auth
                .anyRequest().authenticated()
            )
            .addFilterBefore(new ApiKeyAuthFilter(), UsernamePasswordAuthenticationFilter.class);

        return http.build();
    }
}

// 测试控制器
package com.jam.demo.controller;

import io.swagger.v3.oas.annotations.Operation;
import io.swagger.v3.oas.annotations.Parameter;
import io.swagger.v3.oas.annotations.enums.ParameterIn;
import io.swagger.v3.oas.annotations.security.SecurityRequirement;
import lombok.extern.slf4j.Slf4j;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RestController;

/**
 * 测试控制器
 * 作者：ken
 */
@RestController
@RequestMapping("/api/test")
@Slf4j
@SecurityRequirement(name = "ApiKeyAuth")
publicclass TestController {

    @GetMapping("/hello")
    @Operation(summary = "测试接口",
               parameters = @Parameter(name = "X-API-Key", in = ParameterIn.HEADER, required = true))
    public String hello() {
        return"Hello, API Key authenticated!";
    }
}

// Swagger配置
package com.jam.demo.config;

import io.swagger.v3.oas.models.OpenAPI;
import io.swagger.v3.oas.models.info.Info;
import io.swagger.v3.oas.models.security.SecurityScheme;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;

@Configuration
publicclass SwaggerConfig {

    @Bean
    public OpenAPI customOpenAPI() {
        returnnew OpenAPI()
                .info(new Info().title("微服务API安全示例").version("1.0"))
                .schemaRequirement("ApiKeyAuth", new SecurityScheme()
                        .type(SecurityScheme.Type.APIKEY)
                        .in(SecurityScheme.In.HEADER)
                        .name("X-API-Key"));
    }
}

// 添加JWT依赖
<dependency>
    <groupId>io.jsonwebtoken</groupId>
    <artifactId>jjwt-api</artifactId>
    <version>0.12.3</version>
</dependency>
<dependency>
    <groupId>io.jsonwebtoken</groupId>
    <artifactId>jjwt-impl</artifactId>
    <version>0.12.3</version>
    <scope>runtime</scope>
</dependency>
<dependency>
    <groupId>io.jsonwebtoken</groupId>
    <artifactId>jjwt-jackson</artifactId>
    <version>0.12.3</version>
    <scope>runtime</scope>
</dependency>

// JWT工具类
package com.jam.demo.security;

import io.jsonwebtoken.Jwts;
import io.jsonwebtoken.security.Keys;
import lombok.extern.slf4j.Slf4j;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.stereotype.Component;
import org.springframework.util.StringUtils;

import javax.crypto.SecretKey;
import java.util.Date;

/**
 * JWT工具类
 * 作者：ken
 */
@Component
@Slf4j
publicclass JwtUtil {

    @Value("${jwt.secret}")
    private String secret;

    @Value("${jwt.expiration}")
    privatelong expiration; // 单位：秒

    /**
     * 生成JWT令牌
     * @param username 用户名
     * @return JWT令牌
     */
    public String generateToken(String username) {
        SecretKey key = Keys.hmacShaKeyFor(secret.getBytes());

        return Jwts.builder()
                .subject(username)
                .issuedAt(new Date())
                .expiration(new Date(System.currentTimeMillis() + expiration * 1000))
                .signWith(key)
                .compact();
    }

    /**
     * 验证JWT令牌
     * @param token JWT令牌
     * @return 验证结果
     */
    public boolean validateToken(String token) {
        if (!StringUtils.hasText(token)) {
            returnfalse;
        }

        try {
            SecretKey key = Keys.hmacShaKeyFor(secret.getBytes());
            Jwts.parser()
                .verifyWith(key)
                .build()
                .parseSignedClaims(token);
            returntrue;
        } catch (Exception e) {
            log.error("JWT验证失败", e);
            returnfalse;
        }
    }

    /**
     * 从令牌中获取用户名
     * @param token JWT令牌
     * @return 用户名
     */
    public String getUsernameFromToken(String token) {
        SecretKey key = Keys.hmacShaKeyFor(secret.getBytes());
        return Jwts.parser()
                .verifyWith(key)
                .build()
                .parseSignedClaims(token)
                .getPayload()
                .getSubject();
    }
}

