介绍

https://github.com/cby-chen/Kubernetes 开源不易，帮忙点个star，谢谢了

kubernetes（k8s）二进制高可用安装部署，支持IPv4+IPv6双栈。

强烈建议在Github上查看文档 ！！！

Github出问题会更新文档，并且后续尽可能第一时间更新新版本文档 ！！！

手动项目地址：https://github.com/cby-chen/Kubernetes

1.环境

主机名称

IP地址

说明

软件

192.168.1.60

外网节点

下载各种所需安装包

Master01

192.168.1.31

master节点

kube-apiserver、kube-controller-manager、kube-scheduler、etcd、kubelet、kube-proxy、nfs-client、haproxy、keepalived、nginx

Master02

192.168.1.32

master节点

kube-apiserver、kube-controller-manager、kube-scheduler、etcd、kubelet、kube-proxy、nfs-client、haproxy、keepalived、nginx

Master03

192.168.1.33

master节点

kube-apiserver、kube-controller-manager、kube-scheduler、etcd、kubelet、kube-proxy、nfs-client、haproxy、keepalived、nginx

Node01

192.168.1.34

node节点

kubelet、kube-proxy、nfs-client、nginx

Node02

192.168.1.35

node节点

kubelet、kube-proxy、nfs-client、nginx

192.168.1.36

VIP

详细版本

软件

版本

cni_plugins_version

v1.9.1

cri_containerd_cni_version

2.3.0

crictl_version

v1.36.0

cri_dockerd_version

0.4.3

etcd_version

v3.6.11

cfssl_version

1.6.5

kubernetes_server_version

1.36.0

docker_version

29.4.3

runc_version

1.5.0

kernel_version

6.16.4

helm_version

4.1.4

nginx_version

1.30.0

网段

IPv4 物理主机：192.168.1.0/24 service：10.96.0.0/16 pod：172.16.0.0/16

IPv6 物理主机：fc00::/8 service：fd00:1111::/112 pod：fd00:2222::/112

安装包已经整理好：https://github.com/cby-chen/Kubernetes/releases/download/v1.36.0/kubernetes-v1.36.0.tar

1.1.k8s基础系统环境配置

1.2.配置IP

代码语言：javascript
复制
详见完整版 https://github.com/cby-chen/Kubernetes

1.3.设置主机名

代码语言：javascript
复制
hostnamectl set-hostname k8s-master01
hostnamectl set-hostname k8s-master02
hostnamectl set-hostname k8s-master03
hostnamectl set-hostname k8s-node01
hostnamectl set-hostname k8s-node02

# 参数解释
#
# 参数: set-hostname
# 解释: 这是hostnamectl命令的一个参数，用于设置系统的主机名。
#
# 参数: k8s-master01
# 解释: 这是要设置的主机名，将系统的主机名设置为"k8s-master01"。

1.4.配置yum源

代码语言：javascript
复制
详见完整版 https://github.com/cby-chen/Kubernetes

1.5.安装一些必备工具

代码语言：javascript
复制
# 对于 Ubuntu
apt update && apt upgrade -y && apt install -y wget psmisc vim net-tools nfs-kernel-server telnet lvm2 git tar curl

# 对于 CentOS 7 & CentOS 8 & CentOS 9 & CentOS 10
yum update -y && yum -y install wget psmisc vim net-tools nfs-utils telnet yum-utils device-mapper-persistent-data lvm2 git tar curl
1.5.1 下载离线所需文件(可选)

在互联网服务器上安装一个一模一样的系统进行下载所需包

CentOS7
代码语言：javascript
复制
详见完整版 https://github.com/cby-chen/Kubernetes
CentOS8
代码语言：javascript
复制
详见完整版 https://github.com/cby-chen/Kubernetes
CentOS9 & CentOS10
代码语言：javascript
复制
详见完整版 https://github.com/cby-chen/Kubernetes
Ubuntu 下载包和依赖
代码语言：javascript
复制
详见完整版 https://github.com/cby-chen/Kubernetes

1.6.选择性下载需要工具

代码语言：javascript
复制
#!/bin/bash

# 查看版本地址：
#
# https://github.com/containernetworking/plugins/releases/
# https://github.com/containerd/containerd/releases/
# https://github.com/kubernetes-sigs/cri-tools/releases/
# https://github.com/Mirantis/cri-dockerd/releases/
# https://github.com/etcd-io/etcd/releases/
# https://github.com/cloudflare/cfssl/releases/
# https://github.com/kubernetes/kubernetes/tree/master/CHANGELOG
# https://download.docker.com/linux/static/stable/x86_64/
# https://github.com/opencontainers/runc/releases/
# https://github.com/helm/helm/tags
# http://nginx.org/download/

# Version numbers
cni_plugins_version='v1.9.1'
cri_containerd_cni_version='2.3.0'
crictl_version='v1.36.0'
cri_dockerd_version='0.4.3'
etcd_version='v3.6.11'
cfssl_version='1.6.5'
kubernetes_server_version='1.36.0'
docker_version='29.4.3'
runc_version='1.5.0'
kernel_version='5.4.278'
helm_version='4.1.4'
nginx_version='1.30.0'

# URLs
base_url='https://github.com'
kernel_url="http://mirrors.tuna.tsinghua.edu.cn/elrepo/kernel/el7/x86_64/RPMS/kernel-lt-${kernel_version}-1.el7.elrepo.x86_64.rpm"
runc_url="${base_url}/opencontainers/runc/releases/download/v${runc_version}/runc.amd64"
docker_url="https://mirrors.ustc.edu.cn/docker-ce/linux/static/stable/x86_64/docker-${docker_version}.tgz"
cni_plugins_url="${base_url}/containernetworking/plugins/releases/download/${cni_plugins_version}/cni-plugins-linux-amd64-${cni_plugins_version}.tgz"
cri_containerd_cni_url="${base_url}/containerd/containerd/releases/download/v${cri_containerd_cni_version}/containerd-${cri_containerd_cni_version}-linux-amd64.tar.gz"
crictl_url="${base_url}/kubernetes-sigs/cri-tools/releases/download/${crictl_version}/crictl-${crictl_version}-linux-amd64.tar.gz"
cri_dockerd_url="${base_url}/Mirantis/cri-dockerd/releases/download/v${cri_dockerd_version}/cri-dockerd-${cri_dockerd_version}.amd64.tgz"
etcd_url="${base_url}/etcd-io/etcd/releases/download/${etcd_version}/etcd-${etcd_version}-linux-amd64.tar.gz"
cfssl_url="${base_url}/cloudflare/cfssl/releases/download/v${cfssl_version}/cfssl_${cfssl_version}_linux_amd64"
cfssljson_url="${base_url}/cloudflare/cfssl/releases/download/v${cfssl_version}/cfssljson_${cfssl_version}_linux_amd64"
helm_url="https://mirrors.huaweicloud.com/helm/v${helm_version}/helm-v${helm_version}-linux-amd64.tar.gz"
kubernetes_server_url="https://dl.k8s.io/v${kubernetes_server_version}/kubernetes-server-linux-amd64.tar.gz"
nginx_url="http://nginx.org/download/nginx-${nginx_version}.tar.gz"

# Download packages
packages=(
  # $kernel_url
  $runc_url
  $docker_url
  $cni_plugins_url
  $cri_containerd_cni_url
  $crictl_url
  $cri_dockerd_url
  $etcd_url
  $cfssl_url
  $cfssljson_url
  $helm_url
  $kubernetes_server_url
  $nginx_url
)

for package_url in "${packages[@]}"; do
  filename=$(basename "$package_url")
  if curl --parallel --parallel-immediate -k -L -C - -o "$filename" "$package_url"; then
    echo "Downloaded $filename"
  else
    echo "Failed to download $filename"
    exit 1
  fi
done

1.7.关闭防火墙

代码语言：javascript
复制
# Ubuntu忽略，CentOS执行
systemctl disable --now firewalld

1.8.关闭SELinux

代码语言：javascript
复制
# Ubuntu忽略，CentOS执行
setenforce 0
sed -i 's#SELINUX=enforcing#SELINUX=disabled#g' /etc/selinux/config

1.9.关闭交换分区

代码语言：javascript
复制
sed -ri 's/.*swap.*/#&/' /etc/fstab
swapoff -a && sysctl -w vm.swappiness=0

cat /etc/fstab
# /dev/mapper/centos-swap swap                    swap    defaults        0 0

1.10.网络配置（俩种方式二选一）

代码语言：javascript
复制
# Ubuntu忽略，CentOS执行，CentOS9不支持方式一

# 方式一
# systemctl disable --now NetworkManager
# systemctl start network && systemctl enable network

# 方式二
cat > /etc/NetworkManager/conf.d/calico.conf << EOF
[keyfile]
unmanaged-devices=interface-name:cali*;interface-name:tunl*;interface-name:vxlan*;interface-name:kube*
EOF
systemctl restart NetworkManager

1.11.进行时间同步

代码语言：javascript
复制
# 服务端
# apt install chrony -y
yum install chrony -y
cat > /etc/chrony.conf << EOF
pool ntp.aliyun.com iburst
driftfile /var/lib/chrony/drift
makestep 1.0 3
rtcsync
allow 192.168.1.0/24
local stratum 10
keyfile /etc/chrony.keys
leapsectz right/UTC
logdir /var/log/chrony
EOF

systemctl restart chronyd ; systemctl enable chronyd

# 客户端
# apt install chrony -y
yum install chrony -y
cat > /etc/chrony.conf << EOF
pool 192.168.1.31 iburst
driftfile /var/lib/chrony/drift
makestep 1.0 3
rtcsync
keyfile /etc/chrony.keys
leapsectz right/UTC
logdir /var/log/chrony
EOF

systemctl restart chronyd ; systemctl enable chronyd

#使用客户端进行验证
chronyc sources -v

1.12.配置ulimit

代码语言：javascript
复制
ulimit -SHn 65535
cat >> /etc/security/limits.conf <<EOF
* soft nofile 655360
* hard nofile 131072
* soft nproc 655350
* hard nproc 655350
* seft memlock unlimited
* hard memlock unlimitedd
EOF

1.13.配置免密登录

代码语言：javascript
复制
# apt install -y sshpass
yum install -y sshpass
ssh-keygen -f /root/.ssh/id_rsa -P ''
export IP="192.168.1.31 192.168.1.32 192.168.1.33 192.168.1.34 192.168.1.35"
export SSHPASS=123123
for HOST in $IP;do
     sshpass -e ssh-copy-id -o StrictHostKeyChecking=no $HOST
done

1.14.添加启用源

代码语言：javascript
复制
# Ubuntu忽略，CentOS执行

# 为 RHEL-10或 CentOS-10配置源
dnf install https://www.elrepo.org/elrepo-release-10.el10.elrepo.noarch.rpm -y
sed -i "s@mirrorlist@#mirrorlist@g" /etc/yum.repos.d/elrepo.repo
sed -i "s@elrepo.org/linux@mirrors.tuna.tsinghua.edu.cn/elrepo@g" /etc/yum.repos.d/elrepo.repo

# 为 RHEL-9或 CentOS-9配置源
dnf install https://www.elrepo.org/elrepo-release-9.el9.elrepo.noarch.rpm -y
sed -i "s@mirrorlist@#mirrorlist@g" /etc/yum.repos.d/elrepo.repo
sed -i "s@elrepo.org/linux@mirrors.tuna.tsinghua.edu.cn/elrepo@g" /etc/yum.repos.d/elrepo.repo

# 为 RHEL-8或 CentOS-8配置源
dnf install https://www.elrepo.org/elrepo-release-8.el8.elrepo.noarch.rpm -y
sed -i "s@mirrorlist@#mirrorlist@g" /etc/yum.repos.d/elrepo.repo
sed -i "s@elrepo.org/linux@mirrors.tuna.tsinghua.edu.cn/elrepo@g" /etc/yum.repos.d/elrepo.repo

# 为 RHEL-7 SL-7 或 CentOS-7 安装 ELRepo
yum install https://www.elrepo.org/elrepo-release-7.el7.elrepo.noarch.rpm -y
sed -i "s@mirrorlist@#mirrorlist@g" /etc/yum.repos.d/elrepo.repo
sed -i "s@elrepo.org/linux@mirrors.tuna.tsinghua.edu.cn/elrepo@g" /etc/yum.repos.d/elrepo.repo

# 查看可用安装包
yum  --disablerepo="*"  --enablerepo="elrepo-kernel"  list  available

1.15.升级内核至4.18版本以上（若内核版本不够执行升级）

代码语言：javascript
复制
# Ubuntu忽略，CentOS执行

# 安装最新的内核
# 我这里选择的是稳定版kernel-ml   如需更新长期维护版本kernel-lt
yum -y --enablerepo=elrepo-kernel  install  kernel-ml

# 查看已安装那些内核
rpm -qa | grep kernel

# 查看默认内核
grubby --default-kernel

# 若不是最新的使用命令设置
grubby --set-default $(ls /boot/vmlinuz-* | grep elrepo)

# 重启生效
reboot

# v8 整合命令为：
yum install https://www.elrepo.org/elrepo-release-9.el9.elrepo.noarch.rpm -y ; sed -i "s@mirrorlist@#mirrorlist@g" /etc/yum.repos.d/elrepo.repo ; sed -i "s@elrepo.org/linux@mirrors.tuna.tsinghua.edu.cn/elrepo@g" /etc/yum.repos.d/elrepo.repo ; yum  --disablerepo="*"  --enablerepo="elrepo-kernel"  list  available -y ; yum  --enablerepo=elrepo-kernel  install kernel-lt -y ; grubby --default-kernel ; reboot

# v8 整合命令为：
yum install https://www.elrepo.org/elrepo-release-8.el8.elrepo.noarch.rpm -y ; sed -i "s@mirrorlist@#mirrorlist@g" /etc/yum.repos.d/elrepo.repo ; sed -i "s@elrepo.org/linux@mirrors.tuna.tsinghua.edu.cn/elrepo@g" /etc/yum.repos.d/elrepo.repo ; yum  --disablerepo="*"  --enablerepo="elrepo-kernel"  list  available -y ; yum  --enablerepo=elrepo-kernel  install kernel-lt -y ; grubby --default-kernel ; reboot

# v7 整合命令为：
yum install https://www.elrepo.org/elrepo-release-7.el7.elrepo.noarch.rpm -y ; sed -i "s@mirrorlist@#mirrorlist@g" /etc/yum.repos.d/elrepo.repo ; sed -i "s@elrepo.org/linux@mirrors.tuna.tsinghua.edu.cn/elrepo@g" /etc/yum.repos.d/elrepo.repo ; yum  --disablerepo="*"  --enablerepo="elrepo-kernel"  list  available -y ; yum  --enablerepo=elrepo-kernel  install  kernel-lt -y ; grubby --set-default $(ls /boot/vmlinuz-* | grep elrepo) ; grubby --default-kernel ; reboot

# 离线版本
yum install -y /root/cby/kernel-lt-*-1.el7.elrepo.x86_64.rpm ; grubby --set-default $(ls /boot/vmlinuz-* | grep elrepo) ; grubby --default-kernel ; reboot

1.16.安装ipvsadm

代码语言：javascript
复制
# 对于CentOS7离线安装
# yum install /root/centos7/ipset-*.el7.x86_64.rpm /root/centos7/lm_sensors-libs-*.el7.x86_64.rpm  /root/centos7/ipset-libs-*.el7.x86_64.rpm /root/centos7/sysstat-*.el7_9.x86_64.rpm  /root/centos7/ipvsadm-*.el7.x86_64.rpm  -y

# 对于 Ubuntu
# apt install ipvsadm ipset sysstat conntrack -y

# 对于 CentOS
yum install ipvsadm ipset sysstat conntrack libseccomp -y
cat >> /etc/modules-load.d/ipvs.conf <<EOF
ip_vs
ip_vs_rr
ip_vs_wrr
ip_vs_sh
nf_conntrack
ip_tables
ip_set
xt_set
ipt_set
ipt_rpfilter
ipt_REJECT
ipip
EOF

systemctl restart systemd-modules-load.service

lsmod | grep -e ip_vs -e nf_conntrack
ip_vs_sh               16384  0
ip_vs_wrr              16384  0
ip_vs_rr               16384  0
ip_vs                 237568  6 ip_vs_rr,ip_vs_sh,ip_vs_wrr
nf_conntrack          217088  3 nf_nat,nft_ct,ip_vs
nf_defrag_ipv6         24576  2 nf_conntrack,ip_vs
nf_defrag_ipv4         16384  1 nf_conntrack
libcrc32c              16384  5 nf_conntrack,nf_nat,nf_tables,xfs,ip_vs

1.17.修改内核参数

代码语言：javascript
复制
cat <<EOF > /etc/sysctl.d/k8s.conf
net.ipv4.ip_forward = 1
net.bridge.bridge-nf-call-iptables = 1
fs.may_detach_mounts = 1
vm.overcommit_memory=1
vm.panic_on_oom=0
fs.inotify.max_user_watches=89100
fs.file-max=52706963
fs.nr_open=52706963
net.netfilter.nf_conntrack_max=2310720

net.ipv4.tcp_keepalive_time = 600
net.ipv4.tcp_keepalive_probes = 3
net.ipv4.tcp_keepalive_intvl =15
net.ipv4.tcp_max_tw_buckets = 36000
net.ipv4.tcp_tw_reuse = 1
net.ipv4.tcp_max_orphans = 327680
net.ipv4.tcp_orphan_retries = 3
net.ipv4.tcp_syncookies = 1
net.ipv4.tcp_max_syn_backlog = 16384
net.ipv4.ip_conntrack_max = 65536
net.ipv4.tcp_max_syn_backlog = 16384
net.ipv4.tcp_timestamps = 0
net.core.somaxconn = 16384

net.ipv6.conf.all.disable_ipv6 = 0
net.ipv6.conf.default.disable_ipv6 = 0
net.ipv6.conf.lo.disable_ipv6 = 0
net.ipv6.conf.all.forwarding = 1
EOF

sysctl --system

1.18.所有节点配置hosts本地解析

代码语言：javascript
复制
cat > /etc/hosts <<EOF
127.0.0.1   localhost localhost.localdomain localhost4 localhost4.localdomain4
::1         localhost localhost.localdomain localhost6 localhost6.localdomain6

192.168.1.31 k8s-master01
192.168.1.32 k8s-master02
192.168.1.33 k8s-master03
192.168.1.34 k8s-node01
192.168.1.35 k8s-node02
192.168.1.36 lb-vip

fc00::31 k8s-master01
fc00::32 k8s-master02
fc00::33 k8s-master03
fc00::34 k8s-node01
fc00::35 k8s-node02
EOF

