Power BI 电梯动画箭头

SVG.电梯箭头 =
VAR _UP = "
  <rect x='40' y='0' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='30' y='10' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='40' y='10' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='50' y='10' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='20' y='20' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='30' y='20' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='40' y='20' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='50' y='20' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='60' y='20' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='10' y='30' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='20' y='30' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='30' y='30' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='40' y='30' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='50' y='30' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='60' y='30' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='70' y='30' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='30' y='40' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='40' y='40' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='50' y='40' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='30' y='50' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='40' y='50' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='50' y='50' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='30' y='60' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='40' y='60' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='50' y='60' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='30' y='70' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='40' y='70' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='50' y='70' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='30' y='80' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='40' y='80' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <rect x='50' y='80' width='10' height='10' fill='rgb(60, 141, 7)'/>
  <g stroke='rgb(255, 255, 255)' stroke-width='1'>
    <line x1='0' y1='0' x2='0' y2='90'/>
    <line x1='10' y1='0' x2='10' y2='90'/>
    <line x1='20' y1='0' x2='20' y2='90'/>
    <line x1='30' y1='0' x2='30' y2='90'/>
    <line x1='40' y1='0' x2='40' y2='90'/>
    <line x1='50' y1='0' x2='50' y2='90'/>
    <line x1='60' y1='0' x2='60' y2='90'/>
    <line x1='70' y1='0' x2='70' y2='90'/>
    <line x1='80' y1='0' x2='80' y2='90'/>
    <line x1='90' y1='0' x2='90' y2='90'/>
    <line x1='0' y1='0' x2='90' y2='0'/>
    <line x1='0' y1='10' x2='90' y2='10'/>
    <line x1='0' y1='20' x2='90' y2='20'/>
    <line x1='0' y1='30' x2='90' y2='30'/>
    <line x1='0' y1='40' x2='90' y2='40'/>
    <line x1='0' y1='50' x2='90' y2='50'/>
    <line x1='0' y1='60' x2='90' y2='60'/>
    <line x1='0' y1='70' x2='90' y2='70'/>
    <line x1='0' y1='80' x2='90' y2='80'/>
    <line x1='0' y1='90' x2='90' y2='90'/>
  </g>"
VAR _Down = "
    <rect x='30' y='0' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='40' y='0' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='50' y='0' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='30' y='10' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='40' y='10' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='50' y='10' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='30' y='20' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='40' y='20' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='50' y='20' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='30' y='30' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='40' y='30' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='50' y='30' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='30' y='40' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='40' y='40' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='50' y='40' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='10' y='50' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='20' y='50' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='30' y='50' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='40' y='50' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='50' y='50' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='60' y='50' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='70' y='50' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='20' y='60' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='30' y='60' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='40' y='60' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='50' y='60' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='60' y='60' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='30' y='70' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='40' y='70' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='50' y='70' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <rect x='40' y='80' width='10' height='10' fill='rgb(229, 11, 11)'/>
    <g stroke='rgb(255, 255, 255)' stroke-width='1'>
        <line x1='0' y1='0' x2='0' y2='90'/>
        <line x1='10' y1='0' x2='10' y2='90'/>
        <line x1='20' y1='0' x2='20' y2='90'/>
        <line x1='30' y1='0' x2='30' y2='90'/>
        <line x1='40' y1='0' x2='40' y2='90'/>
        <line x1='50' y1='0' x2='50' y2='90'/>
        <line x1='60' y1='0' x2='60' y2='90'/>
        <line x1='70' y1='0' x2='70' y2='90'/>
        <line x1='80' y1='0' x2='80' y2='90'/>
        <line x1='90' y1='0' x2='90' y2='90'/>
        <line x1='0' y1='0' x2='90' y2='0'/>
        <line x1='0' y1='10' x2='90' y2='10'/>
        <line x1='0' y1='20' x2='90' y2='20'/>
        <line x1='0' y1='30' x2='90' y2='30'/>
        <line x1='0' y1='40' x2='90' y2='40'/>
        <line x1='0' y1='50' x2='90' y2='50'/>
        <line x1='0' y1='60' x2='90' y2='60'/>
        <line x1='0' y1='70' x2='90' y2='70'/>
        <line x1='0' y1='80' x2='90' y2='80'/>
        <line x1='0' y1='90' x2='90' y2='90'/>
    </g>"
RETURN
    <g>
        <animateTransform attributeName='transform' type='translate'
        from='0 " & IF([M.增长率]>0,90,-90) & "' to='0 " & IF([M.增长率]>0,-90,90) & "'
        dur='2s' repeatCount='indefinite' />"
        & IF([M.增长率]>0,_UP,_Down) & "
    </g>
</svg>"