// JWT认证过滤器
package com.jam.demo.security;

import jakarta.servlet.FilterChain;
import jakarta.servlet.ServletException;
import jakarta.servlet.http.HttpServletRequest;
import jakarta.servlet.http.HttpServletResponse;
import lombok.RequiredArgsConstructor;
import lombok.extern.slf4j.Slf4j;
import org.springframework.security.authentication.UsernamePasswordAuthenticationToken;
import org.springframework.security.core.context.SecurityContextHolder;
import org.springframework.security.core.userdetails.User;
import org.springframework.security.core.userdetails.UserDetails;
import org.springframework.web.filter.OncePerRequestFilter;
import org.springframework.util.StringUtils;

import java.io.IOException;
import java.util.Collections;

/**
 * JWT认证过滤器
 * 作者：ken
 */
@Slf4j
@RequiredArgsConstructor
publicclass JwtAuthFilter extends OncePerRequestFilter {

    privatestaticfinal String AUTHORIZATION_HEADER = "Authorization";
    privatestaticfinal String BEARER_PREFIX = "Bearer ";

    privatefinal JwtUtil jwtUtil;

    @Override
    protected void doFilterInternal(HttpServletRequest request, HttpServletResponse response,
                                   FilterChain filterChain) throws ServletException, IOException {
        try {
            String token = extractToken(request);

            if (StringUtils.hasText(token) && jwtUtil.validateToken(token)) {
                String username = jwtUtil.getUsernameFromToken(token);

                UserDetails userDetails = User.withUsername(username)
                        .password("")
                        .authorities(Collections.emptyList())
                        .build();

                UsernamePasswordAuthenticationToken authentication =
                    new UsernamePasswordAuthenticationToken(userDetails, null, userDetails.getAuthorities());
                SecurityContextHolder.getContext().setAuthentication(authentication);
            }
        } catch (Exception e) {
            log.error("JWT认证失败", e);
        }

        filterChain.doFilter(request, response);
    }

    private String extractToken(HttpServletRequest request) {
        String authHeader = request.getHeader(AUTHORIZATION_HEADER);
        if (StringUtils.hasText(authHeader) && authHeader.startsWith(BEARER_PREFIX)) {
            return authHeader.substring(BEARER_PREFIX.length());
        }
        returnnull;
    }
}

// 认证控制器
package com.jam.demo.controller;

import com.jam.demo.security.JwtUtil;
import io.swagger.v3.oas.annotations.Operation;
import io.swagger.v3.oas.annotations.tags.Tag;
import lombok.RequiredArgsConstructor;
import lombok.extern.slf4j.Slf4j;
import org.springframework.web.bind.annotation.PostMapping;
import org.springframework.web.bind.annotation.RequestBody;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RestController;
import org.springframework.util.StringUtils;

/**
 * 认证控制器
 * 作者：ken
 */
@RestController
@RequestMapping("/api/auth")
@RequiredArgsConstructor
@Slf4j
@Tag(name = "认证接口", description = "JWT认证相关接口")
publicclass AuthController {

    privatefinal JwtUtil jwtUtil;

    @PostMapping("/login")
    @Operation(summary = "用户登录", description = "验证用户名密码并生成JWT令牌")
    public String login(@RequestBody LoginRequest request) {
        // 实际应从数据库验证用户名密码
        if ("admin".equals(request.getUsername()) && "password123".equals(request.getPassword())) {
            return jwtUtil.generateToken(request.getUsername());
        }
        thrownew IllegalArgumentException("用户名或密码错误");
    }

    publicstaticclass LoginRequest {
        private String username;
        private String password;

        // getter/setter
        public String getUsername() { return username; }
        public void setUsername(String username) { this.username = username; }
        public String getPassword() { return password; }
        public void setPassword(String password) { this.password = password; }
    }
}

// 权限注解
package com.jam.demo.security;

import java.lang.annotation.ElementType;
import java.lang.annotation.Retention;
import java.lang.annotation.RetentionPolicy;
import java.lang.annotation.Target;

/**
 * 权限注解
 * 作者：ken
 */
@Target({ElementType.METHOD})
@Retention(RetentionPolicy.RUNTIME)
public@interface RequirePermission {
    String value();
}