2.k8s基本组件安装

注意 ： 2.1 和 2.2 二选其一即可

说明：使用docker作为Runtime会出现报错，无法进入容器内部，该问题的是cri-dockerd不兼容导致的，同时官方已经弃用docker，建议使用Containerd作为Runtime，例如：

代码语言：javascript
复制
# docker作为Runtime

[root@k8s-master01 ~]# kubectl exec -ti busybox -- sh
Defaulted container "busybox" out of: busybox, debugger-8sq56 (ephem)
error: Internal error occurred: error sending request: Post "//[::]:39823/cri/exec/JBk5X7Cx": http: server gave HTTP response to HTTPS client
[root@k8s-master01 ~]#

# Containerd作为Runtime

[root@k8s-master01 ~]# kubectl exec -ti busybox -- sh
Defaulted container "busybox" out of: busybox, debugger-8sq56 (ephem)
/ #
/ #
[root@k8s-master01 ~]#

2.1.安装Containerd作为Runtime

代码语言：javascript
复制
# https://github.com/containernetworking/plugins/releases/
# wget https://github.com/containernetworking/plugins/releases/download/v1.7.1/cni-plugins-linux-amd64-v1.7.1.tgz

cd cby/

#创建cni插件所需目录
mkdir -p /etc/cni/net.d /opt/cni/bin
#解压cni二进制包
tar xf cni-plugins-linux-amd64-v*.tgz -C /opt/cni/bin/

# https://github.com/containerd/containerd/releases/
# wget https://github.com/containerd/containerd/releases/download/v2.0.5/containerd-2.0.5-linux-amd64.tar.gz

#解压
tar -xzf containerd-*-linux-amd64.tar.gz -C /usr/local/

#创建服务启动文件
cat > /etc/systemd/system/containerd.service <<EOF
[Unit]
Description=containerd container runtime
Documentation=https://containerd.io
After=network.target local-fs.target

[Service]
ExecStartPre=-/sbin/modprobe overlay
ExecStart=/usr/local/bin/containerd
Type=notify
Delegate=yes
KillMode=process
Restart=always
RestartSec=5
LimitNPROC=infinity
LimitCORE=infinity
LimitNOFILE=infinity
TasksMax=infinity
OOMScoreAdjust=-999

[Install]
WantedBy=multi-user.target
EOF

2.1.1配置Containerd所需的模块

代码语言：javascript
复制
cat <<EOF | sudo tee /etc/modules-load.d/containerd.conf
overlay
br_netfilter
EOF

2.1.2加载模块

代码语言：javascript
复制
systemctl restart systemd-modules-load.service

2.1.3配置Containerd所需的内核

代码语言：javascript
复制
cat <<EOF | sudo tee /etc/sysctl.d/99-kubernetes-cri.conf
net.bridge.bridge-nf-call-iptables  = 1
net.ipv4.ip_forward                 = 1
net.bridge.bridge-nf-call-ip6tables = 1
EOF

# 加载内核
sysctl --system

2.1.4创建Containerd的配置文件

代码语言：javascript
复制
# 创建默认配置文件
mkdir -p /etc/containerd
containerd config default | tee /etc/containerd/config.toml

# 修改Containerd的配置文件

# sed -i "s#SystemdCgroup\ \=\ false#SystemdCgroup\ \=\ true#g" /etc/containerd/config.toml
# cat /etc/containerd/config.toml | grep SystemdCgroup

# 沙箱pause镜像
sed -i "s#registry.k8s.io#registry.aliyuncs.com/chenby#g" /etc/containerd/config.toml
cat /etc/containerd/config.toml | grep sandbox

# 配置加速器
[root@k8s-master01 ~]# vim /etc/containerd/config.toml
[root@k8s-master01 ~]# cat /etc/containerd/config.toml | grep certs.d -C 5

    [plugins.'io.containerd.cri.v1.images'.pinned_images]
      sandbox = 'registry.aliyuncs.com/chenby/pause:3.10'

    [plugins.'io.containerd.cri.v1.images'.registry]
      config_path = '/etc/containerd/certs.d'

    [plugins.'io.containerd.cri.v1.images'.image_decryption]
      key_model = 'node'

  [plugins.'io.containerd.cri.v1.runtime']
[root@k8s-master01 ~]#


mkdir /etc/containerd/certs.d/docker.io -pv
cat > /etc/containerd/certs.d/docker.io/hosts.toml << EOF
server = "https://docker.io"
[host."https://jockerhub.com"]
  capabilities = ["pull", "resolve"]
EOF

# 配置 GFW 代理
mkdir -p /etc/systemd/system/containerd.service.d
touch /etc/systemd/system/containerd.service.d/http-proxy.conf
tee /etc/systemd/system/containerd.service.d/http-proxy.conf << EOF
[Service]
Environment="HTTP_PROXY=http://192.168.1.100:7890"
Environment="HTTPS_PROXY=http://192.168.1.100:7890"
Environment="NO_PROXY=localhost,127.0.0.1,containerd"
EOF

2.1.5启动并设置为开机启动

代码语言：javascript
复制
systemctl daemon-reload
systemctl enable --now containerd.service
systemctl stop containerd.service
systemctl start containerd.service
systemctl restart containerd.service
systemctl status containerd.service

2.1.6配置crictl客户端连接的运行时位置

代码语言：javascript
复制
# https://github.com/kubernetes-sigs/cri-tools/releases/
# wget https://github.com/kubernetes-sigs/cri-tools/releases/download/v1.36.0/crictl-v1.36.0-linux-amd64.tar.gz

#解压
tar xf crictl-v*-linux-amd64.tar.gz -C /usr/bin/
#生成配置文件
cat > /etc/crictl.yaml <<EOF
runtime-endpoint: unix:///run/containerd/containerd.sock
image-endpoint: unix:///run/containerd/containerd.sock
timeout: 10
debug: false
EOF

#测试
systemctl restart  containerd
crictl info

2.2 安装docker作为Runtime

2.2.1 解压docker程序

代码语言：javascript
复制
# 二进制包下载地址：https://download.docker.com/linux/static/stable/x86_64/
# wget https://mirrors.ustc.edu.cn/docker-ce/linux/static/stable/x86_64/docker-27.4.0.tgz

#解压
tar xf docker-*.tgz
#拷贝二进制文件
cp docker/* /usr/bin/

2.2.2 创建containerd的service文件

代码语言：javascript
复制
#创建containerd的service文件,并且启动
cat >/etc/systemd/system/containerd.service <<EOF
[Unit]
Description=containerd container runtime
Documentation=https://containerd.io
After=network.target local-fs.target

[Service]
ExecStartPre=-/sbin/modprobe overlay
ExecStart=/usr/bin/containerd
Type=notify
Delegate=yes
KillMode=process
Restart=always
RestartSec=5
LimitNPROC=infinity
LimitCORE=infinity
LimitNOFILE=1048576
TasksMax=infinity
OOMScoreAdjust=-999

[Install]
WantedBy=multi-user.target
EOF

# 设置开机自启
systemctl enable --now containerd.service

2.2.3 准备docker的service文件

代码语言：javascript
复制
#准备docker的service文件
cat > /etc/systemd/system/docker.service <<EOF
[Unit]
Description=Docker Application Container Engine
Documentation=https://docs.docker.com
After=network-online.target firewalld.service containerd.service
Wants=network-online.target
Requires=containerd.service

[Service]
Type=notify
ExecStart=/usr/bin/dockerd -H fd:// --containerd=/run/containerd/containerd.sock
ExecReload=/bin/kill -s HUP $MAINPID
TimeoutSec=0
RestartSec=2
Restart=always
StartLimitBurst=3
StartLimitInterval=60s
LimitNOFILE=infinity
LimitNPROC=infinity
LimitCORE=infinity
TasksMax=infinity
Delegate=yes
KillMode=process
OOMScoreAdjust=-500

[Install]
WantedBy=multi-user.target
EOF

2.2.4 准备docker的socket文件

代码语言：javascript
复制
#准备docker的socket文件
cat > /etc/systemd/system/docker.socket <<EOF
[Unit]
Description=Docker Socket for the API

[Socket]
ListenStream=/var/run/docker.sock
SocketMode=0660
SocketUser=root
SocketGroup=docker

[Install]
WantedBy=sockets.target
EOF

2.2.5 配置加速器

代码语言：javascript
复制
# 配置加速器
mkdir /etc/docker/ -pv
cat >/etc/docker/daemon.json <<EOF
{
  "exec-opts": ["native.cgroupdriver=systemd"],
  "registry-mirrors": [
    "https://jockerhub.com"
  ],
  "max-concurrent-downloads": 10,
  "log-driver": "json-file",
  "log-level": "warn",
  "log-opts": {
    "max-size": "10m",
    "max-file": "3"
    },
  "data-root": "/var/lib/docker",
  "proxies": {
    "http-proxy": "http://192.168.1.100:7890",
    "https-proxy": "http://192.168.1.100:7890",
    "no-proxy": "localhost"
  }
}
EOF

2.2.6 启动docker

代码语言：javascript
复制
groupadd docker
systemctl daemon-reload
systemctl enable --now docker.service
systemctl enable --now docker.socket
systemctl stop docker.service
systemctl start docker.service
systemctl restart docker.service
systemctl status docker.service
docker info

2.2.7 解压cri-docker

代码语言：javascript
复制
# 由于1.24以及更高版本不支持docker所以安装cri-docker
# 下载cri-docker
# https://github.com/Mirantis/cri-dockerd/releases/
# wget  https://github.com/Mirantis/cri-dockerd/releases/download/v0.3.16/cri-dockerd-0.3.16.amd64.tgz

# 解压cri-docker
tar xvf cri-dockerd-*.amd64.tgz
cp -r cri-dockerd/  /usr/bin/
chmod +x /usr/bin/cri-dockerd/cri-dockerd

2.2.8 写入启动cri-docker配置文件

代码语言：javascript
复制
# 写入启动配置文件
cat >  /usr/lib/systemd/system/cri-docker.service <<EOF
[Unit]
Description=CRI Interface for Docker Application Container Engine
Documentation=https://docs.mirantis.com
After=network-online.target firewalld.service docker.service
Wants=network-online.target
Requires=cri-docker.socket

[Service]
Type=notify
ExecStart=/usr/bin/cri-dockerd/cri-dockerd --ipv6-dual-stack --network-plugin=cni --pod-infra-container-image=registry.aliyuncs.com/google_containers/pause:3.10
ExecReload=/bin/kill -s HUP $MAINPID
TimeoutSec=0
RestartSec=2
Restart=always

# 关键配置：允许 Socket 激活
StartLimitBurst=3

# 资源限制
LimitNOFILE=infinity
LimitNPROC=infinity
LimitCORE=infinity
TasksMax=infinity
Delegate=yes
KillMode=process

[Install]
WantedBy=multi-user.target
EOF

2.2.9 写入cri-docker的socket配置文件

代码语言：javascript
复制
# 写入socket配置文件
cat > /usr/lib/systemd/system/cri-docker.socket <<EOF
[Unit]
Description=CRI Docker Socket for the API
PartOf=cri-docker.service

[Socket]
ListenStream=/var/run/cri-dockerd.sock
SocketMode=0660
SocketUser=root
SocketGroup=docker

[Install]
WantedBy=sockets.target
EOF

2.2.10 启动cri-docker

代码语言：javascript
复制
systemctl daemon-reload
systemctl enable --now cri-docker.socket
systemctl restart cri-docker.socket
systemctl restart cri-docker.service
systemctl status cri-docker.socket
systemctl status cri-docker.service
systemctl stop cri-docker.socket
systemctl stop cri-docker.service

2.3.k8s与etcd下载及安装（仅在master01操作）

2.3.1解压k8s安装包

代码语言：javascript
复制
# 下载安装包
# https://github.com/etcd-io/etcd/releases/
# https://github.com/kubernetes/kubernetes/tree/master/CHANGELOG
#
# wget https://github.com/etcd-io/etcd/releases/download/v3.5.21/etcd-v3.5.21-linux-amd64.tar.gz
# wget https://cdn.dl.k8s.io/release/v1.36.0/kubernetes-server-linux-amd64.tar.gz

# 解压k8s安装文件
cd cby
tar -xf kubernetes-server-linux-amd64.tar.gz  --strip-components=3 -C /usr/local/bin kubernetes/server/bin/kube{let,ctl,-apiserver,-controller-manager,-scheduler,-proxy}

# 解压etcd安装文件
tar -xf etcd*.tar.gz && mv etcd-*/etcd /usr/local/bin/ && mv etcd-*/etcdctl /usr/local/bin/

# 查看/usr/local/bin下内容
[root@localhost cby]# ll /usr/local/bin/
总计 510444
-rwxr-xr-x. 1 root root 48051624  4月15日 01:36 containerd
-rwxr-xr-x. 1 root root  8339640  4月15日 01:36 containerd-shim-runc-v2
-rwxr-xr-x. 1 root root 21758305  4月15日 01:36 containerd-stress
-rwxr-xr-x. 1 root root 24961377  4月15日 01:36 ctr
-rwxr-xr-x. 1 1000 1000 26607800  4月 2日 02:30 etcd
-rwxr-xr-x. 1 1000 1000 17469624  4月 2日 02:30 etcdctl
-rwxr-xr-x. 1 root root 88309922  4月22日 21:59 kube-apiserver
-rwxr-xr-x. 1 root root 74285218  4月22日 21:59 kube-controller-manager
-rwxr-xr-x. 1 root root 59502754  4月22日 21:59 kubectl
-rwxr-xr-x. 1 root root 60064009  4月22日 21:59 kubelet
-rwxr-xr-x. 1 root root 44200098  4月22日 21:59 kube-proxy
-rwxr-xr-x. 1 root root 49098914  4月22日 21:59 kube-scheduler
[root@localhost cby]#

2.3.2查看版本

代码语言：javascript
复制
[root@k8s-master01 ~]#  kubelet --version
Kubernetes v1.36.0
[root@k8s-master01 ~]# etcdctl version
etcdctl version: 3.6.11
API version: 3.6
[root@k8s-master01 ~]#

2.3.3将组件发送至其他k8s节点

代码语言：javascript
复制
Master='k8s-master02 k8s-master03'
Work='k8s-node01 k8s-node02'

# 拷贝master组件
for NODE in $Master; do echo $NODE; scp /usr/local/bin/kube{let,ctl,-apiserver,-controller-manager,-scheduler,-proxy} $NODE:/usr/local/bin/; scp /usr/local/bin/etcd* $NODE:/usr/local/bin/; done

# 拷贝work组件
for NODE in $Work; do echo $NODE; scp /usr/local/bin/kube{let,-proxy} $NODE:/usr/local/bin/ ; done

# 所有节点执行
mkdir -p /opt/cni/bin

2.3创建证书相关文件

代码语言：javascript
复制
# 请查看Github仓库 或者进行获取已经打好的包
# 可以根据下文3.x进行手动部署操作
https://github.com/cby-chen/Kubernetes/
https://github.com/cby-chen/Kubernetes/tags
https://github.com/cby-chen/Kubernetes/releases/download/v1.36.0/kubernetes-v1.36.0.tar

3.相关证书生成

代码语言：javascript
复制
# master01节点下载证书生成工具
# wget "https://github.com/cloudflare/cfssl/releases/download/v1.6.5/cfssl_1.6.5_linux_amd64" -O /usr/local/bin/cfssl
# wget "https://github.com/cloudflare/cfssl/releases/download/v1.6.5/cfssljson_1.6.5_linux_amd64" -O /usr/local/bin/cfssljson

# 软件包内有
cp cfssl_*_linux_amd64 /usr/local/bin/cfssl
cp cfssljson_*_linux_amd64 /usr/local/bin/cfssljson

# 添加执行权限
chmod +x /usr/local/bin/cfssl /usr/local/bin/cfssljson

3.1.生成etcd证书

特别说明除外，以下操作在所有master节点操作

3.1.1所有master节点创建证书存放目录

代码语言：javascript
复制
mkdir /etc/etcd/ssl -p

3.1.2master01节点生成etcd证书

代码语言：javascript
复制
# 写入生成证书所需的配置文件
cat > ca-config.json << EOF
{
  "signing": {
    "default": {
      "expiry": "876000h"
    },
    "profiles": {
      "kubernetes": {
        "usages": [
            "signing",
            "key encipherment",
            "server auth",
            "client auth"
        ],
        "expiry": "876000h"
      }
    }
  }
}
EOF

cat > etcd-ca-csr.json  << EOF
{
  "CN": "etcd",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "ST": "Beijing",
      "L": "Beijing",
      "O": "etcd",
      "OU": "Etcd Security"
    }
  ],
  "ca": {
    "expiry": "876000h"
  }
}
EOF
# 生成etcd证书和etcd证书的key（如果你觉得以后可能会扩容，可以在ip那多写几个预留出来）
# 若没有IPv6 可删除可保留

cfssl gencert -initca etcd-ca-csr.json | cfssljson -bare /etc/etcd/ssl/etcd-ca

cat > etcd-csr.json << EOF
{
  "CN": "etcd",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "ST": "Beijing",
      "L": "Beijing",
      "O": "etcd",
      "OU": "Etcd Security"
    }
  ]
}
EOF


cfssl gencert \
   -ca=/etc/etcd/ssl/etcd-ca.pem \
   -ca-key=/etc/etcd/ssl/etcd-ca-key.pem \
   -config=ca-config.json \
   -hostname=127.0.0.1,k8s-master01,k8s-master02,k8s-master03,192.168.1.31,192.168.1.32,192.168.1.33,::1 \
   -profile=kubernetes \
   etcd-csr.json | cfssljson -bare /etc/etcd/ssl/etcd

3.1.3将证书复制到其他节点

代码语言：javascript
复制
Master='k8s-master02 k8s-master03'
for NODE in $Master; do ssh $NODE "mkdir -p /etc/etcd/ssl"; for FILE in etcd-ca-key.pem  etcd-ca.pem  etcd-key.pem  etcd.pem; do scp /etc/etcd/ssl/${FILE} $NODE:/etc/etcd/ssl/${FILE}; done; done

3.2.生成k8s相关证书

特别说明除外，以下操作在所有master节点操作

3.2.1 所有k8s节点创建证书存放目录

代码语言：javascript
复制
mkdir -p /etc/kubernetes/pki

3.2.2 master01节点生成k8s证书

代码语言：javascript
复制
# 写入生成证书所需的配置文件
cat > ca-csr.json   << EOF
{
  "CN": "kubernetes",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "ST": "Beijing",
      "L": "Beijing",
      "O": "Kubernetes",
      "OU": "Kubernetes-manual"
    }
  ],
  "ca": {
    "expiry": "876000h"
  }
}
EOF


cfssl gencert -initca ca-csr.json | cfssljson -bare /etc/kubernetes/pki/ca

cat > apiserver-csr.json << EOF
{
  "CN": "kube-apiserver",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "ST": "Beijing",
      "L": "Beijing",
      "O": "Kubernetes",
      "OU": "Kubernetes-manual"
    }
  ]
}
EOF

