基于 Raw Socket 的以太网温湿度传感器 UDP 报文监听：绕过应用层直接解析负载

┌─────────────────────────────────────────────────────────────┐
│  以太网帧头 (14 bytes)                                      │
│  DST MAC (6) | SRC MAC (6) | EtherType (2) = 0x0800       │
├─────────────────────────────────────────────────────────────┤
│  IP 头 (20 bytes, 不含选项)                                  │
│  Ver/IHL | TOS | Total Len | ID | Flags/Offset             │
│  TTL | Protocol (17=UDP) | Header Checksum                 │
│  Src IP (4) | Dst IP (4)                                    │
├─────────────────────────────────────────────────────────────┤
│  UDP 头 (8 bytes)                                           │
│  Src Port (2) | Dst Port (2) = 502                         │
│  Length (2) | Checksum (2)                                  │
├─────────────────────────────────────────────────────────────┤
│  Modbus TCP ADU (变长)                                      │
│  Transaction ID (2) | Protocol ID (2) = 0x0000             │
│  Length (2) | Unit ID (1)                                   │
├─────────────────────────────────────────────────────────────┤
│  Modbus PDU (变长)                                          │
│  Function Code (1) = 0x04 (读输入寄存器)                    │
│  Byte Count (1)                                             │
│  Register Values (N × 2 bytes)                              │
│    ├── 寄存器 0: 温度 ×10, INT16                            │
│    ├── 寄存器 1: 湿度 ×10, INT16                            │
│    └── 寄存器 2: 露点 ×10, INT16                            │
└─────────────────────────────────────────────────────────────┘

#!/usr/bin/env python3
"""
raw_udp_listener.py - 基于 Raw Socket 的 UDP 报文监听与 Modbus 负载解析
"""

import socket
import struct
import binascii
import logging
from datetime import datetime

logging.basicConfig(
    level=logging.INFO,
    format='%(asctime)s [%(levelname)s] %(message)s'
)

# ---------- 全局配置 ----------
LISTEN_IP = "0.0.0.0"          # 监听所有接口
TARGET_PORT = 502               # Modbus 默认端口
BUFFER_SIZE = 65535             # 最大 IP 包大小


def create_raw_socket():
    """
    创建 IP Raw Socket，监听 UDP 协议。

    注意：
    - Linux 需要 CAP_NET_RAW 权限（root 或 setcap）
    - IP_HDRINCL 告诉内核我们收到的报文包含 IP 头
    """
    try:
        sock = socket.socket(
            socket.AF_INET,      # IPv4
            socket.SOCK_RAW,      # Raw Socket
            socket.IPPROTO_UDP    # 只接收 UDP 报文
        )
    except PermissionError:
        logging.error("需要 root 权限或 CAP_NET_RAW 能力")
        raise
    except socket.error as e:
        logging.error(f"创建 Raw Socket 失败: {e}")
        raise

    # 设置 IP_HDRINCL，让 recvfrom 返回包含 IP 头的完整报文
    sock.setsockopt(socket.IPPROTO_IP, socket.IP_HDRINCL, 1)

    # 设置接收缓冲区（高吞吐场景）
    sock.setsockopt(socket.SOL_SOCKET, socket.SO_RCVBUF, 8 * 1024 * 1024)

    # 绑定（Raw Socket 绑定 IP 而非端口）
    sock.bind((LISTEN_IP, 0))

    logging.info(f"Raw Socket 已创建，监听 UDP 流量 (端口过滤在应用层完成)")
    return sock

def parse_ip_header(data: bytes) -> tuple:
    """
    解析 IPv4 头部，返回 (src_ip, dst_ip, protocol, header_len, total_len)

    IP 头结构（前 20 字节）：
    Byte 0:  Ver(4) + IHL(4)
    Byte 1:  TOS
    Byte 2-3: Total Length (16 bits, big-endian)
    Byte 4-5: Identification
    Byte 6-7: Flags(3) + Fragment Offset(13)
    Byte 8:   TTL
    Byte 9:   Protocol (17=UDP)
    Byte 10-11: Header Checksum
    Byte 12-15: Source IP
    Byte 16-19: Destination IP
    """
    if len(data) < 20:
        return None

    ver_ihl = data[0]
    version = ver_ihl >> 4
    ihl = ver_ihl & 0x0F
    header_len = ihl * 4  # IHL 单位是 32-bit word

    total_len = struct.unpack(">H", data[2:4])[0]
    protocol = data[9]

    src_ip = socket.inet_ntoa(data[12:16])
    dst_ip = socket.inet_ntoa(data[16:20])

    return src_ip, dst_ip, protocol, header_len, total_len

def parse_udp_header(data: bytes, ip_header_len: int) -> tuple:
    """
    解析 UDP 头部，返回 (src_port, dst_port, udp_len, udp_checksum, payload)

    UDP 头结构（8 字节）：
    Byte 0-1: Source Port
    Byte 2-3: Destination Port
    Byte 4-5: Length (UDP 头 + 载荷)
    Byte 6-7: Checksum
    """
    udp_offset = ip_header_len
    if len(data) < udp_offset + 8:
        return None

    src_port, dst_port, udp_len, udp_checksum = struct.unpack(
        ">HHHH", data[udp_offset:udp_offset + 8]
    )

    payload_offset = udp_offset + 8
    payload = data[payload_offset:]

    return src_port, dst_port, udp_len, udp_checksum, payload

def parse_modbus_adu(payload: bytes) -> dict | None:
    """
    解析 Modbus TCP ADU (7 字节 MBAP + PDU)