// 权限拦截器
package com.jam.demo.security;

import jakarta.servlet.http.HttpServletRequest;
import jakarta.servlet.http.HttpServletResponse;
import lombok.extern.slf4j.Slf4j;
import org.springframework.stereotype.Component;
import org.springframework.web.method.HandlerMethod;
import org.springframework.web.servlet.HandlerInterceptor;
import org.springframework.security.core.Authentication;
import org.springframework.security.core.context.SecurityContextHolder;
import org.springframework.util.ObjectUtils;

import java.lang.reflect.Method;

/**
 * 权限拦截器
 * 作者：ken
 */
@Component
@Slf4j
publicclass PermissionInterceptor implements HandlerInterceptor {

    @Override
    public boolean preHandle(HttpServletRequest request, HttpServletResponse response,
                            Object handler) throws Exception {
        if (!(handler instanceof HandlerMethod)) {
            returntrue;
        }

        HandlerMethod handlerMethod = (HandlerMethod) handler;
        Method method = handlerMethod.getMethod();

        RequirePermission annotation = method.getAnnotation(RequirePermission.class);
        if (ObjectUtils.isEmpty(annotation)) {
            returntrue;
        }

        String requiredPermission = annotation.value();

        // 获取当前用户权限（实际应从数据库/缓存获取）
        Authentication authentication = SecurityContextHolder.getContext().getAuthentication();
        String username = authentication.getName();

        if ("admin".equals(username) && "user:delete".equals(requiredPermission)) {
            returntrue;
        }

        response.setStatus(HttpServletResponse.SC_FORBIDDEN);
        response.getWriter().write("无访问权限");
        returnfalse;
    }
}

// Web配置
package com.jam.demo.config;

import com.jam.demo.security.PermissionInterceptor;
import lombok.RequiredArgsConstructor;
import org.springframework.context.annotation.Configuration;
import org.springframework.web.servlet.config.annotation.InterceptorRegistry;
import org.springframework.web.servlet.config.annotation.WebMvcConfigurer;

/**
 * Web配置类
 * 作者：ken
 */
@Configuration
@RequiredArgsConstructor
publicclass WebConfig implements WebMvcConfigurer {

    privatefinal PermissionInterceptor permissionInterceptor;

    @Override
    public void addInterceptors(InterceptorRegistry registry) {
        registry.addInterceptor(permissionInterceptor)
                .addPathPatterns("/api/**");
    }
}

// 用户控制器
package com.jam.demo.controller;

import com.jam.demo.security.RequirePermission;
import io.swagger.v3.oas.annotations.Operation;
import io.swagger.v3.oas.annotations.security.SecurityRequirement;
import io.swagger.v3.oas.annotations.tags.Tag;
import lombok.extern.slf4j.Slf4j;
import org.springframework.web.bind.annotation.DeleteMapping;
import org.springframework.web.bind.annotation.PathVariable;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RestController;

/**
 * 用户控制器
 * 作者：ken
 */
@RestController
@RequestMapping("/api/users")
@Slf4j
@Tag(name = "用户接口", description = "用户管理相关接口")
@SecurityRequirement(name = "ApiKeyAuth")
publicclass UserController {

    @DeleteMapping("/{id}")
    @Operation(summary = "删除用户", description = "根据ID删除用户（需要管理员权限）")
    @RequirePermission("user:delete")
    public String deleteUser(@PathVariable Long id) {
        log.info("删除用户：{}", id);
        return"用户" + id + "已删除";
    }
}

// MyBatis-Plus数据权限插件
package com.jam.demo.config;

import com.baomidou.mybatisplus.core.plugins.InterceptorIgnoreHelper;
import com.baomidou.mybatisplus.core.toolkit.PluginUtils;
import com.baomidou.mybatisplus.extension.plugins.handler.DataPermissionHandler;
import com.baomidou.mybatisplus.extension.plugins.inner.DataPermissionInterceptor;
import lombok.extern.slf4j.Slf4j;
import org.apache.ibatis.executor.statement.StatementHandler;
import org.apache.ibatis.mapping.BoundSql;
import org.apache.ibatis.mapping.MappedStatement;
import org.apache.ibatis.reflection.MetaObject;
import org.apache.ibatis.reflection.SystemMetaObject;
import org.springframework.security.core.context.SecurityContextHolder;
import org.springframework.stereotype.Component;

import java.sql.Connection;
import java.util.Map;