# 生成一个根证书 ，多写了一些IP作为预留IP，为将来添加node做准备
# 10.96.0.1是service网段的第一个地址，需要计算，192.168.1.36为高可用vip地址
# 若没有IPv6 可删除可保留

cfssl gencert   \
-ca=/etc/kubernetes/pki/ca.pem   \
-ca-key=/etc/kubernetes/pki/ca-key.pem   \
-config=ca-config.json   \
-hostname=10.96.0.1,192.168.1.36,127.0.0.1,kubernetes,kubernetes.default,kubernetes.default.svc,kubernetes.default.svc.cluster,kubernetes.default.svc.cluster.local,x.oiox.cn,z.oiox.cn,192.168.1.31,192.168.1.32,192.168.1.33,192.168.1.34,192.168.1.35,192.168.1.36,192.168.1.37,192.168.1.38,192.168.1.39,192.168.1.40,::1   \
-profile=kubernetes   apiserver-csr.json | cfssljson -bare /etc/kubernetes/pki/apiserver

3.2.3 生成apiserver聚合证书

代码语言：javascript
复制
cat > front-proxy-ca-csr.json  << EOF
{
  "CN": "kubernetes",
  "key": {
     "algo": "rsa",
     "size": 2048
  },
  "ca": {
    "expiry": "876000h"
  }
}
EOF

cfssl gencert   -initca front-proxy-ca-csr.json | cfssljson -bare /etc/kubernetes/pki/front-proxy-ca

cat > front-proxy-client-csr.json  << EOF
{
  "CN": "front-proxy-client",
  "key": {
     "algo": "rsa",
     "size": 2048
  }
}
EOF

cfssl gencert  \
-ca=/etc/kubernetes/pki/front-proxy-ca.pem   \
-ca-key=/etc/kubernetes/pki/front-proxy-ca-key.pem   \
-config=ca-config.json   \
-profile=kubernetes   front-proxy-client-csr.json | cfssljson -bare /etc/kubernetes/pki/front-proxy-client

3.2.4 生成controller-manage的证书

在《5.高可用配置》选择使用那种高可用方案 若使用 haproxy、keepalived 那么为 --server=https://192.168.1.36:9443 若使用 nginx方案，那么为 --server=https://127.0.0.1:8443

代码语言：javascript
复制
cat > manager-csr.json << EOF
{
  "CN": "system:kube-controller-manager",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "ST": "Beijing",
      "L": "Beijing",
      "O": "system:kube-controller-manager",
      "OU": "Kubernetes-manual"
    }
  ]
}
EOF


cfssl gencert \
   -ca=/etc/kubernetes/pki/ca.pem \
   -ca-key=/etc/kubernetes/pki/ca-key.pem \
   -config=ca-config.json \
   -profile=kubernetes \
   manager-csr.json | cfssljson -bare /etc/kubernetes/pki/controller-manager


# 设置一个集群项
# 在《5.高可用配置》选择使用那种高可用方案
# 若使用 haproxy、keepalived 那么为 `--server=https://192.168.1.36:9443`
# 若使用 nginx方案，那么为 `--server=https://127.0.0.1:8443`
kubectl config set-cluster kubernetes \
     --certificate-authority=/etc/kubernetes/pki/ca.pem \
     --embed-certs=true \
     --server=https://127.0.0.1:8443 \
     --kubeconfig=/etc/kubernetes/controller-manager.kubeconfig

# 设置一个环境项，一个上下文
kubectl config set-context system:kube-controller-manager@kubernetes \
    --cluster=kubernetes \
    --user=system:kube-controller-manager \
    --kubeconfig=/etc/kubernetes/controller-manager.kubeconfig

  # 设置一个用户项
kubectl config set-credentials system:kube-controller-manager \
   --client-certificate=/etc/kubernetes/pki/controller-manager.pem \
   --client-key=/etc/kubernetes/pki/controller-manager-key.pem \
   --embed-certs=true \
   --kubeconfig=/etc/kubernetes/controller-manager.kubeconfig

# 设置默认环境
kubectl config use-context system:kube-controller-manager@kubernetes \
     --kubeconfig=/etc/kubernetes/controller-manager.kubeconfig

3.2.5 生成kube-scheduler的证书

代码语言：javascript
复制
cat > scheduler-csr.json << EOF
{
  "CN": "system:kube-scheduler",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "ST": "Beijing",
      "L": "Beijing",
      "O": "system:kube-scheduler",
      "OU": "Kubernetes-manual"
    }
  ]
}
EOF


cfssl gencert \
   -ca=/etc/kubernetes/pki/ca.pem \
   -ca-key=/etc/kubernetes/pki/ca-key.pem \
   -config=ca-config.json \
   -profile=kubernetes \
   scheduler-csr.json | cfssljson -bare /etc/kubernetes/pki/scheduler


# 在《5.高可用配置》选择使用那种高可用方案
# 若使用 haproxy、keepalived 那么为 `--server=https://192.168.1.36:9443`
# 若使用 nginx方案，那么为 `--server=https://127.0.0.1:8443`

kubectl config set-cluster kubernetes \
     --certificate-authority=/etc/kubernetes/pki/ca.pem \
     --embed-certs=true \
     --server=https://127.0.0.1:8443 \
     --kubeconfig=/etc/kubernetes/scheduler.kubeconfig


kubectl config set-credentials system:kube-scheduler \
     --client-certificate=/etc/kubernetes/pki/scheduler.pem \
     --client-key=/etc/kubernetes/pki/scheduler-key.pem \
     --embed-certs=true \
     --kubeconfig=/etc/kubernetes/scheduler.kubeconfig


kubectl config set-context system:kube-scheduler@kubernetes \
     --cluster=kubernetes \
     --user=system:kube-scheduler \
     --kubeconfig=/etc/kubernetes/scheduler.kubeconfig

kubectl config use-context system:kube-scheduler@kubernetes \
     --kubeconfig=/etc/kubernetes/scheduler.kubeconfig

3.2.6 生成admin的证书配置

代码语言：javascript
复制
cat > admin-csr.json << EOF
{
  "CN": "admin",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "ST": "Beijing",
      "L": "Beijing",
      "O": "system:masters",
      "OU": "Kubernetes-manual"
    }
  ]
}
EOF


cfssl gencert \
   -ca=/etc/kubernetes/pki/ca.pem \
   -ca-key=/etc/kubernetes/pki/ca-key.pem \
   -config=ca-config.json \
   -profile=kubernetes \
   admin-csr.json | cfssljson -bare /etc/kubernetes/pki/admin

# 在《5.高可用配置》选择使用那种高可用方案
# 若使用 haproxy、keepalived 那么为 `--server=https://192.168.1.36:9443`
# 若使用 nginx方案，那么为 `--server=https://127.0.0.1:8443`

kubectl config set-cluster kubernetes     \
  --certificate-authority=/etc/kubernetes/pki/ca.pem     \
  --embed-certs=true     \
  --server=https://127.0.0.1:8443     \
  --kubeconfig=/etc/kubernetes/admin.kubeconfig
# 该命令用于配置一个名为"kubernetes"的集群，并将其应用到/etc/kubernetes/scheduler.kubeconfig文件中。
#
# 该命令的解释如下：
# - `kubectl config set-cluster kubernetes`: 设置一个集群并命名为"kubernetes"。
# - `--certificate-authority=/etc/kubernetes/pki/ca.pem`: 指定集群使用的证书授权机构的路径。
# - `--embed-certs=true`: 该标志指示将证书嵌入到生成的kubeconfig文件中。
# - `--server=https://127.0.0.1:8443`: 指定集群的 API server 位置。
# - `--kubeconfig=/etc/kubernetes/admin.kubeconfig`: 指定要保存 kubeconfig 文件的路径和名称。

kubectl config set-credentials kubernetes-admin  \
  --client-certificate=/etc/kubernetes/pki/admin.pem     \
  --client-key=/etc/kubernetes/pki/admin-key.pem     \
  --embed-certs=true     \
  --kubeconfig=/etc/kubernetes/admin.kubeconfig

kubectl config set-context kubernetes-admin@kubernetes    \
  --cluster=kubernetes     \
  --user=kubernetes-admin     \
  --kubeconfig=/etc/kubernetes/admin.kubeconfig

kubectl config use-context kubernetes-admin@kubernetes  --kubeconfig=/etc/kubernetes/admin.kubeconfig
# 上述命令是使用`kubectl`命令来配置Kubernetes集群中的调度器组件。
#
# `kubectl config use-context`命令用于切换`kubectl`当前使用的上下文。上下文是Kubernetes集群、用户和命名空间的组合，用于确定`kubectl`的连接目标。下面解释这个命令的不同部分：
#
# - `kubernetes-admin@kubernetes`是一个上下文名称。它指定了使用`kubernetes-admin`用户和`kubernetes`命名空间的系统级别上下文。系统级别上下文用于操作Kubernetes核心组件。
#
# - `--kubeconfig=/etc/kubernetes/admin.kubeconfig`用于指定Kubernetes配置文件的路径。Kubernetes配置文件包含连接到Kubernetes集群所需的身份验证和连接信息。
#
# 通过运行以上命令，`kubectl`将使用指定的上下文和配置文件，以便在以后的命令中能正确地与Kubernetes集群中的调度器组件进行交互。

3.2.7 创建kube-proxy证书

在《5.高可用配置》选择使用那种高可用方案 若使用 haproxy、keepalived 那么为 --server=https://192.168.1.36:9443 若使用 nginx方案，那么为 --server=https://127.0.0.1:8443

代码语言：javascript
复制
cat > kube-proxy-csr.json  << EOF
{
  "CN": "system:kube-proxy",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "ST": "Beijing",
      "L": "Beijing",
      "O": "system:kube-proxy",
      "OU": "Kubernetes-manual"
    }
  ]
}
EOF

cfssl gencert \
   -ca=/etc/kubernetes/pki/ca.pem \
   -ca-key=/etc/kubernetes/pki/ca-key.pem \
   -config=ca-config.json \
   -profile=kubernetes \
   kube-proxy-csr.json | cfssljson -bare /etc/kubernetes/pki/kube-proxy

# 在《5.高可用配置》选择使用那种高可用方案
# 若使用 haproxy、keepalived 那么为 `--server=https://192.168.1.36:9443`
# 若使用 nginx方案，那么为 `--server=https://127.0.0.1:8443`

kubectl config set-cluster kubernetes     \
  --certificate-authority=/etc/kubernetes/pki/ca.pem     \
  --embed-certs=true     \
  --server=https://127.0.0.1:8443     \
  --kubeconfig=/etc/kubernetes/kube-proxy.kubeconfig


kubectl config set-credentials kube-proxy  \
  --client-certificate=/etc/kubernetes/pki/kube-proxy.pem     \
  --client-key=/etc/kubernetes/pki/kube-proxy-key.pem     \
  --embed-certs=true     \
  --kubeconfig=/etc/kubernetes/kube-proxy.kubeconfig

kubectl config set-context kube-proxy@kubernetes    \
  --cluster=kubernetes     \
  --user=kube-proxy     \
  --kubeconfig=/etc/kubernetes/kube-proxy.kubeconfig

kubectl config use-context kube-proxy@kubernetes  --kubeconfig=/etc/kubernetes/kube-proxy.kubeconfig

3.2.8 创建ServiceAccount Key ——secret

代码语言：javascript
复制
openssl genrsa -out /etc/kubernetes/pki/sa.key 2048
openssl rsa -in /etc/kubernetes/pki/sa.key -pubout -out /etc/kubernetes/pki/sa.pub

3.2.9 将证书发送到其他master节点

代码语言：javascript
复制
#其他节点创建目录
# mkdir  /etc/kubernetes/pki/ -p

for NODE in k8s-master02 k8s-master03; do  for FILE in $(ls /etc/kubernetes/pki | grep -v etcd); do  scp /etc/kubernetes/pki/${FILE} $NODE:/etc/kubernetes/pki/${FILE}; done;  for FILE in admin.kubeconfig controller-manager.kubeconfig scheduler.kubeconfig; do  scp /etc/kubernetes/${FILE} $NODE:/etc/kubernetes/${FILE}; done; done

3.2.10 查看证书

代码语言：javascript
复制
[root@k8s-master01 cby]# ll /etc/kubernetes/pki/
总计 104
-rw-r--r--. 1 root root 1025  4月26日 19:22 admin.csr
-rw-------. 1 root root 1679  4月26日 19:22 admin-key.pem
-rw-r--r--. 1 root root 1444  4月26日 19:22 admin.pem
-rw-r--r--. 1 root root 1415  4月26日 19:22 apiserver.csr
-rw-------. 1 root root 1679  4月26日 19:22 apiserver-key.pem
-rw-r--r--. 1 root root 1805  4月26日 19:22 apiserver.pem
-rw-r--r--. 1 root root 1070  4月26日 19:22 ca.csr
-rw-------. 1 root root 1675  4月26日 19:22 ca-key.pem
-rw-r--r--. 1 root root 1363  4月26日 19:22 ca.pem
-rw-r--r--. 1 root root 1082  4月26日 19:22 controller-manager.csr
-rw-------. 1 root root 1679  4月26日 19:22 controller-manager-key.pem
-rw-r--r--. 1 root root 1501  4月26日 19:22 controller-manager.pem
-rw-r--r--. 1 root root  940  4月26日 19:22 front-proxy-ca.csr
-rw-------. 1 root root 1675  4月26日 19:22 front-proxy-ca-key.pem
-rw-r--r--. 1 root root 1094  4月26日 19:22 front-proxy-ca.pem
-rw-r--r--. 1 root root  903  4月26日 19:22 front-proxy-client.csr
-rw-------. 1 root root 1675  4月26日 19:22 front-proxy-client-key.pem
-rw-r--r--. 1 root root 1188  4月26日 19:22 front-proxy-client.pem
-rw-r--r--. 1 root root 1045  4月26日 19:22 kube-proxy.csr
-rw-------. 1 root root 1679  4月26日 19:22 kube-proxy-key.pem
-rw-r--r--. 1 root root 1464  4月26日 19:22 kube-proxy.pem
-rw-------. 1 root root 1704  4月26日 19:23 sa.key
-rw-r--r--. 1 root root  451  4月26日 19:23 sa.pub
-rw-r--r--. 1 root root 1058  4月26日 19:22 scheduler.csr
-rw-------. 1 root root 1675  4月26日 19:22 scheduler-key.pem
-rw-r--r--. 1 root root 1476  4月26日 19:22 scheduler.pem
[root@k8s-master01 cby]#

[root@k8s-master01 cby]# ll /etc/kubernetes/pki/ | wc -l
27
[root@k8s-master01 cby]#

4.k8s系统组件配置

4.1.etcd配置

代码语言：javascript
复制
详见完整版 https://github.com/cby-chen/Kubernetes

4.1.1master01配置

代码语言：javascript
复制
cat > /etc/etcd/etcd.config.yml << EOF
name: 'k8s-master01'
data-dir: /var/lib/etcd
wal-dir: /var/lib/etcd/wal
snapshot-count: 5000
heartbeat-interval: 100
election-timeout: 1000
quota-backend-bytes: 0
listen-peer-urls: 'https://192.168.1.31:2380'
listen-client-urls: 'https://192.168.1.31:2379,http://127.0.0.1:2379'
max-snapshots: 3
max-wals: 5
cors:
initial-advertise-peer-urls: 'https://192.168.1.31:2380'
advertise-client-urls: 'https://192.168.1.31:2379'
discovery:
discovery-fallback: 'proxy'
discovery-proxy:
discovery-srv:
initial-cluster: 'k8s-master01=https://192.168.1.31:2380,k8s-master02=https://192.168.1.32:2380,k8s-master03=https://192.168.1.33:2380'
initial-cluster-token: 'etcd-k8s-cluster'
initial-cluster-state: 'new'
strict-reconfig-check: false
enable-v2: true
enable-pprof: true
proxy: 'off'
proxy-failure-wait: 5000
proxy-refresh-interval: 30000
proxy-dial-timeout: 1000
proxy-write-timeout: 5000
proxy-read-timeout: 0
client-transport-security:
  cert-file: '/etc/kubernetes/pki/etcd/etcd.pem'
  key-file: '/etc/kubernetes/pki/etcd/etcd-key.pem'
  client-cert-auth: true
  trusted-ca-file: '/etc/kubernetes/pki/etcd/etcd-ca.pem'
  auto-tls: true
peer-transport-security:
  cert-file: '/etc/kubernetes/pki/etcd/etcd.pem'
  key-file: '/etc/kubernetes/pki/etcd/etcd-key.pem'
  peer-client-cert-auth: true
  trusted-ca-file: '/etc/kubernetes/pki/etcd/etcd-ca.pem'
  auto-tls: true
debug: false
log-package-levels:
log-outputs: [default]
force-new-cluster: false
EOF

4.1.2master02配置

代码语言：javascript
复制
cat > /etc/etcd/etcd.config.yml << EOF
name: 'k8s-master02'
data-dir: /var/lib/etcd
wal-dir: /var/lib/etcd/wal
snapshot-count: 5000
heartbeat-interval: 100
election-timeout: 1000
quota-backend-bytes: 0
listen-peer-urls: 'https://192.168.1.32:2380'
listen-client-urls: 'https://192.168.1.32:2379,http://127.0.0.1:2379'
max-snapshots: 3
max-wals: 5
cors:
initial-advertise-peer-urls: 'https://192.168.1.32:2380'
advertise-client-urls: 'https://192.168.1.32:2379'
discovery:
discovery-fallback: 'proxy'
discovery-proxy:
discovery-srv:
initial-cluster: 'k8s-master01=https://192.168.1.31:2380,k8s-master02=https://192.168.1.32:2380,k8s-master03=https://192.168.1.33:2380'
initial-cluster-token: 'etcd-k8s-cluster'
initial-cluster-state: 'new'
strict-reconfig-check: false
enable-v2: true
enable-pprof: true
proxy: 'off'
proxy-failure-wait: 5000
proxy-refresh-interval: 30000
proxy-dial-timeout: 1000
proxy-write-timeout: 5000
proxy-read-timeout: 0
client-transport-security:
  cert-file: '/etc/kubernetes/pki/etcd/etcd.pem'
  key-file: '/etc/kubernetes/pki/etcd/etcd-key.pem'
  client-cert-auth: true
  trusted-ca-file: '/etc/kubernetes/pki/etcd/etcd-ca.pem'
  auto-tls: true
peer-transport-security:
  cert-file: '/etc/kubernetes/pki/etcd/etcd.pem'
  key-file: '/etc/kubernetes/pki/etcd/etcd-key.pem'
  peer-client-cert-auth: true
  trusted-ca-file: '/etc/kubernetes/pki/etcd/etcd-ca.pem'
  auto-tls: true
debug: false
log-package-levels:
log-outputs: [default]
force-new-cluster: false
EOF