/**
 * 数据权限处理器
 * 作者：ken
 */
@Component
@Slf4j
publicclass CustomDataPermissionHandler implements DataPermissionHandler {

    @Override
    public String getSqlSegment(StatementHandler statementHandler,
                               MetaObject metaObject,
                               MappedStatement mappedStatement) {
        // 获取当前用户名
        String username = SecurityContextHolder.getContext().getAuthentication().getName();

        // 管理员可以查看所有数据
        if ("admin".equals(username)) {
            return"";
        }

        // 普通用户只能查看自己的数据
        return" AND create_user = '" + username + "'";
    }
}

// MyBatis配置
package com.jam.demo.config;

import com.baomidou.mybatisplus.annotation.DbType;
import com.baomidou.mybatisplus.extension.plugins.MybatisPlusInterceptor;
import com.baomidou.mybatisplus.extension.plugins.inner.DataPermissionInterceptor;
import com.baomidou.mybatisplus.extension.plugins.inner.PaginationInnerInterceptor;
import lombok.RequiredArgsConstructor;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;

/**
 * MyBatis配置
 * 作者：ken
 */
@Configuration
@RequiredArgsConstructor
publicclass MybatisPlusConfig {

    privatefinal CustomDataPermissionHandler dataPermissionHandler;

    @Bean
    public MybatisPlusInterceptor mybatisPlusInterceptor() {
        MybatisPlusInterceptor interceptor = new MybatisPlusInterceptor();

        // 分页插件
        interceptor.addInnerInterceptor(new PaginationInnerInterceptor(DbType.MYSQL));

        // 数据权限插件
        DataPermissionInterceptor dataPermissionInterceptor = new DataPermissionInterceptor();
        dataPermissionInterceptor.setDataPermissionHandler(dataPermissionHandler);
        interceptor.addInnerInterceptor(dataPermissionInterceptor);

        return interceptor;
    }
}

// 订单实体
package com.jam.demo.entity;

import com.baomidou.mybatisplus.annotation.IdType;
import com.baomidou.mybatisplus.annotation.TableId;
import com.baomidou.mybatisplus.annotation.TableName;
import lombok.Data;

import java.math.BigDecimal;
import java.time.LocalDateTime;

/**
 * 订单实体
 * 作者：ken
 */
@Data
@TableName("t_order")
publicclass Order {
    @TableId(type = IdType.AUTO)
    private Long id;
    private String orderNo;
    private BigDecimal amount;
    private String status;
    private String createUser;
    private LocalDateTime createTime;
}

// 订单Mapper
package com.jam.demo.mapper;

import com.baomidou.mybatisplus.core.mapper.BaseMapper;
import com.jam.demo.entity.Order;
import org.apache.ibatis.annotations.Mapper;

/**
 * 订单Mapper
 * 作者：ken
 */
@Mapper
publicinterface OrderMapper extends BaseMapper<Order> {
}

// 订单控制器
package com.jam.demo.controller;

import com.baomidou.mybatisplus.core.conditions.query.QueryWrapper;
import com.baomidou.mybatisplus.core.metadata.IPage;
import com.baomidou.mybatisplus.extension.plugins.pagination.Page;
import com.jam.demo.entity.Order;
import com.jam.demo.mapper.OrderMapper;
import io.swagger.v3.oas.annotations.Operation;
import io.swagger.v3.oas.annotations.security.SecurityRequirement;
import io.swagger.v3.oas.annotations.tags.Tag;
import lombok.RequiredArgsConstructor;
import lombok.extern.slf4j.Slf4j;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RequestParam;
import org.springframework.web.bind.annotation.RestController;

/**
 * 订单控制器
 * 作者：ken
 */
@RestController
@RequestMapping("/api/orders")
@RequiredArgsConstructor
@Slf4j
@Tag(name = "订单接口", description = "订单管理相关接口")
@SecurityRequirement(name = "ApiKeyAuth")
publicclass OrderController {

    privatefinal OrderMapper orderMapper;