4.1.3master03配置

代码语言：javascript
复制
cat > /etc/etcd/etcd.config.yml << EOF
name: 'k8s-master03'
data-dir: /var/lib/etcd
wal-dir: /var/lib/etcd/wal
snapshot-count: 5000
heartbeat-interval: 100
election-timeout: 1000
quota-backend-bytes: 0
listen-peer-urls: 'https://192.168.1.33:2380'
listen-client-urls: 'https://192.168.1.33:2379,http://127.0.0.1:2379'
max-snapshots: 3
max-wals: 5
cors:
initial-advertise-peer-urls: 'https://192.168.1.33:2380'
advertise-client-urls: 'https://192.168.1.33:2379'
discovery:
discovery-fallback: 'proxy'
discovery-proxy:
discovery-srv:
initial-cluster: 'k8s-master01=https://192.168.1.31:2380,k8s-master02=https://192.168.1.32:2380,k8s-master03=https://192.168.1.33:2380'
initial-cluster-token: 'etcd-k8s-cluster'
initial-cluster-state: 'new'
strict-reconfig-check: false
enable-v2: true
enable-pprof: true
proxy: 'off'
proxy-failure-wait: 5000
proxy-refresh-interval: 30000
proxy-dial-timeout: 1000
proxy-write-timeout: 5000
proxy-read-timeout: 0
client-transport-security:
  cert-file: '/etc/kubernetes/pki/etcd/etcd.pem'
  key-file: '/etc/kubernetes/pki/etcd/etcd-key.pem'
  client-cert-auth: true
  trusted-ca-file: '/etc/kubernetes/pki/etcd/etcd-ca.pem'
  auto-tls: true
peer-transport-security:
  cert-file: '/etc/kubernetes/pki/etcd/etcd.pem'
  key-file: '/etc/kubernetes/pki/etcd/etcd-key.pem'
  peer-client-cert-auth: true
  trusted-ca-file: '/etc/kubernetes/pki/etcd/etcd-ca.pem'
  auto-tls: true
debug: false
log-package-levels:
log-outputs: [default]
force-new-cluster: false
EOF

4.2.创建service（所有master节点操作）

4.2.1创建etcd.service并启动

代码语言：javascript
复制
cat > /usr/lib/systemd/system/etcd.service << EOF

[Unit]
Description=Etcd Service
Documentation=https://coreos.com/etcd/docs/latest/
After=network.target

[Service]
Type=notify
ExecStart=/usr/local/bin/etcd --config-file=/etc/etcd/etcd.config.yml
TimeoutSec=0
RestartSec=60
Restart=always
StartLimitBurst=3
StartLimitInterval=60s
LimitNOFILE=infinity
LimitNPROC=infinity
LimitCORE=infinity
TasksMax=infinity

[Install]
WantedBy=multi-user.target
Alias=etcd3.service

EOF

4.2.2创建etcd证书目录

代码语言：javascript
复制
mkdir /etc/kubernetes/pki/etcd
ln -s /etc/etcd/ssl/* /etc/kubernetes/pki/etcd/

systemctl daemon-reload
systemctl enable --now etcd.service
systemctl restart etcd.service
systemctl status etcd.service

4.2.3查看etcd状态

代码语言：javascript
复制
etcdctl --endpoints="192.168.1.33:2379,192.168.1.32:2379,192.168.1.31:2379" --cacert=/etc/kubernetes/pki/etcd/etcd-ca.pem --cert=/etc/kubernetes/pki/etcd/etcd.pem --key=/etc/kubernetes/pki/etcd/etcd-key.pem  endpoint status --write-out=table

+-------------------+------------------+---------+-----------------+---------+--------+-----------------------+--------+-----------+------------+-----------+------------+--------------------+--------+--------------------------+-------------------+
|     ENDPOINT      |        ID        | VERSION | STORAGE VERSION | DB SIZE | IN USE | PERCENTAGE NOT IN USE | QUOTA  | IS LEADER | IS LEARNER | RAFT TERM | RAFT INDEX | RAFT APPLIED INDEX | ERRORS | DOWNGRADE TARGET VERSION | DOWNGRADE ENABLED |
+-------------------+------------------+---------+-----------------+---------+--------+-----------------------+--------+-----------+------------+-----------+------------+--------------------+--------+--------------------------+-------------------+
| 192.168.1.33:2379 |  8065f2e59c8d68c |  3.6.11 |           3.6.0 |   20 kB |  16 kB |                   20% | 2.1 GB |     false |      false |         3 |         13 |                 13 |        |                          |             false |
| 192.168.1.32:2379 | b7b7ad6bf4db3f28 |  3.6.11 |           3.6.0 |   20 kB |  16 kB |                   20% | 2.1 GB |     false |      false |         3 |         13 |                 13 |        |                          |             false |
| 192.168.1.31:2379 | bf047bcfe3b9bf27 |  3.6.11 |           3.6.0 |   20 kB |  16 kB |                   20% | 2.1 GB |      true |      false |         3 |         13 |                 13 |        |                          |             false |
+-------------------+------------------+---------+-----------------+---------+--------+-----------------------+--------+-----------+------------+-----------+------------+--------------------+--------+--------------------------+-------------------+

5.高可用配置（在Master服务器上操作）

注意* 5.1.1 和5.1.2 二选一即可

选择使用那种高可用方案，同时可以俩种都选用，实现内外兼顾的效果，比如： 5.1 的 NGINX方案实现集群内的高可用 5.2 的 haproxy、keepalived 方案实现集群外访问

在《3.2.生成k8s相关证书》

若使用 nginx方案，那么为 --server=https://127.0.0.1:8443 若使用 haproxy、keepalived 那么为 --server=https://192.168.1.36:9443

5.1 NGINX高可用方案

5.1.1 进行编译

代码语言：javascript
复制
# 安装编译环境
yum install gcc -y

# 下载解压nginx二进制文件
# wget http://nginx.org/download/nginx-1.25.3.tar.gz
tar xvf nginx-*.tar.gz
cd nginx-*

# 进行编译
./configure --with-stream --without-http --without-http_uwsgi_module --without-http_scgi_module --without-http_fastcgi_module
make && make install

# 拷贝编译好的nginx
node='k8s-master02 k8s-master03 k8s-node01 k8s-node02'
for NODE in $node; do scp -r /usr/local/nginx/ $NODE:/usr/local/nginx/; done

5.1.2 写入启动配置

在所有主机上执行

代码语言：javascript
复制
# 写入nginx配置文件
cat > /usr/local/nginx/conf/kube-nginx.conf <<EOF
worker_processes 1;
events {
    worker_connections  1024;
}
stream {
    upstream backend {
        least_conn;
        hash $remote_addr consistent;
        server 192.168.1.31:6443        max_fails=3 fail_timeout=30s;
        server 192.168.1.32:6443        max_fails=3 fail_timeout=30s;
        server 192.168.1.33:6443        max_fails=3 fail_timeout=30s;
    }
    server {
        listen 127.0.0.1:8443;
        proxy_connect_timeout 1s;
        proxy_pass backend;
    }
}
EOF

# 写入启动配置文件
cat > /etc/systemd/system/kube-nginx.service <<EOF
[Unit]
Description=kube-apiserver nginx proxy
After=network.target
After=network-online.target
Wants=network-online.target

[Service]
Type=forking
ExecStartPre=/usr/local/nginx/sbin/nginx -c /usr/local/nginx/conf/kube-nginx.conf -p /usr/local/nginx -t
ExecStart=/usr/local/nginx/sbin/nginx -c /usr/local/nginx/conf/kube-nginx.conf -p /usr/local/nginx
ExecReload=/usr/local/nginx/sbin/nginx -c /usr/local/nginx/conf/kube-nginx.conf -p /usr/local/nginx -s reload
PrivateTmp=true
Restart=always
RestartSec=5
StartLimitInterval=0
LimitNOFILE=65536

[Install]
WantedBy=multi-user.target
EOF

# 设置开机自启
systemctl daemon-reload
systemctl enable --now kube-nginx.service
systemctl restart kube-nginx.service
systemctl status kube-nginx.service

5.2 keepalived和haproxy 高可用方案

5.2.1安装keepalived和haproxy服务

代码语言：javascript
复制
systemctl disable --now firewalld
setenforce 0
sed -i 's#SELINUX=enforcing#SELINUX=disabled#g' /etc/selinux/config
yum -y install keepalived haproxy

5.2.2修改haproxy配置文件（配置文件一样）

代码语言：javascript
复制
cp /etc/haproxy/haproxy.cfg /etc/haproxy/haproxy.cfg.bak
cat >/etc/haproxy/haproxy.cfg<<"EOF"
global
 maxconn 2000
 ulimit-n 16384
 log 127.0.0.1 local0 err
 stats timeout 30s

defaults
 log global
 mode http
 option httplog
 timeout connect 5000
 timeout client 50000
 timeout server 50000
 timeout http-request 15s
 timeout http-keep-alive 15s


frontend monitor-in
 bind *:33305
 mode http
 option httplog
 monitor-uri /monitor

frontend k8s-master
 bind 0.0.0.0:9443
 bind 127.0.0.1:9443
 mode tcp
 option tcplog
 tcp-request inspect-delay 5s
 default_backend k8s-master


backend k8s-master
 mode tcp
 option tcplog
 option tcp-check
 balance roundrobin
 default-server inter 10s downinter 5s rise 2 fall 2 slowstart 60s maxconn 250 maxqueue 256 weight 100
 server  k8s-master01  192.168.1.31:6443 check
 server  k8s-master02  192.168.1.32:6443 check
 server  k8s-master03  192.168.1.33:6443 check
EOF

参数

代码语言：javascript
复制
详见完整版 https://github.com/cby-chen/Kubernetes

5.2.3Master01配置keepalived master节点

代码语言：javascript
复制
cp /etc/keepalived/keepalived.conf /etc/keepalived/keepalived.conf.bak

cat > /etc/keepalived/keepalived.conf << EOF
! Configuration File for keepalived

global_defs {
    router_id LVS_DEVEL
}
vrrp_script chk_apiserver {
    script "/etc/keepalived/check_apiserver.sh"
    interval 5
    weight -5
    fall 2
    rise 1
}
vrrp_instance VI_1 {
    state MASTER
    # 注意网卡名
    interface ens32
    mcast_src_ip 192.168.1.31
    virtual_router_id 51
    priority 100
    nopreempt
    advert_int 2
    authentication {
        auth_type PASS
        auth_pass K8SHA_KA_AUTH
    }
    virtual_ipaddress {
        192.168.1.36
    }
    track_script {
      chk_apiserver
} }

EOF

5.2.4Master02配置keepalived backup节点

代码语言：javascript
复制
cp /etc/keepalived/keepalived.conf /etc/keepalived/keepalived.conf.bak

cat > /etc/keepalived/keepalived.conf << EOF
! Configuration File for keepalived

global_defs {
    router_id LVS_DEVEL
}
vrrp_script chk_apiserver {
    script "/etc/keepalived/check_apiserver.sh"
    interval 5
    weight -5
    fall 2
    rise 1

}
vrrp_instance VI_1 {
    state BACKUP
    # 注意网卡名
    interface ens32
    mcast_src_ip 192.168.1.32
    virtual_router_id 51
    priority 80
    nopreempt
    advert_int 2
    authentication {
        auth_type PASS
        auth_pass K8SHA_KA_AUTH
    }
    virtual_ipaddress {
        192.168.1.36
    }
    track_script {
      chk_apiserver
} }

EOF

5.2.5Master03配置keepalived backup节点

代码语言：javascript
复制
cp /etc/keepalived/keepalived.conf /etc/keepalived/keepalived.conf.bak

cat > /etc/keepalived/keepalived.conf << EOF
! Configuration File for keepalived

global_defs {
    router_id LVS_DEVEL
}
vrrp_script chk_apiserver {
    script "/etc/keepalived/check_apiserver.sh"
    interval 5
    weight -5
    fall 2
    rise 1

}
vrrp_instance VI_1 {
    state BACKUP
    # 注意网卡名
    interface ens32
    mcast_src_ip 192.168.1.33
    virtual_router_id 51
    priority 50
    nopreempt
    advert_int 2
    authentication {
        auth_type PASS
        auth_pass K8SHA_KA_AUTH
    }
    virtual_ipaddress {
        192.168.1.36
    }
    track_script {
      chk_apiserver
} }

EOF

参数

代码语言：javascript
复制
详见完整版 https://github.com/cby-chen/Kubernetes

5.2.6健康检查脚本配置（lb主机）

代码语言：javascript
复制
cat >  /etc/keepalived/check_apiserver.sh << EOF
#!/bin/bash

err=0
for k in \$(seq 1 3)
do
    check_code=\$(pgrep haproxy)
    if [[ \$check_code == "" ]]; then
        err=\$(expr \$err + 1)
        sleep 1
        continue
    else
        err=0
        break
    fi
done

if [[ \$err != "0" ]]; then
    echo "systemctl stop keepalived"
    /usr/bin/systemctl stop keepalived
    exit 1
else
    exit 0
fi
EOF

# 给脚本授权

chmod +x /etc/keepalived/check_apiserver.sh

5.2.7启动服务

代码语言：javascript
复制
systemctl daemon-reload
systemctl enable --now haproxy.service
systemctl enable --now keepalived.service
systemctl status haproxy.service
systemctl status keepalived.service

5.2.8测试高可用

代码语言：javascript
复制
# 能ping同
[root@k8s-node02 ~]# ping 192.168.1.36

# 能telnet访问
[root@k8s-node02 ~]# telnet 192.168.1.36 9443

# 关闭主节点，看vip是否漂移到备节点

6.k8s组件配置

所有k8s节点创建以下目录

代码语言：javascript
复制
mkdir -p /etc/kubernetes/manifests/ /etc/systemd/system/kubelet.service.d /var/lib/kubelet /var/log/kubernetes

6.1.创建apiserver（所有master节点）

6.1.1master01节点配置

代码语言：javascript
复制
# 若关闭IPv6 删除 --service-cluster-ip-range 的 IPv6 即可
cat > /usr/lib/systemd/system/kube-apiserver.service << EOF
[Unit]
Description=Kubernetes API Server
Documentation=https://github.com/kubernetes/kubernetes
After=network.target

[Service]
ExecStart=/usr/local/bin/kube-apiserver \\
      --v=2  \\
      --allow-privileged=true  \\
      --bind-address=0.0.0.0  \\
      --secure-port=6443  \\
      --advertise-address=192.168.1.31 \\
      --service-cluster-ip-range=10.96.0.0/16,fd00:1111::/112  \\
      --service-node-port-range=30000-32767  \\
      --etcd-servers=https://192.168.1.31:2379,https://192.168.1.32:2379,https://192.168.1.33:2379 \\
      --etcd-cafile=/etc/etcd/ssl/etcd-ca.pem  \\
      --etcd-certfile=/etc/etcd/ssl/etcd.pem  \\
      --etcd-keyfile=/etc/etcd/ssl/etcd-key.pem  \\
      --client-ca-file=/etc/kubernetes/pki/ca.pem  \\
      --tls-cert-file=/etc/kubernetes/pki/apiserver.pem  \\
      --tls-private-key-file=/etc/kubernetes/pki/apiserver-key.pem  \\
      --kubelet-client-certificate=/etc/kubernetes/pki/apiserver.pem  \\
      --kubelet-client-key=/etc/kubernetes/pki/apiserver-key.pem  \\
      --service-account-key-file=/etc/kubernetes/pki/sa.pub  \\
      --service-account-signing-key-file=/etc/kubernetes/pki/sa.key  \\
      --service-account-issuer=https://kubernetes.default.svc.cluster.local \\
      --kubelet-preferred-address-types=InternalIP,ExternalIP,Hostname  \\
      --enable-admission-plugins=NamespaceLifecycle,LimitRanger,ServiceAccount,DefaultStorageClass,DefaultTolerationSeconds,NodeRestriction,ResourceQuota  \
      --authorization-mode=Node,RBAC  \\
      --enable-bootstrap-token-auth=true  \\
      --requestheader-client-ca-file=/etc/kubernetes/pki/front-proxy-ca.pem  \\
      --proxy-client-cert-file=/etc/kubernetes/pki/front-proxy-client.pem  \\
      --proxy-client-key-file=/etc/kubernetes/pki/front-proxy-client-key.pem  \\
      --requestheader-allowed-names=aggregator  \\
      --requestheader-group-headers=X-Remote-Group  \\
      --requestheader-extra-headers-prefix=X-Remote-Extra-  \\
      --requestheader-username-headers=X-Remote-User \\
      --enable-aggregator-routing=true
Restart=on-failure
RestartSec=10s
LimitNOFILE=65535

[Install]
WantedBy=multi-user.target

EOF

6.1.2master02节点配置

代码语言：javascript
复制
# 若关闭IPv6 删除 --service-cluster-ip-range 的 IPv6 即可
cat > /usr/lib/systemd/system/kube-apiserver.service << EOF
[Unit]
Description=Kubernetes API Server
Documentation=https://github.com/kubernetes/kubernetes
After=network.target

[Service]
ExecStart=/usr/local/bin/kube-apiserver \\
      --v=2  \\
      --allow-privileged=true  \\
      --bind-address=0.0.0.0  \\
      --secure-port=6443  \\
      --advertise-address=192.168.1.32 \\
      --service-cluster-ip-range=10.96.0.0/16,fd00:1111::/112  \\
      --service-node-port-range=30000-32767  \\
      --etcd-servers=https://192.168.1.31:2379,https://192.168.1.32:2379,https://192.168.1.33:2379 \\
      --etcd-cafile=/etc/etcd/ssl/etcd-ca.pem  \\
      --etcd-certfile=/etc/etcd/ssl/etcd.pem  \\
      --etcd-keyfile=/etc/etcd/ssl/etcd-key.pem  \\
      --client-ca-file=/etc/kubernetes/pki/ca.pem  \\
      --tls-cert-file=/etc/kubernetes/pki/apiserver.pem  \\
      --tls-private-key-file=/etc/kubernetes/pki/apiserver-key.pem  \\
      --kubelet-client-certificate=/etc/kubernetes/pki/apiserver.pem  \\
      --kubelet-client-key=/etc/kubernetes/pki/apiserver-key.pem  \\
      --service-account-key-file=/etc/kubernetes/pki/sa.pub  \\
      --service-account-signing-key-file=/etc/kubernetes/pki/sa.key  \\
      --service-account-issuer=https://kubernetes.default.svc.cluster.local \\
      --kubelet-preferred-address-types=InternalIP,ExternalIP,Hostname  \\
      --enable-admission-plugins=NamespaceLifecycle,LimitRanger,ServiceAccount,DefaultStorageClass,DefaultTolerationSeconds,NodeRestriction,ResourceQuota  \\
      --authorization-mode=Node,RBAC  \\
      --enable-bootstrap-token-auth=true  \\
      --requestheader-client-ca-file=/etc/kubernetes/pki/front-proxy-ca.pem  \\
      --proxy-client-cert-file=/etc/kubernetes/pki/front-proxy-client.pem  \\
      --proxy-client-key-file=/etc/kubernetes/pki/front-proxy-client-key.pem  \\
      --requestheader-allowed-names=aggregator  \\
      --requestheader-group-headers=X-Remote-Group  \\
      --requestheader-extra-headers-prefix=X-Remote-Extra-  \\
      --requestheader-username-headers=X-Remote-User \\
      --enable-aggregator-routing=true