    @GetMapping
    @Operation(summary = "分页查询订单", description = "根据条件分页查询订单（自动过滤数据权限）")
    public IPage<Order> getOrders(
            @RequestParam(defaultValue = "1") Integer pageNum,
            @RequestParam(defaultValue = "10") Integer pageSize) {

        Page<Order> page = new Page<>(pageNum, pageSize);
        QueryWrapper<Order> queryWrapper = new QueryWrapper<>();
        queryWrapper.eq("status", "PAID");

        return orderMapper.selectPage(page, queryWrapper);
    }
}

# application.yml
server:
  port: 8443
  ssl:
    key-store: classpath:keystore.p12
    key-store-password: password123
    key-store-type: PKCS12
    key-alias: api-server

// 添加加密依赖
<dependency>
    <groupId>org.bouncycastle</groupId>
    <artifactId>bcprov-jdk18on</artifactId>
    <version>1.77</version>
</dependency>

// 加密工具类
package com.jam.demo.util;

import lombok.extern.slf4j.Slf4j;
import org.bouncycastle.jce.provider.BouncyCastleProvider;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.stereotype.Component;
import org.springframework.util.StringUtils;

import javax.crypto.Cipher;
import javax.crypto.spec.IvParameterSpec;
import javax.crypto.spec.SecretKeySpec;
import java.nio.charset.StandardCharsets;
import java.security.Security;
import java.util.Base64;

/**
 * AES加密工具类
 * 作者：ken
 */
@Component
@Slf4j
publicclass AesEncryptUtil {

    static {
        Security.addProvider(new BouncyCastleProvider());
    }

    @Value("${encrypt.aes.key}")
    private String aesKey;

    @Value("${encrypt.aes.iv}")
    private String aesIv;

    /**
     * AES加密
     * @param content 待加密内容
     * @return 加密后的Base64字符串
     */
    public String encrypt(String content) {
        if (!StringUtils.hasText(content)) {
            return content;
        }

        try {
            Cipher cipher = Cipher.getInstance("AES/CBC/PKCS7Padding");
            SecretKeySpec keySpec = new SecretKeySpec(aesKey.getBytes(), "AES");
            IvParameterSpec ivSpec = new IvParameterSpec(aesIv.getBytes());

            cipher.init(Cipher.ENCRYPT_MODE, keySpec, ivSpec);
            byte[] encrypted = cipher.doFinal(content.getBytes(StandardCharsets.UTF_8));

            return Base64.getEncoder().encodeToString(encrypted);
        } catch (Exception e) {
            log.error("AES加密失败", e);
            thrownew RuntimeException("加密失败");
        }
    }

    /**
     * AES解密
     * @param encryptedContent 加密后的Base64字符串
     * @return 解密后的内容
     */
    public String decrypt(String encryptedContent) {
        if (!StringUtils.hasText(encryptedContent)) {
            return encryptedContent;
        }

        try {
            Cipher cipher = Cipher.getInstance("AES/CBC/PKCS7Padding");
            SecretKeySpec keySpec = new SecretKeySpec(aesKey.getBytes(), "AES");
            IvParameterSpec ivSpec = new IvParameterSpec(aesIv.getBytes());

            cipher.init(Cipher.DECRYPT_MODE, keySpec, ivSpec);
            byte[] decoded = Base64.getDecoder().decode(encryptedContent);
            byte[] decrypted = cipher.doFinal(decoded);

            returnnew String(decrypted, StandardCharsets.UTF_8);
        } catch (Exception e) {
            log.error("AES解密失败", e);
            thrownew RuntimeException("解密失败");
        }
    }
}

// 用户DTO
package com.jam.demo.dto;

import io.swagger.v3.oas.annotations.media.Schema;
import lombok.Data;

/**
 * 用户DTO
 * 作者：ken
 */
@Data
publicclass UserDTO {
    @Schema(description = "用户ID")
    private Long id;

    @Schema(description = "用户名")
    private String username;

    @Schema(description = "手机号（加密）")
    private String phone;

    @Schema(description = "身份证号（加密）")
    private String idCard;
}

// 用户服务
package com.jam.demo.service;

import com.jam.demo.dto.UserDTO;
import com.jam.demo.util.AesEncryptUtil;
import lombok.RequiredArgsConstructor;
import lombok.extern.slf4j.Slf4j;
import org.springframework.stereotype.Service;

/**
 * 用户服务
 * 作者：ken
 */
@Service
@RequiredArgsConstructor
@Slf4j
publicclass UserService {

    privatefinal AesEncryptUtil aesEncryptUtil;

    /**
     * 获取用户详情（敏感数据加密）
     * @param userId 用户ID
     * @return 用户详情
     */
    public UserDTO getUserById(Long userId) {
        // 模拟从数据库查询
        UserDTO userDTO = new UserDTO();
        userDTO.setId(userId);
        userDTO.setUsername("testuser");

        // 敏感数据加密
        String phone = "13800138000";
        String idCard = "110101199001011234";

        userDTO.setPhone(aesEncryptUtil.encrypt(phone));
        userDTO.setIdCard(aesEncryptUtil.encrypt(idCard));

        return userDTO;
    }

    /**
     * 解密敏感数据
     * @param userDTO 用户DTO
     * @return 解密后的用户DTO
     */
    public UserDTO decryptUserSensitiveData(UserDTO userDTO) {
        userDTO.setPhone(aesEncryptUtil.decrypt(userDTO.getPhone()));
        userDTO.setIdCard(aesEncryptUtil.decrypt(userDTO.getIdCard()));
        return userDTO;
    }
}

// 添加Redis依赖
<dependency>
    <groupId>org.springframework.boot</groupId>
    <artifactId>spring-boot-starter-data-redis</artifactId>
    <version>3.2.0</version>
</dependency>

// 限流注解
package com.jam.demo.annotation;

import java.lang.annotation.ElementType;
import java.lang.annotation.Retention;
import java.lang.annotation.RetentionPolicy;
import java.lang.annotation.Target;

/**
 * 限流注解
 * 作者：ken
 */
@Target({ElementType.METHOD})
@Retention(RetentionPolicy.RUNTIME)
public@interface RateLimit {
    /**
     * 限流key前缀
     */
    String prefix() default "rate_limit:";

    /**
     * 限流时间窗口（秒）
     */
    int period() default 60;

    /**
     * 时间窗口内最大请求数
     */
    int count() default 100;

    /**
     * 是否按IP限流
     */
    boolean byIp() default true;
}

// 限流切面
package com.jam.demo.aspect;

import com.jam.demo.annotation.RateLimit;
import jakarta.servlet.http.HttpServletRequest;
import lombok.RequiredArgsConstructor;
import lombok.extern.slf4j.Slf4j;
import org.aspectj.lang.ProceedingJoinPoint;
import org.aspectj.lang.annotation.Around;
import org.aspectj.lang.annotation.Aspect;
import org.aspectj.lang.reflect.MethodSignature;
import org.springframework.data.redis.core.StringRedisTemplate;
import org.springframework.data.redis.core.script.DefaultRedisScript;
import org.springframework.stereotype.Component;
import org.springframework.web.context.request.RequestContextHolder;
import org.springframework.web.context.request.ServletRequestAttributes;

import java.lang.reflect.Method;
import java.util.Collections;
import java.util.List;

/**
 * 限流切面
 * 作者：ken
 */
@Aspect
@Component
@RequiredArgsConstructor
@Slf4j
publicclass RateLimitAspect {

    privatefinal StringRedisTemplate stringRedisTemplate;

    privatestaticfinal String RATE_LIMIT_LUA_SCRIPT =
        "local key = KEYS[1]\n" +
        "local count = tonumber(ARGV[1])\n" +
        "local period = tonumber(ARGV[2])\n" +
        "local current = tonumber(redis.call('get', key) or '0')\n" +
        "if current + 1 > count then\n" +
        "    return 0\n" +
        "else\n" +
        "    redis.call('incr', key)\n" +
        "    if current == 0 then\n" +
        "        redis.call('expire', key, period)\n" +
        "    end\n" +
        "    return 1\n" +
        "end";

    privatefinal DefaultRedisScript<Long> rateLimitScript = new DefaultRedisScript<>(
        RATE_LIMIT_LUA_SCRIPT, Long.class
    );