Restart=on-failure
RestartSec=10s
LimitNOFILE=65535

[Install]
WantedBy=multi-user.target

EOF

6.1.3master03节点配置

代码语言：javascript
复制
# 若关闭IPv6 删除 --service-cluster-ip-range 的 IPv6 即可
cat > /usr/lib/systemd/system/kube-apiserver.service  << EOF
[Unit]
Description=Kubernetes API Server
Documentation=https://github.com/kubernetes/kubernetes
After=network.target

[Service]
ExecStart=/usr/local/bin/kube-apiserver \\
      --v=2  \\
      --allow-privileged=true  \\
      --bind-address=0.0.0.0  \\
      --secure-port=6443  \\
      --advertise-address=192.168.1.33 \\
      --service-cluster-ip-range=10.96.0.0/16,fd00:1111::/112  \\
      --service-node-port-range=30000-32767  \\
      --etcd-servers=https://192.168.1.31:2379,https://192.168.1.32:2379,https://192.168.1.33:2379 \\
      --etcd-cafile=/etc/etcd/ssl/etcd-ca.pem  \\
      --etcd-certfile=/etc/etcd/ssl/etcd.pem  \\
      --etcd-keyfile=/etc/etcd/ssl/etcd-key.pem  \\
      --client-ca-file=/etc/kubernetes/pki/ca.pem  \\
      --tls-cert-file=/etc/kubernetes/pki/apiserver.pem  \\
      --tls-private-key-file=/etc/kubernetes/pki/apiserver-key.pem  \\
      --kubelet-client-certificate=/etc/kubernetes/pki/apiserver.pem  \\
      --kubelet-client-key=/etc/kubernetes/pki/apiserver-key.pem  \\
      --service-account-key-file=/etc/kubernetes/pki/sa.pub  \\
      --service-account-signing-key-file=/etc/kubernetes/pki/sa.key  \\
      --service-account-issuer=https://kubernetes.default.svc.cluster.local \\
      --kubelet-preferred-address-types=InternalIP,ExternalIP,Hostname  \\
      --enable-admission-plugins=NamespaceLifecycle,LimitRanger,ServiceAccount,DefaultStorageClass,DefaultTolerationSeconds,NodeRestriction,ResourceQuota  \\
      --authorization-mode=Node,RBAC  \\
      --enable-bootstrap-token-auth=true  \\
      --requestheader-client-ca-file=/etc/kubernetes/pki/front-proxy-ca.pem  \\
      --proxy-client-cert-file=/etc/kubernetes/pki/front-proxy-client.pem  \\
      --proxy-client-key-file=/etc/kubernetes/pki/front-proxy-client-key.pem  \\
      --requestheader-allowed-names=aggregator  \\
      --requestheader-group-headers=X-Remote-Group  \\
      --requestheader-extra-headers-prefix=X-Remote-Extra-  \\
      --requestheader-username-headers=X-Remote-User \\
      --enable-aggregator-routing=true

Restart=on-failure
RestartSec=10s
LimitNOFILE=65535

[Install]
WantedBy=multi-user.target

EOF

参数

代码语言：javascript
复制
详见完整版 https://github.com/cby-chen/Kubernetes

6.1.4启动apiserver（所有master节点）

代码语言：javascript
复制
systemctl daemon-reload
# 用于重新加载systemd管理的单位文件。当你新增或修改了某个单位文件（如.service文件、.socket文件等），需要运行该命令来刷新systemd对该文件的配置。

systemctl enable --now kube-apiserver.service
# 启用并立即启动kube-apiserver.service单元。kube-apiserver.service是kube-apiserver守护进程的systemd服务单元。

systemctl restart kube-apiserver.service
# 重启kube-apiserver.service单元，即重新启动etcd守护进程。

systemctl status kube-apiserver.service
# kube-apiserver.service单元的当前状态，包括运行状态、是否启用等信息。

6.2.配置kube-controller-manager service

代码语言：javascript
复制
# 所有master节点配置，且配置相同
# 172.16.0.0/16为pod网段，按需求设置你自己的网段

cat > /usr/lib/systemd/system/kube-controller-manager.service << EOF
[Unit]
Description=Kubernetes Controller Manager
Documentation=https://github.com/kubernetes/kubernetes
After=network.target

[Service]
ExecStart=/usr/local/bin/kube-controller-manager \\
      --v=2 \\
      --bind-address=0.0.0.0 \\
      --root-ca-file=/etc/kubernetes/pki/ca.pem \\
      --cluster-signing-cert-file=/etc/kubernetes/pki/ca.pem \\
      --cluster-signing-key-file=/etc/kubernetes/pki/ca-key.pem \\
      --service-account-private-key-file=/etc/kubernetes/pki/sa.key \\
      --kubeconfig=/etc/kubernetes/controller-manager.kubeconfig \\
      --leader-elect=true \\
      --use-service-account-credentials=true \\
      --node-monitor-grace-period=40s \\
      --node-monitor-period=5s \\
      --controllers=*,bootstrapsigner,tokencleaner \\
      --allocate-node-cidrs=true \\
      --service-cluster-ip-range=10.96.0.0/16,fd00:1111::/112 \\
      --cluster-cidr=172.16.0.0/16,fd00:2222::/112 \\
      --node-cidr-mask-size-ipv4=24 \\
      --node-cidr-mask-size-ipv6=120 \\
      --requestheader-client-ca-file=/etc/kubernetes/pki/front-proxy-ca.pem

Restart=always
RestartSec=10s

[Install]
WantedBy=multi-user.target
EOF



# 关闭IPv6
# 删除 --service-cluster-ip-range 中的IPv6地址
# 删除 --cluster-cidr 中的IPv6地址
# 删除 --node-cidr-mask-size-ipv6=120
cat > /usr/lib/systemd/system/kube-controller-manager.service << EOF
[Unit]
Description=Kubernetes Controller Manager
Documentation=https://github.com/kubernetes/kubernetes
After=network.target

[Service]
ExecStart=/usr/local/bin/kube-controller-manager \\
      --v=2 \\
      --bind-address=0.0.0.0 \\
      --root-ca-file=/etc/kubernetes/pki/ca.pem \\
      --cluster-signing-cert-file=/etc/kubernetes/pki/ca.pem \\
      --cluster-signing-key-file=/etc/kubernetes/pki/ca-key.pem \\
      --service-account-private-key-file=/etc/kubernetes/pki/sa.key \\
      --kubeconfig=/etc/kubernetes/controller-manager.kubeconfig \\
      --leader-elect=true \\
      --use-service-account-credentials=true \\
      --node-monitor-grace-period=40s \\
      --node-monitor-period=5s \\
      --controllers=*,bootstrapsigner,tokencleaner \\
      --allocate-node-cidrs=true \\
      --service-cluster-ip-range=10.96.0.0/16 \\
      --cluster-cidr=172.16.0.0/16 \\
      --node-cidr-mask-size-ipv4=24 \\
      --requestheader-client-ca-file=/etc/kubernetes/pki/front-proxy-ca.pem

Restart=always
RestartSec=10s

[Install]
WantedBy=multi-user.target
EOF

参数

代码语言：javascript
复制
详见完整版 https://github.com/cby-chen/Kubernetes

6.2.1启动kube-controller-manager，并查看状态

代码语言：javascript
复制
systemctl daemon-reload
systemctl enable --now kube-controller-manager.service
systemctl restart kube-controller-manager.service
systemctl status kube-controller-manager.service

6.3.配置kube-scheduler service

6.3.1所有master节点配置，且配置相同

代码语言：javascript
复制
cat > /usr/lib/systemd/system/kube-scheduler.service << EOF

[Unit]
Description=Kubernetes Scheduler
Documentation=https://github.com/kubernetes/kubernetes
After=network.target

[Service]
ExecStart=/usr/local/bin/kube-scheduler \\
      --v=2 \\
      --bind-address=0.0.0.0 \\
      --leader-elect=true \\
      --kubeconfig=/etc/kubernetes/scheduler.kubeconfig

Restart=always
RestartSec=10s

[Install]
WantedBy=multi-user.target

EOF

参数

代码语言：javascript
复制
详见完整版 https://github.com/cby-chen/Kubernetes

6.3.2启动并查看服务状态

代码语言：javascript
复制
systemctl daemon-reload
systemctl enable --now kube-scheduler.service
systemctl restart kube-scheduler.service
systemctl status kube-scheduler.service

7.TLS Bootstrapping配置

7.1在master01上配置

代码语言：javascript
复制
# 在《5.高可用配置》选择使用那种高可用方案
# 若使用 haproxy、keepalived 那么为 `--server=https://192.168.1.36:9443`
# 若使用 nginx方案，那么为 `--server=https://127.0.0.1:8443`

kubectl config set-cluster kubernetes     \
--certificate-authority=/etc/kubernetes/pki/ca.pem     \
--embed-certs=true     --server=https://127.0.0.1:8443     \
--kubeconfig=/etc/kubernetes/bootstrap-kubelet.kubeconfig

# 可以使用这个命令进行创建token也可以使用我的
echo "$(head -c 6 /dev/urandom | md5sum | head -c 6)"."$(head -c 16 /dev/urandom | md5sum | head -c 16)"

kubectl config set-credentials tls-bootstrap-token-user     \
--token=c8ad9c.2e4d610cf3e7426e \
--kubeconfig=/etc/kubernetes/bootstrap-kubelet.kubeconfig

kubectl config set-context tls-bootstrap-token-user@kubernetes     \
--cluster=kubernetes     \
--user=tls-bootstrap-token-user     \
--kubeconfig=/etc/kubernetes/bootstrap-kubelet.kubeconfig

kubectl config use-context tls-bootstrap-token-user@kubernetes     \
--kubeconfig=/etc/kubernetes/bootstrap-kubelet.kubeconfig

# token的位置在bootstrap.secret.yaml，如果修改的话到这个文件修改
mkdir -p /root/.kube ; cp /etc/kubernetes/admin.kubeconfig /root/.kube/config

7.2查看集群状态，没问题的话继续后续操作

代码语言：javascript
复制
# 1.28 版本只能查看到一个etcd 属于正常现象
# export ETCDCTL_API=3
# etcdctl --endpoints="192.168.1.33:2379,192.168.1.32:2379,192.168.1.31:2379" --cacert=/etc/kubernetes/pki/etcd/etcd-ca.pem --cert=/etc/kubernetes/pki/etcd/etcd.pem --key=/etc/kubernetes/pki/etcd/etcd-key.pem  endpoint status --write-out=table

kubectl get cs
Warning: v1 ComponentStatus is deprecated in v1.19+
NAME                 STATUS    MESSAGE   ERROR
scheduler            Healthy   ok
controller-manager   Healthy   ok
etcd-0               Healthy   ok

# 写入bootstrap-token
cat > bootstrap.secret.yaml << EOF
apiVersion: v1
kind: Secret
metadata:
  name: bootstrap-token-c8ad9c
  namespace: kube-system
type: bootstrap.kubernetes.io/token
stringData:
  description: "The default bootstrap token generated by 'kubelet '."
  token-id: c8ad9c
  token-secret: 2e4d610cf3e7426e
  usage-bootstrap-authentication: "true"
  usage-bootstrap-signing: "true"
  auth-extra-groups:  system:bootstrappers:default-node-token,system:bootstrappers:worker,system:bootstrappers:ingress

---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: kubelet-bootstrap
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: system:node-bootstrapper
subjects:
- apiGroup: rbac.authorization.k8s.io
  kind: Group
  name: system:bootstrappers:default-node-token
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: node-autoapprove-bootstrap
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: system:certificates.k8s.io:certificatesigningrequests:nodeclient
subjects:
- apiGroup: rbac.authorization.k8s.io
  kind: Group
  name: system:bootstrappers:default-node-token
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: node-autoapprove-certificate-rotation
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: system:certificates.k8s.io:certificatesigningrequests:selfnodeclient
subjects:
- apiGroup: rbac.authorization.k8s.io
  kind: Group
  name: system:nodes
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  annotations:
    rbac.authorization.kubernetes.io/autoupdate: "true"
  labels:
    kubernetes.io/bootstrapping: rbac-defaults
  name: system:kube-apiserver-to-kubelet
rules:
  - apiGroups:
      - ""
    resources:
      - nodes/proxy
      - nodes/stats
      - nodes/log
      - nodes/spec
      - nodes/metrics
    verbs:
      - "*"
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: system:kube-apiserver
  namespace: ""
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: system:kube-apiserver-to-kubelet
subjects:
  - apiGroup: rbac.authorization.k8s.io
    kind: User
    name: kube-apiserver
EOF
# 切记执行，别忘记！！！
kubectl create -f bootstrap.secret.yaml

8.node节点配置

8.1.在master01上将证书复制到node节点

代码语言：javascript
复制
cd /etc/kubernetes/

for NODE in k8s-master02 k8s-master03 k8s-node01 k8s-node02; do ssh $NODE mkdir -p /etc/kubernetes/pki; for FILE in pki/ca.pem pki/ca-key.pem pki/front-proxy-ca.pem bootstrap-kubelet.kubeconfig kube-proxy.kubeconfig; do scp /etc/kubernetes/$FILE $NODE:/etc/kubernetes/${FILE}; done; done

8.2.kubelet配置

注意 ： 8.2.1 和 8.2.2 需要和 上方 2.1 和 2.2 对应起来

8.2.1配置kubelet

代码语言：javascript
复制
cat > /usr/lib/systemd/system/kubelet.service << EOF

[Unit]
Description=Kubernetes Kubelet
Documentation=https://github.com/kubernetes/kubernetes
After=network-online.target firewalld.service cri-docker.service docker.socket containerd.service
Wants=network-online.target
Requires=docker.socket containerd.service

[Service]
ExecStart=/usr/local/bin/kubelet \\
    --bootstrap-kubeconfig=/etc/kubernetes/bootstrap-kubelet.kubeconfig  \\
    --kubeconfig=/etc/kubernetes/kubelet.kubeconfig \\
    --config=/etc/kubernetes/kubelet-conf.yml \\
    --node-labels=node.kubernetes.io/node=


[Install]
WantedBy=multi-user.target
EOF


# IPv6示例
# 若不使用IPv6那么忽略此项即可
# 下方 --node-ip 更换为每个节点的IP即可
cat > /usr/lib/systemd/system/kubelet.service << EOF
[Unit]
Description=Kubernetes Kubelet
Documentation=https://github.com/kubernetes/kubernetes
After=network-online.target firewalld.service cri-docker.service docker.socket containerd.service
Wants=network-online.target
Requires=docker.socket containerd.service

[Service]
ExecStart=/usr/local/bin/kubelet \\
    --bootstrap-kubeconfig=/etc/kubernetes/bootstrap-kubelet.kubeconfig  \\
    --kubeconfig=/etc/kubernetes/kubelet.kubeconfig \\
    --config=/etc/kubernetes/kubelet-conf.yml \\
    --node-labels=node.kubernetes.io/node=   \\
    --node-ip=192.168.1.31,fc00::31
[Install]
WantedBy=multi-user.target
EOF

# 自动获取IP编制
# 1. 自动获取本机 IPv4 地址 (根据实际情况，这里假设网卡名为 eth0，如果不同请修改)
# 如果你的网卡名不同，可以用 ip addr show | grep 'inet ' | grep -v '127.0.0.1' | awk '{print $2}' | cut -d/ -f1 自动获取
NODE_IPV4=$(hostname -I | awk '{print $1}')

# 2. 根据 IPv4 自动推算 IPv6 (针对你提供的 192.168.1.x -> fc00::x 规则)
# 提取最后一段数字
LAST_OCTET=$(echo $NODE_IPV4 | awk -F. '{print $4}')
NODE_IPV6="fc00::${LAST_OCTET}"

# 3. 生成 kubelet.service 文件
cat > /usr/lib/systemd/system/kubelet.service << EOF
[Unit]
Description=Kubernetes Kubelet
Documentation=https://github.com/kubernetes/kubernetes
After=network-online.target firewalld.service cri-docker.service docker.socket containerd.service
Wants=network-online.target
Requires=docker.socket containerd.service

[Service]
ExecStart=/usr/local/bin/kubelet \\
    --bootstrap-kubeconfig=/etc/kubernetes/bootstrap-kubelet.kubeconfig  \\
    --kubeconfig=/etc/kubernetes/kubelet.kubeconfig \\
    --config=/etc/kubernetes/kubelet-conf.yml \\
    --node-labels=node.kubernetes.io/node=   \\
    --node-ip=${NODE_IPV4},${NODE_IPV6}
[Install]
WantedBy=multi-user.target
EOF