    @Around("@annotation(com.jam.demo.annotation.RateLimit)")
    public Object around(ProceedingJoinPoint joinPoint) throws Throwable {
        // 获取注解信息
        MethodSignature signature = (MethodSignature) joinPoint.getSignature();
        Method method = signature.getMethod();
        RateLimit rateLimit = method.getAnnotation(RateLimit.class);

        // 构建限流key
        String key = rateLimit.prefix() + method.getName();
        if (rateLimit.byIp()) {
            HttpServletRequest request = ((ServletRequestAttributes) RequestContextHolder.getRequestAttributes()).getRequest();
            String ip = getClientIp(request);
            key += ":" + ip;
        }

        // 执行Lua脚本
        List<String> keys = Collections.singletonList(key);
        Long result = stringRedisTemplate.execute(
            rateLimitScript,
            keys,
            String.valueOf(rateLimit.count()),
            String.valueOf(rateLimit.period())
        );

        if (result == null || result == 0) {
            log.warn("接口限流触发：{}，IP：{}", method.getName(), getClientIp(((ServletRequestAttributes) RequestContextHolder.getRequestAttributes()).getRequest()));
            thrownew RuntimeException("请求过于频繁，请稍后再试");
        }

        return joinPoint.proceed();
    }

    private String getClientIp(HttpServletRequest request) {
        String ip = request.getHeader("X-Forwarded-For");
        if (ip == null || ip.length() == 0 || "unknown".equalsIgnoreCase(ip)) {
            ip = request.getHeader("Proxy-Client-IP");
        }
        if (ip == null || ip.length() == 0 || "unknown".equalsIgnoreCase(ip)) {
            ip = request.getHeader("WL-Proxy-Client-IP");
        }
        if (ip == null || ip.length() == 0 || "unknown".equalsIgnoreCase(ip)) {
            ip = request.getRemoteAddr();
        }
        return ip;
    }
}

// 限流测试控制器
package com.jam.demo.controller;

import com.jam.demo.annotation.RateLimit;
import io.swagger.v3.oas.annotations.Operation;
import io.swagger.v3.oas.annotations.security.SecurityRequirement;
import io.swagger.v3.oas.annotations.tags.Tag;
import lombok.extern.slf4j.Slf4j;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RestController;

/**
 * 限流测试控制器
 * 作者：ken
 */
@RestController
@RequestMapping("/api/limit")
@Slf4j
@Tag(name = "限流测试接口", description = "接口限流测试相关接口")
@SecurityRequirement(name = "ApiKeyAuth")
publicclass RateLimitController {

    @GetMapping("/test")
    @Operation(summary = "限流测试接口", description = "每分钟最多10次请求")
    @RateLimit(period = 60, count = 10)
    public String testLimit() {
        return"请求成功";
    }
}

// 添加Gateway依赖
<dependency>
    <groupId>org.springframework.cloud</groupId>
    <artifactId>spring-cloud-starter-gateway</artifactId>
    <version>4.1.0</version>
</dependency>
<dependency>
    <groupId>org.springframework.cloud</groupId>
    <artifactId>spring-cloud-starter-circuitbreaker-reactor-resilience4j</artifactId>
    <version>4.1.0</version>
</dependency>

// Gateway安全过滤器
package com.jam.demo.gateway.filter;

import lombok.extern.slf4j.Slf4j;
import org.springframework.cloud.gateway.filter.GatewayFilterChain;
import org.springframework.cloud.gateway.filter.GlobalFilter;
import org.springframework.core.Ordered;
import org.springframework.http.server.reactive.ServerHttpRequest;
import org.springframework.stereotype.Component;
import org.springframework.util.StringUtils;
import org.springframework.web.server.ServerWebExchange;
import reactor.core.publisher.Mono;

/**
 * API网关认证过滤器
 * 作者：ken
 */
@Component
@Slf4j
publicclass GatewayAuthFilter implements GlobalFilter, Ordered {

    privatestaticfinal String API_KEY_HEADER = "X-API-Key";
    privatestaticfinal String VALID_API_KEY = "valid-api-key-123456";