# 查看是否正确
cat /usr/lib/systemd/system/kubelet.service

8.2.2所有k8s节点创建kubelet的配置文件

当使用docker作为Runtime

代码语言：javascript
复制
cat > /etc/kubernetes/kubelet-conf.yml <<EOF
apiVersion: kubelet.config.k8s.io/v1beta1
kind: KubeletConfiguration
enableServer: true
staticPodPath: /etc/kubernetes/manifests
syncFrequency: 1m0s
fileCheckFrequency: 20s
httpCheckFrequency: 20s
address: 0.0.0.0
port: 10250
readOnlyPort: 10255
rotateCertificates: true
authentication:
  x509:
    clientCAFile: /etc/kubernetes/pki/ca.pem
  webhook:
    enabled: true
    cacheTTL: 2m0s
  anonymous:
    enabled: true
authorization:
  mode: AlwaysAllow
  webhook:
    cacheAuthorizedTTL: 5m0s
    cacheUnauthorizedTTL: 30s
registryPullQPS: 5
registryBurst: 10
eventRecordQPS: 50
eventBurst: 100
enableDebuggingHandlers: true
healthzPort: 10248
healthzBindAddress: 127.0.0.1
oomScoreAdj: -999
clusterDomain: cluster.local
clusterDNS:
  - 10.0.0.10
streamingConnectionIdleTimeout: 4h0m0s
nodeStatusUpdateFrequency: 10s
nodeStatusReportFrequency: 5m0s
nodeLeaseDurationSeconds: 40
imageMinimumGCAge: 2m0s
imageMaximumGCAge: 0s
imageGCHighThresholdPercent: 85
imageGCLowThresholdPercent: 80
volumeStatsAggPeriod: 1m0s
cgroupsPerQOS: true
cgroupDriver: systemd
cpuManagerPolicy: none
cpuManagerReconcilePeriod: 10s
memoryManagerPolicy: None
topologyManagerPolicy: none
topologyManagerScope: container
runtimeRequestTimeout: 2m0s
hairpinMode: promiscuous-bridge
maxPods: 110
podPidsLimit: -1
resolvConf: /etc/resolv.conf
cpuCFSQuota: true
cpuCFSQuotaPeriod: 100ms
nodeStatusMaxImages: 50
maxOpenFiles: 1000000
contentType: application/vnd.kubernetes.protobuf
kubeAPIQPS: 50
kubeAPIBurst: 100
serializeImagePulls: true
evictionHard:
  imagefs.available: 15%
  memory.available: 100Mi
  nodefs.available: 10%
  nodefs.inodesFree: 5%
  imagefs.inodesFree: 5%
evictionPressureTransitionPeriod: 1m0s
mergeDefaultEvictionSettings: false
enableControllerAttachDetach: true
makeIPTablesUtilChains: true
iptablesMasqueradeBit: 14
iptablesDropBit: 15
featureGates:
  AllAlpha: false
failSwapOn: false
memorySwap: {}
containerLogMaxSize: 10Mi
containerLogMaxFiles: 5
configMapAndSecretChangeDetectionStrategy: Watch
enforceNodeAllocatable:
  - pods
volumePluginDir: /usr/libexec/kubernetes/kubelet-plugins/volume/exec/
logging:
  format: text
  flushFrequency: 5s
  verbosity: 3
  options:
    json:
      infoBufferSize: 0
enableSystemLogHandler: true
enableSystemLogQuery: false
shutdownGracePeriod: 0s
shutdownGracePeriodCriticalPods: 0s
enableProfilingHandler: true
enableDebugFlagsHandler: true
seccompDefault: false
memoryThrottlingFactor: 0.9
registerNode: true
localStorageCapacityIsolation: true
containerRuntimeEndpoint: unix:///run/cri-dockerd.sock
EOF

8.2.3当使用Containerd作为Runtime

代码语言：javascript
复制
cat > /etc/kubernetes/kubelet-conf.yml <<EOF
apiVersion: kubelet.config.k8s.io/v1beta1
kind: KubeletConfiguration
enableServer: true
staticPodPath: /etc/kubernetes/manifests
syncFrequency: 1m0s
fileCheckFrequency: 20s
httpCheckFrequency: 20s
address: 0.0.0.0
port: 10250
readOnlyPort: 10255
rotateCertificates: true
authentication:
  x509:
    clientCAFile: /etc/kubernetes/pki/ca.pem
  webhook:
    enabled: true
    cacheTTL: 2m0s
  anonymous:
    enabled: true
authorization:
  mode: AlwaysAllow
  webhook:
    cacheAuthorizedTTL: 5m0s
    cacheUnauthorizedTTL: 30s
registryPullQPS: 5
registryBurst: 10
eventRecordQPS: 50
eventBurst: 100
enableDebuggingHandlers: true
healthzPort: 10248
healthzBindAddress: 127.0.0.1
oomScoreAdj: -999
clusterDomain: cluster.local
clusterDNS:
  - 10.0.0.10
streamingConnectionIdleTimeout: 4h0m0s
nodeStatusUpdateFrequency: 10s
nodeStatusReportFrequency: 5m0s
nodeLeaseDurationSeconds: 40
imageMinimumGCAge: 2m0s
imageMaximumGCAge: 0s
imageGCHighThresholdPercent: 85
imageGCLowThresholdPercent: 80
volumeStatsAggPeriod: 1m0s
cgroupsPerQOS: true
cgroupDriver: systemd
cpuManagerPolicy: none
cpuManagerReconcilePeriod: 10s
memoryManagerPolicy: None
topologyManagerPolicy: none
topologyManagerScope: container
runtimeRequestTimeout: 2m0s
hairpinMode: promiscuous-bridge
maxPods: 110
podPidsLimit: -1
resolvConf: /etc/resolv.conf
cpuCFSQuota: true
cpuCFSQuotaPeriod: 100ms
nodeStatusMaxImages: 50
maxOpenFiles: 1000000
contentType: application/vnd.kubernetes.protobuf
kubeAPIQPS: 50
kubeAPIBurst: 100
serializeImagePulls: true
evictionHard:
  imagefs.available: 15%
  memory.available: 100Mi
  nodefs.available: 10%
  nodefs.inodesFree: 5%
  imagefs.inodesFree: 5%
evictionPressureTransitionPeriod: 1m0s
mergeDefaultEvictionSettings: false
enableControllerAttachDetach: true
makeIPTablesUtilChains: true
iptablesMasqueradeBit: 14
iptablesDropBit: 15
featureGates:
  AllAlpha: false
failSwapOn: false
memorySwap: {}
containerLogMaxSize: 10Mi
containerLogMaxFiles: 5
configMapAndSecretChangeDetectionStrategy: Watch
enforceNodeAllocatable:
  - pods
volumePluginDir: /usr/libexec/kubernetes/kubelet-plugins/volume/exec/
logging:
  format: text
  flushFrequency: 5s
  verbosity: 3
  options:
    json:
      infoBufferSize: 0
enableSystemLogHandler: true
enableSystemLogQuery: false
shutdownGracePeriod: 0s
shutdownGracePeriodCriticalPods: 0s
enableProfilingHandler: true
enableDebugFlagsHandler: true
seccompDefault: false
memoryThrottlingFactor: 0.9
registerNode: true
localStorageCapacityIsolation: true
containerRuntimeEndpoint: unix:///run/containerd/containerd.sock
EOF

8.2.4启动kubelet

代码语言：javascript
复制
systemctl daemon-reload
systemctl enable --now kubelet.service
systemctl restart kubelet.service
systemctl status kubelet.service

8.2.5查看集群

代码语言：javascript
复制
[root@k8s-master01 cby]# kubectl  get node
NAME           STATUS     ROLES    AGE   VERSION
k8s-master01   NotReady   <none>   9s    v1.36.0
k8s-master02   NotReady   <none>   7s    v1.36.0
k8s-master03   NotReady   <none>   6s    v1.36.0
k8s-node01     NotReady   <none>   4s    v1.36.0
k8s-node02     NotReady   <none>   4s    v1.36.0
[root@k8s-master01 cby]#

8.2.6查看容器运行时

代码语言：javascript
复制
[root@k8s-master01 cby]# kubectl describe node | grep Runtime
  Container Runtime Version:  containerd://2.2.3
  Container Runtime Version:  containerd://2.2.3
  Container Runtime Version:  containerd://2.2.3
  Container Runtime Version:  containerd://2.2.3
  Container Runtime Version:  containerd://2.2.3
[root@k8s-master01 cby]#
[root@k8s-master01 ~]# kubectl describe node | grep Runtime
  Container Runtime Version:  docker://29.4.3
  Container Runtime Version:  docker://29.4.3
  Container Runtime Version:  docker://29.4.3
  Container Runtime Version:  docker://29.4.3
  Container Runtime Version:  docker://29.4.3
[root@k8s-master01 ~]#

8.3.kube-proxy配置

8.3.1将kubeconfig发送至其他节点

代码语言：javascript
复制
# master-1执行
for NODE in k8s-master02 k8s-master03 k8s-node01 k8s-node02; do scp /etc/kubernetes/kube-proxy.kubeconfig $NODE:/etc/kubernetes/kube-proxy.kubeconfig; done

8.3.2所有k8s节点添加kube-proxy的service文件

代码语言：javascript
复制
cat >  /usr/lib/systemd/system/kube-proxy.service << EOF
[Unit]
Description=Kubernetes Kube Proxy
Documentation=https://github.com/kubernetes/kubernetes
After=network.target

[Service]
ExecStart=/usr/local/bin/kube-proxy \\
  --config=/etc/kubernetes/kube-proxy.yaml \\
  --cluster-cidr=172.16.0.0/16,fd00:2222::/112 \\
  --v=2
Restart=always
RestartSec=10s

[Install]
WantedBy=multi-user.target

EOF


# 关闭IPv6
# 删除 --cluster-cidr 的IPv6地址
cat >  /usr/lib/systemd/system/kube-proxy.service << EOF
[Unit]
Description=Kubernetes Kube Proxy
Documentation=https://github.com/kubernetes/kubernetes
After=network.target

[Service]
ExecStart=/usr/local/bin/kube-proxy \\
  --config=/etc/kubernetes/kube-proxy.yaml \\
  --cluster-cidr=172.16.0.0/16 \\
  --v=2
Restart=always
RestartSec=10s

[Install]
WantedBy=multi-user.target

EOF

# 这是一个 systemd 服务单元文件的示例，用于配置 Kubernetes Kube Proxy 服务。下面是对其中一些字段的详细解释：
#
# [Unit]
#
# Description: 描述了该服务单元的用途，这里是 Kubernetes Kube Proxy。
# Documentation: 指定了该服务单元的文档地址，即 https://github.com/kubernetes/kubernetes。
# After: 指定该服务单元应在 network.target（网络目标）之后启动。
# [Service]
#
# ExecStart: 指定了启动 Kube Proxy 服务的命令。通过 /usr/local/bin/kube-proxy 命令启动，并指定了配置文件的路径为 /etc/kubernetes/kube-proxy.yaml，同时指定了日志级别为 2。
# Restart: 配置了服务在失败或退出后自动重启。
# RestartSec: 配置了重启间隔，这里是每次重启之间的等待时间为 10 秒。
# [Install]
#
# WantedBy: 指定了该服务单元的安装目标为 multi-user.target（多用户目标），表示该服务将在多用户模式下启动。
# 通过配置这些字段，你可以启动和管理 Kubernetes Kube Proxy 服务。请注意，你需要根据实际情况修改 ExecStart 中的路径和文件名，确保与你的环境一致。另外，可以根据需求修改其他字段的值，以满足你的特定要求。

8.3.3所有k8s节点添加kube-proxy的配置

代码语言：javascript
复制
cat > /etc/kubernetes/kube-proxy.yaml << EOF
apiVersion: kubeproxy.config.k8s.io/v1alpha1
bindAddress: 0.0.0.0
clientConnection:
  acceptContentTypes: ""
  burst: 10
  contentType: application/vnd.kubernetes.protobuf
  kubeconfig: /etc/kubernetes/kube-proxy.kubeconfig
  qps: 5
clusterCIDR: 172.16.0.0/16,fd00:2222::/112
configSyncPeriod: 15m0s
conntrack:
  max: null
  maxPerCore: 32768
  min: 131072
  tcpCloseWaitTimeout: 1h0m0s
  tcpEstablishedTimeout: 24h0m0s
enableProfiling: false
healthzBindAddress: 0.0.0.0:10256
hostnameOverride: ""
iptables:
  masqueradeAll: false
  masqueradeBit: 14
  minSyncPeriod: 0s
  syncPeriod: 30s
ipvs:
  masqueradeAll: true
  minSyncPeriod: 5s
  scheduler: "rr"
  syncPeriod: 30s
kind: KubeProxyConfiguration
metricsBindAddress: 127.0.0.1:10249
mode: "ipvs"
nodePortAddresses: null
oomScoreAdj: -999
portRange: ""
udpIdleTimeout: 250ms
EOF

8.3.4启动kube-proxy

代码语言：javascript
复制
 systemctl daemon-reload
systemctl enable --now kube-proxy.service
systemctl restart kube-proxy.service
systemctl status kube-proxy.service

9.安装网络插件

注意 9.1 和 9.2 二选其一即可，建议在此处创建好快照后在进行操作，后续出问题可以回滚

** centos7 要升级libseccomp 不然 无法安装网络插件**

代码语言：javascript
复制
# https://github.com/opencontainers/runc/releases
# 升级runc
# wget https://github.com/opencontainers/runc/releases/download/v1.1.12/runc.amd64

install -m 755 runc.amd64 /usr/local/sbin/runc
cp -p /usr/local/sbin/runc  /usr/local/bin/runc
cp -p /usr/local/sbin/runc  /usr/bin/runc

#查看当前版本
[root@k8s-master-1 ~]# rpm -qa | grep libseccomp
libseccomp-2.5.2-2.el9.x86_64

#下载高于2.4以上的包
# yum -y install http://rpmfind.net/linux/centos/8-stream/BaseOS/x86_64/os/Packages/libseccomp-2.5.1-1.el8.x86_64.rpm
# 清华源
# yum -y install https://mirrors.tuna.tsinghua.edu.cn/centos/8-stream/BaseOS/x86_64/os/Packages/libseccomp-2.5.1-1.el8.x86_64.rpm

9.1安装Calico

9.1.1更改calico网段

代码语言：javascript
复制
# 查看版本
https://github.com/projectcalico/calico/tags

# 安装operator
kubectl create -f https://raw.githubusercontent.com/projectcalico/calico/v3.32.0/manifests/tigera-operator.yaml

# 下载配置文件
curl https://raw.githubusercontent.com/projectcalico/calico/v3.32.0/manifests/custom-resources.yaml -O

# 修改地址池
vim custom-resources.yaml
apiVersion: operator.tigera.io/v1
kind: Installation
metadata:
  name: default
spec:
  calicoNetwork:
    ipPools:
    - name: default-ipv4-ippool
      blockSize: 26
      cidr: 172.16.0.0/16
      encapsulation: VXLANCrossSubnet
      natOutgoing: Enabled
      nodeSelector: all()

# 修改地址池
vim custom-resources.yaml
apiVersion: operator.tigera.io/v1
kind: Installation
metadata:
  name: default
spec:
  calicoNetwork:
    ipPools:
    - name: ipv4-ippool
      cidr: 172.16.0.0/16
      blockSize: 26
      # encapsulation: IPIP
      encapsulation: VXLANCrossSubnet
      natOutgoing: Enabled
      nodeSelector: all()
    - name: ipv6-ippool
      cidr: "fd00:2222::/112"
      blockSize: 122
      encapsulation: VXLANCrossSubnet
      natOutgoing: Enabled
      nodeSelector: all()
    nodeAddressAutodetectionV4:
      interface: "eth.*|en.*"
    nodeAddressAutodetectionV6:
      interface: "eth.*|en.*"


# 打开vxlan内核  适用于大多数使用 systemd 的发行版
echo "vxlan" | sudo tee /etc/modules-load.d/vxlan.conf
systemctl restart systemd-modules-load.service
lsmod | grep vxlan

# 执行安装
kubectl create -f custom-resources.yaml

# 安装客户端
curl -L https://github.com/projectcalico/calico/releases/download/v3.32.0/calicoctl-linux-amd64 -o calicoctl

# 给客户端添加执行权限
chmod +x ./calicoctl

# 查看集群节点
./calicoctl get nodes --allow-version-mismatch
# 查看集群节点状态
./calicoctl node status --allow-version-mismatch
#查看地址池
./calicoctl get ipPool --allow-version-mismatch
./calicoctl get ipPool --allow-version-mismatch -o yaml

9.1.2查看容器状态

代码语言：javascript
复制
# calico 初始化会很慢 需要耐心等待一下，大约十分钟左右
[root@k8s-master01 kubernetes-v1.36.0]# kubectl get pod -A
NAMESPACE         NAME                                       READY   STATUS    RESTARTS   AGE
calico-system     calico-apiserver-7bb46cd974-2tb62          1/1     Running   0          7m46s
calico-system     calico-apiserver-7bb46cd974-92p96          1/1     Running   0          7m46s
calico-system     calico-kube-controllers-7c4f878bd8-xptks   1/1     Running   0          7m45s
calico-system     calico-node-6wbsv                          1/1     Running   0          7m46s
calico-system     calico-node-djq59                          1/1     Running   0          7m46s
calico-system     calico-node-dm97b                          1/1     Running   0          7m46s
calico-system     calico-node-lvq6w                          1/1     Running   0          7m46s
calico-system     calico-node-pmq6v                          1/1     Running   0          7m46s
calico-system     calico-typha-758c8bf6f7-8tkss              1/1     Running   0          7m43s
calico-system     calico-typha-758c8bf6f7-dqsqq              1/1     Running   0          7m46s
calico-system     calico-typha-758c8bf6f7-h7569              1/1     Running   0          7m43s
calico-system     csi-node-driver-4rld6                      2/2     Running   0          7m45s
calico-system     csi-node-driver-8krh7                      2/2     Running   0          7m45s
calico-system     csi-node-driver-bvq9q                      2/2     Running   0          7m45s
calico-system     csi-node-driver-qcb9d                      2/2     Running   0          7m45s
calico-system     csi-node-driver-xkkcj                      2/2     Running   0          7m45s
calico-system     goldmane-6885dcb7d-k26sd                   1/1     Running   0          7m46s
calico-system     whisker-898cf7b47-75pdh                    2/2     Running   0          6m53s
tigera-operator   tigera-operator-85dbff4478-sntj6           1/1     Running   0          9m13s
[root@k8s-master01 kubernetes-v1.36.0]#

# IPIP模式 仅支持IPv4，不支持IPv6，有tun网口
[root@k8s-master01 ~]# route -n
Kernel IP routing table
Destination     Gateway         Genmask         Flags Metric Ref    Use Iface
0.0.0.0         192.168.1.1     0.0.0.0         UG    100    0        0 ens32
172.17.125.0    192.168.1.34    255.255.255.192 UG    0      0        0 tunl0
172.18.195.0    192.168.1.33    255.255.255.192 UG    0      0        0 tunl0
172.25.92.64    192.168.1.32    255.255.255.192 UG    0      0        0 tunl0
172.25.244.192  0.0.0.0         255.255.255.192 U     0      0        0 *
172.25.244.193  0.0.0.0         255.255.255.255 UH    0      0        0 calif3e9d7544a4
172.27.14.192   192.168.1.35    255.255.255.192 UG    0      0        0 tunl0
192.168.1.0     0.0.0.0         255.255.255.0   U     100    0        0 ens32
[root@k8s-master01 ~]#

# VXLANCrossSubnet模式，无tun网口
[root@k8s-master01 ~]# route -n
Kernel IP routing table
Destination     Gateway         Genmask         Flags Metric Ref    Use Iface
0.0.0.0         192.168.1.1     0.0.0.0         UG    100    0        0 ens32
172.16.32.128   0.0.0.0         255.255.255.192 U     0      0        0 *
172.16.32.129   0.0.0.0         255.255.255.255 UH    1024   0        0 calic9ff772e94d
172.16.58.192   192.168.1.35    255.255.255.192 UG    0      0        0 ens32
172.16.85.192   192.168.1.34    255.255.255.192 UG    0      0        0 ens32
172.16.122.128  192.168.1.32    255.255.255.192 UG    0      0        0 ens32
172.16.195.0    192.168.1.33    255.255.255.192 UG    0      0        0 ens32
172.17.0.0      0.0.0.0         255.255.0.0     U     0      0        0 docker0
192.168.1.0     0.0.0.0         255.255.255.0   U     100    0        0 ens32
[root@k8s-master01 ~]#

# 路由表
[root@k8s-master01 ~]# route  -n -4 -6  | grep  vxlan
fe80::/64                      ::                         U    256 1      0 vxlan.calico
fd00:100::88bd:e5c3:433c:2080/128 ::                         Un   0   2      0 vxlan-v6.calico
fe80::/128                     ::                         Un   0   3      0 vxlan.calico
fe80::6454:d1ff:fe67:d36d/128  ::                         Un   0   2      0 vxlan.calico
ff00::/8                       ::                         U    256 1      0 vxlan.calico
ff00::/8                       ::                         U    256 1      0 vxlan-v6.calico
[root@k8s-master01 ~]#

9.1.3删除

代码语言：javascript
复制
kubectl delete -f https://raw.githubusercontent.com/projectcalico/calico/v3.32.0/manifests/tigera-operator.yaml  --force --grace-period=0
kubectl delete -f https://raw.githubusercontent.com/projectcalico/calico/v3.32.0/manifests/custom-resources.yaml --force --grace-period=0
# 在所有主机上执行
modprobe -r ipip      # 删除 IPIP 模式虚拟网卡
modprobe -r vxlan     # 删除 VXLAN 模式虚拟网卡
# 在所有主机上执行
sudo rm -rf /etc/cni/net.d/*calico*
sudo rm -f /opt/cni/bin/calico*
sudo rm -f /usr/local/bin/calico*
sudo rm -rf /var/lib/cni/networks/calico/
# 在所有主机上执行
systemctl restart kubelet

9.2 安装cilium

9.2.1 安装helm

代码语言：javascript
复制
# [root@k8s-master01 ~]# curl -fsSL -o get_helm.sh https://raw.githubusercontent.com/helm/helm/main/scripts/get-helm-3
# [root@k8s-master01 ~]# chmod 700 get_helm.sh
# [root@k8s-master01 ~]# ./get_helm.sh

# wget https://get.helm.sh/helm-v4.0.4-linux-amd64.tar.gz
tar xvf helm-*-linux-amd64.tar.gz
cp linux-amd64/helm /usr/local/bin/

9.2.2 安装cilium

代码语言：javascript
复制
# 添加源
helm repo add cilium https://helm.cilium.io

# 修改为国内源
helm pull cilium/cilium
tar xvf cilium-*.tgz
cd cilium/

# sed -i "s#quay.io/#quay.m.daocloud.io/#g" values.yaml

# 默认参数安装
helm install  cilium ./cilium/ -n kube-system

helm install cilium cilium/cilium --version 1.19.3 -n kube-system

# 启用ipv6
# helm install cilium cilium/cilium -n kube-system --set ipv6.enabled=true

# 启用路由信息和监控插件
# helm install cilium ./cilium/ --namespace kube-system --set ipv6.enabled=true --set hubble.relay.enabled=true --set hubble.ui.enabled=true --set prometheus.enabled=true --set operator.prometheus.enabled=true --set hubble.enabled=true --set hubble.metrics.enabled="{dns,drop,tcp,flow,port-distribution,icmp,http}"

9.2.3 查看

代码语言：javascript
复制
[root@k8s-master01 ~]# kubectl  get pod -A | grep cil
NAMESPACE     NAME                               READY   STATUS    RESTARTS   AGE
kube-system   cilium-2tnfb                       1/1     Running   0          60s
kube-system   cilium-5tgcb                       1/1     Running   0          60s
kube-system   cilium-6shf5                       1/1     Running   0          60s
kube-system   cilium-ccbcx                       1/1     Running   0          60s
kube-system   cilium-cppft                       1/1     Running   0          60s
kube-system   cilium-operator-675f685d59-7q27q   1/1     Running   0          60s
kube-system   cilium-operator-675f685d59-kwmqz   1/1     Running   0          60s
[root@k8s-master01 ~]#

9.2.4 下载专属监控面板

安装时候没有创建 监控可以忽略

代码语言：javascript
复制
[root@k8s-master01 yaml]# wget https://raw.githubusercontent.com/cilium/cilium/1.19.3/examples/kubernetes/addons/prometheus/monitoring-example.yaml

[root@k8s-master01 yaml]# sed -i "s#docker.io/#jockerhub.com/#g" monitoring-example.yaml

[root@k8s-master01 yaml]# kubectl  apply -f monitoring-example.yaml
namespace/cilium-monitoring created
serviceaccount/prometheus-k8s created
configmap/grafana-config created
configmap/grafana-cilium-dashboard created
configmap/grafana-cilium-operator-dashboard created
configmap/grafana-hubble-dashboard created
configmap/prometheus created
clusterrole.rbac.authorization.k8s.io/prometheus created
clusterrolebinding.rbac.authorization.k8s.io/prometheus created
service/grafana created
service/prometheus created
deployment.apps/grafana created
deployment.apps/prometheus created
[root@k8s-master01 yaml]#

9.2.5 修改为NodePort

安装时候没有创建 监控可以忽略

代码语言：javascript
复制
[root@k8s-master01 yaml]# kubectl  edit svc  -n kube-system hubble-ui
service/hubble-ui edited
[root@k8s-master01 yaml]#
[root@k8s-master01 yaml]# kubectl  edit svc  -n cilium-monitoring grafana
service/grafana edited
[root@k8s-master01 yaml]#
[root@k8s-master01 yaml]# kubectl  edit svc  -n cilium-monitoring prometheus
service/prometheus edited
[root@k8s-master01 yaml]#

type: NodePort

9.2.6 查看端口

安装时候没有创建 监控可以忽略

代码语言：javascript
复制
[root@k8s-master01 yaml]# kubectl get svc -A | grep NodePort
cilium-monitoring   grafana          NodePort    10.111.74.3      <none>        3000:32648/TCP   74s
cilium-monitoring   prometheus       NodePort    10.107.240.124   <none>        9090:30495/TCP   74s
kube-system         hubble-ui        NodePort    10.96.185.26     <none>        80:31568/TCP     99s

9.2.7 访问

安装时候没有创建 监控可以忽略

代码语言：javascript
复制
http://192.168.1.31:32648
http://192.168.1.31:30495
http://192.168.1.31:31568

10.安装CoreDNS

10.1以下步骤只在master01操作

10.1.1修改文件

代码语言：javascript
复制
# 下载tgz包
helm repo add coredns https://coredns.github.io/helm
helm pull coredns/coredns
tar xvf coredns-*.tgz
cd coredns/

# 修改IP地址
vim values.yaml
cat values.yaml | grep clusterIP:
clusterIP: "10.96.0.10"

# 示例
---
service:
# clusterIP: ""
# clusterIPs: []
# loadBalancerIP: ""
# externalIPs: []
# externalTrafficPolicy: ""
# ipFamilyPolicy: ""
  # The name of the Service
  # If not set, a name is generated using the fullname template
  clusterIP: "10.96.0.10"
  name: ""
  annotations: {}
---

# 修改为国内源
sed -i "s#registry.k8s.io/#k8s.m.daocloud.io/#g" values.yaml

# 默认参数安装
helm install  coredns ./coredns/ -n kube-system

11.安装Metrics Server

11.1以下步骤只在master01操作

11.1.1安装Metrics-server

在新版的Kubernetes中系统资源的采集均使用Metrics-server，可以通过Metrics采集节点和Pod的内存、磁盘、CPU和网络的使用率

代码语言：javascript
复制
# 下载
wget https://github.com/kubernetes-sigs/metrics-server/releases/latest/download/components.yaml -O metrics-server.yaml

# 修改配置
vim metrics-server.yaml

---
#
    - args:
        - --cert-dir=/tmp
        - --kubelet-preferred-address-types=InternalIP,ExternalIP,Hostname
        - --kubelet-use-node-status-port
        - --metric-resolution=15s
        - --kubelet-insecure-tls
        - --requestheader-client-ca-file=/etc/kubernetes/pki/front-proxy-ca.pem
        - --requestheader-username-headers=X-Remote-User
        - --requestheader-group-headers=X-Remote-Group
        - --requestheader-extra-headers-prefix=X-Remote-Extra-

#
        volumeMounts:
        - mountPath: /tmp
          name: tmp-dir
        - name: ca-ssl
          mountPath: /etc/kubernetes/pki

#
      volumes:
      - emptyDir: {}
        name: tmp-dir
      - name: ca-ssl
        hostPath:
          path: /etc/kubernetes/pki
---


# 修改为国内源 docker源可选
sed -i "s#registry.k8s.io/#k8s.m.daocloud.io/#g" metrics-server.yaml

# 执行部署
kubectl apply -f metrics-server.yaml

11.1.2稍等片刻查看状态

代码语言：javascript
复制
kubectl  top node
NAME           CPU(cores)   CPU(%)   MEMORY(bytes)   MEMORY(%)
k8s-master01   182m         2%       2059Mi          58%
k8s-master02   104m         1%       1577Mi          44%
k8s-master03   113m         1%       1516Mi          42%
k8s-node01     53m          0%       915Mi           25%
k8s-node02     66m          0%       930Mi           26%

12.集群验证

12.1部署pod资源

代码语言：javascript
复制
cat<<EOF | kubectl apply -f -
apiVersion: v1
kind: Pod
metadata:
  name: busybox
  namespace: default
spec:
  containers:
  - name: busybox
    image: docker.m.daocloud.io/library/busybox:1.28
    command:
      - sleep
      - "3600"
    imagePullPolicy: IfNotPresent
  restartPolicy: Always
EOF

# 查看
kubectl  get pod
NAME      READY   STATUS    RESTARTS   AGE
busybox   1/1     Running   0          17s

12.2用pod解析默认命名空间中的kubernetes

代码语言：javascript
复制
# 查看name
kubectl get svc
NAME         TYPE        CLUSTER-IP   EXTERNAL-IP   PORT(S)   AGE
kubernetes   ClusterIP   10.96.0.1    <none>        443/TCP   17h

# 进行解析
kubectl exec  busybox -n default -- nslookup kubernetes
3Server:    10.96.0.10
Address 1: 10.96.0.10 kube-dns.kube-system.svc.cluster.local

Name:      kubernetes
Address 1: 10.96.0.1 kubernetes.default.svc.cluster.local

12.3测试跨命名空间是否可以解析

代码语言：javascript
复制
# 查看有那些name
kubectl  get svc -A
NAMESPACE     NAME              TYPE        CLUSTER-IP      EXTERNAL-IP   PORT(S)         AGE
default       kubernetes        ClusterIP   10.96.0.1       <none>        443/TCP         76m
kube-system   calico-typha      ClusterIP   10.105.100.82   <none>        5473/TCP        35m
kube-system   coredns-coredns   ClusterIP   10.96.0.10      <none>        53/UDP,53/TCP   8m14s
kube-system   metrics-server    ClusterIP   10.105.60.31    <none>        443/TCP         109s

# 进行解析
kubectl exec  busybox -n default -- nslookup coredns.kube-system
Server:    10.96.0.10
Address 1: 10.96.0.10 coredns-coredns.kube-system.svc.cluster.local

Name:      coredns-coredns.kube-system
Address 1: 10.96.0.10 coredns-coredns.kube-system.svc.cluster.local
[root@k8s-master01 metrics-server]#

12.4每个节点都必须要能访问Kubernetes的kubernetes svc 443和kube-dns的service 53

代码语言：javascript
复制
telnet 10.96.0.1 443
Trying 10.96.0.1...
Connected to 10.96.0.1.
Escape character is '^]'.

telnet 10.96.0.10 53
Trying 10.96.0.10...
Connected to 10.96.0.10.
Escape character is '^]'.

12.5Pod和Pod之前要能通

代码语言：javascript
复制
kubectl get po -owide
NAME      READY   STATUS    RESTARTS   AGE   IP              NODE         NOMINATED NODE   READINESS GATES
busybox   1/1     Running   0          17m   172.27.14.193   k8s-node02   <none>           <none>

kubectl get po -n kube-system -owide
NAME                                       READY   STATUS    RESTARTS   AGE     IP               NODE           NOMINATED NODE   READINESS GATES
calico-kube-controllers-76754ff848-pw4xg   1/1     Running   0          38m     172.25.244.193   k8s-master01   <none>           <none>
calico-node-97m55                          1/1     Running   0          38m     192.168.1.34     k8s-node01     <none>           <none>
calico-node-hlz7j                          1/1     Running   0          38m     192.168.1.32     k8s-master02   <none>           <none>
calico-node-jtlck                          1/1     Running   0          38m     192.168.1.33     k8s-master03   <none>           <none>
calico-node-lxfkf                          1/1     Running   0          38m     192.168.1.35     k8s-node02     <none>           <none>
calico-node-t667x                          1/1     Running   0          38m     192.168.1.31     k8s-master01   <none>           <none>
calico-typha-59d75c5dd4-gbhfp              1/1     Running   0          38m     192.168.1.35     k8s-node02     <none>           <none>
coredns-coredns-c5c6d4d9b-bd829            1/1     Running   0          10m     172.25.92.65     k8s-master02   <none>           <none>
metrics-server-7c8b55c754-w7q8v            1/1     Running   0          3m56s   172.17.125.3     k8s-node01     <none>           <none>

# 进入busybox ping其他节点上的pod

kubectl exec -ti busybox -- sh
/ # ping 192.168.1.34
PING 192.168.1.34 (192.168.1.34): 56 data bytes
64 bytes from 192.168.1.34: seq=0 ttl=63 time=0.358 ms
64 bytes from 192.168.1.34: seq=1 ttl=63 time=0.668 ms
64 bytes from 192.168.1.34: seq=2 ttl=63 time=0.637 ms
64 bytes from 192.168.1.34: seq=3 ttl=63 time=0.624 ms
64 bytes from 192.168.1.34: seq=4 ttl=63 time=0.907 ms

# 可以连通证明这个pod是可以跨命名空间和跨主机通信的

12.6创建三个副本，可以看到3个副本分布在不同的节点上（用完可以删了）

代码语言：javascript
复制
cat<<EOF | kubectl apply -f -
apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx-deployment
  labels:
    app: nginx
spec:
  replicas: 3
  selector:
    matchLabels:
      app: nginx
  template:
    metadata:
      labels:
        app: nginx
    spec:
      containers:
      - name: nginx
        image: nginx
        ports:
        - containerPort: 80
EOF

kubectl  get pod
NAME                               READY   STATUS    RESTARTS   AGE
busybox                            1/1     Running   0          6m25s
nginx-deployment-9456bbbf9-4bmvk   1/1     Running   0          8s
nginx-deployment-9456bbbf9-9rcdk   1/1     Running   0          8s
nginx-deployment-9456bbbf9-dqv8s   1/1     Running   0          8s

# 删除nginx
[root@k8s-master01 ~]# kubectl delete deployments nginx-deployment

13.安装 Headlamp

代码语言：javascript
复制
helm repo add headlamp https://kubernetes-sigs.github.io/headlamp/
helm install my-headlamp headlamp/headlamp --namespace kube-system

13.1更改 Headlamp 的svc为NodePort

代码语言：javascript
复制
[root@k8s-master01 ~]# kubectl edit svc  -n kube-system my-headlamp
  type: NodePort

[root@k8s-master01 ~]# kubectl get svc -A | grep headlamp
kube-system     my-headlamp                       NodePort    10.96.242.100     <none>        80:31715/TCP    20s
[root@k8s-master01 ~]#

13.2创建 token

代码语言：javascript
复制
kubectl create token my-headlamp --namespace kube-system

eyJhbGciOiJSUzI1NiIsImtpZCI6ImU1Z2RQTWFxRTh0aTNJRFI0c0pSUXM0bkVyOEp5V2tZRXpPdGw4TnBaQnMifQ.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.jxhOecRIUL9dNrnImdZODmuSg1vpgQV4Cuup3vJe5fwmhs2QzdRd7jQ9gd-n430QWakhp9hZBt68oRaiJMxiASDsXZz8VNi_KIMoWn9AnQ_at7aoqLtZia2l0Q82PcUEOq6gB3kSH9saIEgmDwiinRv2KDpxYPZ3myAWoUXU-aUHNG2qlx0I87TkaIkqxVmvVk_AZYipuNrAZfoJDU3-A9l8e15w1IqOR84AH2svJNp9R2D5KZaRFRu3a7Z3ikFukRGx54dJdpgWlTYslRqNDtG9k5VoJPMFvnYRCI4NDuJgyanPx3aC1EqLSJ9aayb2OdcrrZM8yAdnF_z_i1993w

13.5登录 Headlamp

http://192.168.1.31:31715/

14.部署metallb

14.1 下载部署

代码语言：javascript
复制
# 下载应用包
wget https://raw.githubusercontent.com/metallb/metallb/v0.15.3/config/manifests/metallb-native.yaml

# 修改镜像地址
# 自行找代理
sed -i "s#quay.io#quay.chenby.cn#g" metallb-native.yaml
cat metallb-native.yaml | grep image
        image: quay.chenby.cn/metallb/controller:v0.14.5
        image: quay.chenby.cn/metallb/speaker:v0.14.5

# 执行部署
kubectl apply -f metallb-native.yaml

# 可以连接国际网络
# kubectl apply -f https://raw.githubusercontent.com/metallb/metallb/v0.15.3/config/manifests/metallb-native.yaml

14.2 查看运行情况

代码语言：javascript
复制
[root@k8s-master01 yaml]# kubectl -n metallb-system get all
NAME                              READY   STATUS    RESTARTS      AGE
pod/controller-6dd55858b4-g6dm2   1/1     Running   1 (11m ago)   12m
pod/speaker-2z5hf                 1/1     Running   0             12m
pod/speaker-fbq8s                 1/1     Running   0             12m
pod/speaker-nmlxx                 1/1     Running   0             12m
pod/speaker-sbl4d                 1/1     Running   0             12m
pod/speaker-xr4bd                 1/1     Running   0             12m