    @Override
    public Mono<Void> filter(ServerWebExchange exchange, GatewayFilterChain chain) {
        ServerHttpRequest request = exchange.getRequest();
        String apiKey = request.getHeaders().getFirst(API_KEY_HEADER);

        if (!StringUtils.hasText(apiKey) || !VALID_API_KEY.equals(apiKey)) {
            exchange.getResponse().setStatusCode(org.springframework.http.HttpStatus.UNAUTHORIZED);
            return exchange.getResponse().setComplete();
        }

        return chain.filter(exchange);
    }

    @Override
    public int getOrder() {
        return -100; // 优先级高于其他过滤器
    }
}

// Gateway配置
package com.jam.demo.gateway.config;

import org.springframework.cloud.gateway.route.RouteLocator;
import org.springframework.cloud.gateway.route.builder.RouteLocatorBuilder;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;

/**
 * Gateway路由配置
 * 作者：ken
 */
@Configuration
publicclass GatewayConfig {

    @Bean
    public RouteLocator customRouteLocator(RouteLocatorBuilder builder) {
        return builder.routes()
                .route("service-test", r -> r.path("/api/**")
                        .filters(f -> f
                                .requestRateLimiter(c -> c
                                        .setRateLimiter(redisRateLimiter())
                                        .setKeyResolver(userKeyResolver()))
                                .circuitBreaker(c -> c.setName("service-test")))
                        .uri("lb://service-test"))
                .build();
    }
}

// 添加日志依赖
<dependency>
    <groupId>net.logstash.logback</groupId>
    <artifactId>logstash-logback-encoder</artifactId>
    <version>7.4</version>
</dependency>

// logback-spring.xml
<?xml version="1.0" encoding="UTF-8"?>
<configuration>
    <appender name="CONSOLE"class="ch.qos.logback.core.ConsoleAppender">
        <encoder class="net.logstash.logback.encoder.LogstashEncoder">
            <includeMdcKeyName>traceId</includeMdcKeyName>
            <includeMdcKeyName>userId</includeMdcKeyName>
            <includeMdcKeyName>api</includeMdcKeyName>
        </encoder>
    </appender>

    <root level="INFO">
        <appender-ref ref="CONSOLE" />
    </root>
</configuration>

// 日志切面
package com.jam.demo.aspect;

import lombok.extern.slf4j.Slf4j;
import org.aspectj.lang.ProceedingJoinPoint;
import org.aspectj.lang.annotation.Around;
import org.aspectj.lang.annotation.Aspect;
import org.aspectj.lang.reflect.MethodSignature;
import org.springframework.security.core.context.SecurityContextHolder;
import org.springframework.stereotype.Component;
import org.springframework.web.context.request.RequestContextHolder;
import org.springframework.web.context.request.ServletRequestAttributes;

import java.lang.reflect.Method;
import java.util.UUID;

/**
 * API日志切面
 * 作者：ken
 */
@Aspect
@Component
@Slf4j
publicclass ApiLogAspect {

    @Around("execution(* com.jam.demo.controller..*(..))")
    public Object around(ProceedingJoinPoint joinPoint) throws Throwable {
        // 设置Trace ID
        String traceId = UUID.randomUUID().toString().replace("-", "");
        org.slf4j.MDC.put("traceId", traceId);

        // 设置用户ID
        String username = SecurityContextHolder.getContext().getAuthentication().getName();
        org.slf4j.MDC.put("userId", username);

        // 获取API路径
        ServletRequestAttributes attributes = (ServletRequestAttributes) RequestContextHolder.getRequestAttributes();
        String apiPath = attributes.getRequest().getRequestURI();
        org.slf4j.MDC.put("api", apiPath);

        // 记录请求日志
        long startTime = System.currentTimeMillis();
        try {
            Object result = joinPoint.proceed();
            long costTime = System.currentTimeMillis() - startTime;
            log.info("API请求成功，耗时：{}ms", costTime);
            return result;
        } catch (Exception e) {
            long costTime = System.currentTimeMillis() - startTime;
            log.error("API请求失败，耗时：{}ms，异常：{}", costTime, e.getMessage(), e);
            throw e;
        } finally {
            org.slf4j.MDC.clear();
        }
    }
}