NAME                              TYPE        CLUSTER-IP       EXTERNAL-IP   PORT(S)   AGE
service/metallb-webhook-service   ClusterIP   10.110.219.226   <none>        443/TCP   12m

NAME                     DESIRED   CURRENT   READY   UP-TO-DATE   AVAILABLE   NODE SELECTOR            AGE
daemonset.apps/speaker   5         5         5       5            5           kubernetes.io/os=linux   12m

NAME                         READY   UP-TO-DATE   AVAILABLE   AGE
deployment.apps/controller   1/1     1            1           12m

NAME                                    DESIRED   CURRENT   READY   AGE
replicaset.apps/controller-6dd55858b4   1         1         1       12m
[root@k8s-master01 yaml]#

14.3 配置VIP的资源池

代码语言：javascript
复制
# 新版本metallb使用了CR（Custom Resources），这里我们通过IPAddressPool的CR，进行地址池的定义。
# 如果实例中不设置IPAddressPool选择器L2Advertisement；那么L2Advertisement默认为该实例所有的IPAddressPool相关联。

cat > metallb-config-ipaddresspool.yaml << EOF
apiVersion: metallb.io/v1beta1
kind: IPAddressPool
metadata:
  name: first-pool
  namespace: metallb-system
spec:
  addresses:
  - 192.168.1.71-192.168.1.75
EOF

# 进行L2关联地址池的绑定。

cat > metallb-config-L2Advertisement.yaml << EOF
apiVersion: metallb.io/v1beta1
kind: L2Advertisement
metadata:
  name: example
  namespace: metallb-system
spec:
  ipAddressPools:
  - first-pool
EOF

# 执行部署
kubectl apply -f metallb-config-ipaddresspool.yaml
kubectl apply -f metallb-config-L2Advertisement.yaml

15.安装 Envoy Gateway

15.1执行部署

代码语言：javascript
复制
# https://gateway.envoyproxy.io/docs/install/install-helm/
# 安装网关 API CRD 和 Envoy 网关
helm install eg oci://docker.io/envoyproxy/gateway-helm --version v1.7.3 -n envoy-gateway-system --create-namespace

15.2创建测试应用

代码语言：javascript
复制
kubectl apply -f https://github.com/envoyproxy/gateway/releases/download/v1.7.3/quickstart.yaml -n default

# 查看访问地址
[root@k8s-master01 ~]# kubectl get svc -n envoy-gateway-system
NAME                        TYPE           CLUSTER-IP       EXTERNAL-IP    PORT(S)                                            AGE
envoy-default-eg-e41e7b31   LoadBalancer   10.100.111.66    192.168.1.71   80:30208/TCP                                       3m16s
envoy-gateway               ClusterIP      10.103.128.149   <none>         18000/TCP,18001/TCP,18002/TCP,19001/TCP,9443/TCP   5m19s
[root@k8s-master01 ~]#

15.3测试访问

代码语言：javascript
复制
curl --verbose --header "Host: www.example.com" http://192.168.1.71/get

16.IPv6测试

代码语言：javascript
复制
#部署应用

cat<<EOF | kubectl apply -f -
apiVersion: apps/v1
kind: Deployment
metadata:
  name: chenby
spec:
  replicas: 1
  selector:
    matchLabels:
      app: chenby
  template:
    metadata:
      labels:
        app: chenby
    spec:
      hostNetwork: true
      containers:
      - name: chenby
        image: docker.io/library/nginx
        resources:
          limits:
            memory: "128Mi"
            cpu: "500m"
        ports:
        - containerPort: 80
---
apiVersion: v1
kind: Service
metadata:
  name: chenby
spec:
  ipFamilyPolicy: PreferDualStack
  ipFamilies:
  - IPv6
  - IPv4
  type: NodePort
  selector:
    app: chenby
  ports:
  - port: 80
    targetPort: 80
EOF


#查看端口
[root@k8s-master01 ~]# kubectl  get svc
NAME           TYPE        CLUSTER-IP        EXTERNAL-IP   PORT(S)        AGE
chenby         NodePort    fd00:1111::4c64   <none>        80:30923/TCP   5s

[root@k8s-master01 ~]#

# 直接访问POD地址
[root@k8s-master01 ~]# curl -I http://[fd00:1111::4c64]
HTTP/1.1 200 OK
Server: nginx/1.29.1
Date: Sun, 31 Aug 2025 04:14:38 GMT
Content-Type: text/html
Content-Length: 615
Last-Modified: Wed, 13 Aug 2025 14:33:41 GMT
Connection: keep-alive
ETag: "689ca245-267"
Accept-Ranges: bytes



# 使用IPv4地址访问测试
[root@k8s-master01 ~]# curl -I http://192.168.1.31:30923
HTTP/1.1 200 OK
Server: nginx/1.29.1
Date: Sun, 31 Aug 2025 04:15:05 GMT
Content-Type: text/html
Content-Length: 615
Last-Modified: Wed, 13 Aug 2025 14:33:41 GMT
Connection: keep-alive
ETag: "689ca245-267"
Accept-Ranges: bytes


# 使用主机的内网IPv6地址测试
[root@k8s-master01 ~]# curl -I http://[fc00::31]:30923
HTTP/1.1 200 OK
Server: nginx/1.29.1
Date: Sun, 31 Aug 2025 04:15:23 GMT
Content-Type: text/html
Content-Length: 615
Last-Modified: Wed, 13 Aug 2025 14:33:41 GMT
Connection: keep-alive
ETag: "689ca245-267"
Accept-Ranges: bytes


# 使用主机的公网IPv6地址测试
[root@k8s-master01 ~]# curl -I http://[2409:8a10:6d0:a071:601f:ae96:9f4f:403d]:30923
HTTP/1.1 200 OK
Server: nginx/1.29.1
Date: Sun, 31 Aug 2025 04:16:16 GMT
Content-Type: text/html
Content-Length: 615
Last-Modified: Wed, 13 Aug 2025 14:33:41 GMT
Connection: keep-alive
ETag: "689ca245-267"
Accept-Ranges: bytes

17.安装NFS动态存储

代码语言：javascript
复制
# 安装nfs
# CentOS
yum install -y nfs-utils

# Ubuntu
apt install nfs-kernel-server nfs-common

# 创建共享
mkdir /nfs

# 编辑共享
vim /etc/exports
/nfs *(rw,sync,no_root_squash,no_subtree_check)


# centos
systemctl enable rpcbind.service
systemctl enable nfs-server.service
systemctl restart rpcbind.service
systemctl restart nfs-server.service

# ubuntu
systemctl enable nfs-kernel-server
systemctl restart nfs-kernel-server

# 加载配置
exportfs -a
exportfs -r
exportfs


# 添加仓库
helm repo add nfs-subdir-external-provisioner https://kubernetes-sigs.github.io/nfs-subdir-external-provisioner/
# --set nfs.server 填写你的nfs服务器地址
# --set nfs.path 填写你的nfs服务器路径
helm install -n kube-system nfs-subdir-external-provisioner nfs-subdir-external-provisioner/nfs-subdir-external-provisioner \
    --set storageClass.defaultClass=true \
    --set nfs.server=192.168.1.31 \
    --set nfs.path=/nfs

# 查看是否为默认存储
[root@k8s-master01 ~]# kubectl get storageclasses.storage.k8s.io
NAME                   PROVISIONER                                     RECLAIMPOLICY   VOLUMEBINDINGMODE   ALLOWVOLUMEEXPANSION   AGE
nfs-client (default)   cluster.local/nfs-subdir-external-provisioner   Delete          Immediate           true                   123m
[root@k8s-master01 ~]#

17.1 测试

代码语言：javascript
复制
# 创建PVC需求
cat >> pvc.yaml <<EOF
kind: PersistentVolumeClaim
apiVersion: v1
metadata:
  name: nginx-pvc
spec:
  accessModes:
    - ReadWriteMany
  resources:
    requests:
      storage: 200Mi
EOF
# 执行部署
kubectl apply -f pvc.yaml

[root@k8s-master01 ~]# kubectl  get pvc
NAME        STATUS   VOLUME                                     CAPACITY   ACCESS MODES   STORAGECLASS   VOLUMEATTRIBUTESCLASS   AGE
nginx-pvc   Bound    pvc-f448b2b0-9778-4220-a4f8-97a3dc8b1d3a   200Mi      RWX            nfs-client     <unset>                 33s
[root@k8s-master01 ~]#

[root@k8s-master01 ~]# kubectl  get pv
NAME                                       CAPACITY   ACCESS MODES   RECLAIM POLICY   STATUS   CLAIM               STORAGECLASS   VOLUMEATTRIBUTESCLASS   REASON   AGE
pvc-f448b2b0-9778-4220-a4f8-97a3dc8b1d3a   200Mi      RWX            Delete           Bound    default/nginx-pvc   nfs-client     <unset>                          23s
[root@k8s-master01 ~]#

18.污点

代码语言：javascript
复制
# 查看当前污点状态
[root@k8s-master01 ~]# kubectl describe node  | grep Taints
Taints:             <none>
Taints:             <none>
Taints:             <none>
Taints:             <none>
Taints:             <none>

# 设置污点 禁止调度 同时进行驱赶现有的POD
kubectl taint nodes k8s-master01 key1=value1:NoExecute
kubectl taint nodes k8s-master02 key1=value1:NoExecute
kubectl taint nodes k8s-master03 key1=value1:NoExecute

# 取消污点
kubectl taint nodes k8s-master01 key1=value1:NoExecute-
kubectl taint nodes k8s-master02 key1=value1:NoExecute-
kubectl taint nodes k8s-master03 key1=value1:NoExecute-

# 设置污点 禁止调度 不进行驱赶现有的POD
kubectl taint nodes k8s-master01 key1=value1:NoSchedule
kubectl taint nodes k8s-master02 key1=value1:NoSchedule
kubectl taint nodes k8s-master03 key1=value1:NoSchedule

# 取消污点
kubectl taint nodes k8s-master01 key1=value1:NoSchedule-
kubectl taint nodes k8s-master02 key1=value1:NoSchedule-
kubectl taint nodes k8s-master03 key1=value1:NoSchedule-

19.安装命令行自动补全功能

代码语言：javascript
复制
yum install bash-completion -y
source /usr/share/bash-completion/bash_completion
source <(kubectl completion bash)
echo "source <(kubectl completion bash)" >> ~/.bashrc

附录

代码语言：javascript
复制
详见完整版 https://github.com/cby-chen/Kubernetes
本文参与 腾讯云自媒体同步曝光计划，分享自微信公众号。
原始发表：2026-05-11，如有侵权请联系 cloudcommunity@tencent.com 删除
二进制
高可用
配置
kubernetes
etcd

本文分享自 小陈运维 微信公众号，前往查看

如有侵权，请联系 cloudcommunity@tencent.com 删除。

本文参与 腾讯云自媒体同步曝光计划  ，欢迎热爱写作的你一起参与！

二进制
高可用
配置
kubernetes
etcd
评论
登录后参与评论
0 条评论
热度
最新
登录 后参与评论
推荐阅读
目录
  • 介绍
    • kubernetes（k8s）二进制高可用安装部署，支持IPv4+IPv6双栈。
    • 强烈建议在Github上查看文档 ！！！
    • Github出问题会更新文档，并且后续尽可能第一时间更新新版本文档 ！！！
    • 手动项目地址：https://github.com/cby-chen/Kubernetes
  • 1.环境
    • 1.1.k8s基础系统环境配置
      • 1.2.配置IP
      • 1.3.设置主机名
      • 1.4.配置yum源
      • 1.5.安装一些必备工具
      • 1.6.选择性下载需要工具
      • 1.7.关闭防火墙
      • 1.8.关闭SELinux
      • 1.9.关闭交换分区
      • 1.10.网络配置（俩种方式二选一）
      • 1.11.进行时间同步
      • 1.12.配置ulimit
      • 1.13.配置免密登录
      • 1.14.添加启用源
      • 1.15.升级内核至4.18版本以上（若内核版本不够执行升级）
      • 1.16.安装ipvsadm
      • 1.17.修改内核参数
      • 1.18.所有节点配置hosts本地解析
  • 2.k8s基本组件安装
    • 2.1.安装Containerd作为Runtime
      • 2.1.1配置Containerd所需的模块
      • 2.1.2加载模块
      • 2.1.3配置Containerd所需的内核
      • 2.1.4创建Containerd的配置文件
      • 2.1.5启动并设置为开机启动
      • 2.1.6配置crictl客户端连接的运行时位置
    • 2.2 安装docker作为Runtime
      • 2.2.1 解压docker程序
      • 2.2.2 创建containerd的service文件
      • 2.2.3 准备docker的service文件
      • 2.2.4 准备docker的socket文件
      • 2.2.5 配置加速器
      • 2.2.6 启动docker
      • 2.2.7 解压cri-docker
      • 2.2.8 写入启动cri-docker配置文件
      • 2.2.9 写入cri-docker的socket配置文件
      • 2.2.10 启动cri-docker
    • 2.3.k8s与etcd下载及安装（仅在master01操作）
      • 2.3.1解压k8s安装包
      • 2.3.2查看版本
      • 2.3.3将组件发送至其他k8s节点
    • 2.3创建证书相关文件
  • 3.相关证书生成
    • 3.1.生成etcd证书
      • 3.1.1所有master节点创建证书存放目录
      • 3.1.2master01节点生成etcd证书
      • 3.1.3将证书复制到其他节点
    • 3.2.生成k8s相关证书
      • 3.2.1 所有k8s节点创建证书存放目录
      • 3.2.2 master01节点生成k8s证书
      • 3.2.3 生成apiserver聚合证书
      • 3.2.4 生成controller-manage的证书
      • 3.2.5 生成kube-scheduler的证书
      • 3.2.6 生成admin的证书配置
      • 3.2.7 创建kube-proxy证书
      • 3.2.8 创建ServiceAccount Key ——secret
      • 3.2.9 将证书发送到其他master节点
      • 3.2.10 查看证书
  • 4.k8s系统组件配置
    • 4.1.etcd配置
      • 4.1.1master01配置
      • 4.1.2master02配置
      • 4.1.3master03配置
    • 4.2.创建service（所有master节点操作）
      • 4.2.1创建etcd.service并启动
      • 4.2.2创建etcd证书目录
      • 4.2.3查看etcd状态
  • 5.高可用配置（在Master服务器上操作）
    • 5.1 NGINX高可用方案
      • 5.1.1 进行编译
      • 5.1.2 写入启动配置
    • 5.2 keepalived和haproxy 高可用方案
      • 5.2.1安装keepalived和haproxy服务
      • 5.2.2修改haproxy配置文件（配置文件一样）
      • 5.2.3Master01配置keepalived master节点
      • 5.2.4Master02配置keepalived backup节点
      • 5.2.5Master03配置keepalived backup节点
      • 5.2.6健康检查脚本配置（lb主机）
      • 5.2.7启动服务
      • 5.2.8测试高可用
  • 6.k8s组件配置
    • 6.1.创建apiserver（所有master节点）
      • 6.1.1master01节点配置
      • 6.1.2master02节点配置
      • 6.1.3master03节点配置
      • 6.1.4启动apiserver（所有master节点）
    • 6.2.配置kube-controller-manager service
      • 6.2.1启动kube-controller-manager，并查看状态
    • 6.3.配置kube-scheduler service
      • 6.3.1所有master节点配置，且配置相同
      • 6.3.2启动并查看服务状态
  • 7.TLS Bootstrapping配置
    • 7.1在master01上配置
    • 7.2查看集群状态，没问题的话继续后续操作
  • 8.node节点配置
    • 8.1.在master01上将证书复制到node节点
    • 8.2.kubelet配置
      • 8.2.1配置kubelet
      • 8.2.2所有k8s节点创建kubelet的配置文件
      • 当使用docker作为Runtime
      • 8.2.3当使用Containerd作为Runtime
      • 8.2.4启动kubelet
      • 8.2.5查看集群
      • 8.2.6查看容器运行时
    • 8.3.kube-proxy配置
      • 8.3.1将kubeconfig发送至其他节点
      • 8.3.2所有k8s节点添加kube-proxy的service文件
      • 8.3.3所有k8s节点添加kube-proxy的配置
      • 8.3.4启动kube-proxy
  • 9.安装网络插件
    • 9.1安装Calico
      • 9.1.1更改calico网段
      • 9.1.2查看容器状态
      • 9.1.3删除
    • 9.2 安装cilium
      • 9.2.1 安装helm
      • 9.2.2 安装cilium
      • 9.2.3 查看
      • 9.2.4 下载专属监控面板
      • 9.2.5 修改为NodePort
      • 9.2.6 查看端口
      • 9.2.7 访问
  • 10.安装CoreDNS
    • 10.1以下步骤只在master01操作
      • 10.1.1修改文件
  • 11.安装Metrics Server
    • 11.1以下步骤只在master01操作
      • 11.1.1安装Metrics-server
      • 11.1.2稍等片刻查看状态
  • 12.集群验证
    • 12.1部署pod资源
    • 12.2用pod解析默认命名空间中的kubernetes
    • 12.3测试跨命名空间是否可以解析
    • 12.4每个节点都必须要能访问Kubernetes的kubernetes svc 443和kube-dns的service 53
    • 12.5Pod和Pod之前要能通
    • 12.6创建三个副本，可以看到3个副本分布在不同的节点上（用完可以删了）
  • 13.安装 Headlamp
    • 13.1更改 Headlamp 的svc为NodePort
    • 13.2创建 token
    • 13.5登录 Headlamp
  • 14.部署metallb
    • 14.1 下载部署
    • 14.2 查看运行情况
    • 14.3 配置VIP的资源池
  • 15.安装 Envoy Gateway
    • 15.1执行部署
    • 15.2创建测试应用
    • 15.3测试访问
  • 16.IPv6测试
  • 17.安装NFS动态存储
  • 17.1 测试
  • 18.污点
  • 19.安装命令行自动补全功能
  • 附录
领券

腾讯云开发者

扫码关注腾讯云开发者

扫码关注腾讯云开发者

领取腾讯云代金券

热门产品

热门推荐

更多推荐

Copyright © 2013 - 2026 Tencent Cloud. All Rights Reserved. 腾讯云 版权所有

深圳市腾讯计算机系统有限公司 ICP备案/许可证号：粤B2-20090059 粤公网安备44030502008569号

腾讯云计算（北京）有限责任公司 京ICP证150476号 |  京ICP备11018762号

问题归档专栏文章快讯文章归档关键词归档开发者手册归档开发者手册 Section 归档

Copyright © 2013 - 2026 Tencent Cloud.

All Rights Reserved. 腾讯云 版权所有

登录 后参与评论