    MBAP:
    - Transaction ID (2 bytes)
    - Protocol ID (2 bytes, 0x0000)
    - Length (2 bytes, 后续字节数)
    - Unit ID (1 byte)

    PDU (Function Code + Data):
    - 0x03: 读保持寄存器
    - 0x04: 读输入寄存器
    """
    if len(payload) < 8:
        return None

    tid, proto_id, length, unit_id = struct.unpack(">HHHB", payload[:7])
    pdu = payload[7:]

    if len(pdu) < 2:
        return None

    func_code = pdu[0]

    # 异常响应检测
    if func_code & 0x80:
        exception_code = pdu[1] if len(pdu) > 1 else 0
        logging.warning(f"Modbus 异常: FC=0x{func_code:02X}, Exception=0x{exception_code:02X}")
        return None

    result = {
        "transaction_id": tid,
        "protocol_id": proto_id,
        "length": length,
        "unit_id": unit_id,
        "function_code": func_code,
        "registers": [],
    }

    # 解析寄存器数据
    if func_code in (0x03, 0x04):  # 读保持/输入寄存器
        if len(pdu) < 2:
            return result
        byte_count = pdu[1]
        reg_data = pdu[2:2 + byte_count]
        regs = []
        for i in range(0, len(reg_data), 2):
            val = struct.unpack(">H", reg_data[i:i+2])[0]
            # 处理有符号（温度可能为负）
            if val > 32767:
                val -= 65536
            regs.append(val)
        result["registers"] = regs

        # 转换为工程值
        if len(regs) >= 2:
            result["temperature"] = round(regs[0] / 10.0, 1)
            result["humidity"] = round(regs[1] / 10.0, 1)
        if len(regs) >= 3:
            dew = regs[2]
            result["dew_point"] = round(dew / 10.0, 1)

    return result

def main():
    sock = create_raw_socket()
    packet_count = 0
    modbus_count = 0

    logging.info("开始监听... (Ctrl+C 停止)")

    try:
        while True:
            raw_data, addr = sock.recvfrom(BUFFER_SIZE)
            packet_count += 1

            # 1. 解析 IP 头
            ip_info = parse_ip_header(raw_data)
            if not ip_info:
                continue

            src_ip, dst_ip, protocol, ip_hdr_len, total_len = ip_info

            # 只处理 UDP
            if protocol != 17:
                continue

            # 2. 解析 UDP 头
            udp_info = parse_udp_header(raw_data, ip_hdr_len)
            if not udp_info:
                continue

            src_port, dst_port, udp_len, udp_csum, payload = udp_info

            # 3. 端口过滤（应用层过滤，Raw Socket 不帮你做）
            if dst_port != TARGET_PORT and src_port != TARGET_PORT:
                continue

            # 4. 解析 Modbus 负载
            modbus_data = parse_modbus_adu(payload)
            if not modbus_data:
                continue

            modbus_count += 1

            # 5. 输出结果
            ts = datetime.now().strftime("%H:%M:%S.%f")[:-3]
            print(f"[{ts}] {src_ip}:{src_port} → {dst_ip}:{dst_port}")
            print(f"  Transaction ID: {modbus_data['transaction_id']}")
            print(f"  Unit ID: {modbus_data['unit_id']}")
            print(f"  Function: 0x{modbus_data['function_code']:02X}")

            if "temperature" in modbus_data:
                print(f"  🌡️  温度: {modbus_data['temperature']}℃")
                print(f"  💧 湿度: {modbus_data['humidity']}%RH")
                if "dew_point" in modbus_data:
                    print(f"  💧 露点: {modbus_data['dew_point']}℃")
            else:
                print(f"  📊 原始寄存器: {modbus_data['registers']}")
            print()

            # 6. 写入 InfluxDB / MQTT（见前篇）
            # publish_to_influx(modbus_data, src_ip)

    except KeyboardInterrupt:
        logging.info(f"停止监听. 总报文: {packet_count}, Modbus 报文: {modbus_count}")
    finally:
        sock.close()


if __name__ == "__main__":
    main()

# 方法一：直接用 root 运行（简单但不推荐生产）
sudo python3 raw_udp_listener.py

# 方法二：给 Python 解释器赋予 CAP_NET_RAW 能力（推荐）
sudo setcap cap_net_raw+eip /usr/bin/python3

# 验证
getcap /usr/bin/python3
# 输出: /usr/bin/python3 = cap_net_raw+eip

# 方法三：用 systemd 服务，配置 CapabilityBoundingSet

# /etc/systemd/system/raw-sensor-listener.service
[Unit]
Description=Raw Socket UDP Listener for Ethernet Temperature Sensors
After=network.target

[Service]
Type=simple
User=sensor
Group=sensor
ExecStart=/usr/bin/python3 /opt/sensor-listener/raw_udp_listener.py
Restart=always
RestartSec=5

# 能力配置
CapabilityBoundingSet=CAP_NET_RAW
AmbientCapabilities=CAP_NET_RAW

# 安全加固
NoNewPrivileges=true
PrivateTmp=true
ProtectSystem=strict
ReadWritePaths=/var/log/sensor-listener

StandardOutput=journal
StandardError=journal

[Install]
WantedBy=multi-user.target

# BPF 过滤: UDP 目标端口 == 502
# 以太网头 14 字节, IP 头 20 字节, UDP 头偏移 2 字节是 dst_port
# 指令序列:
# 加载 UDP 目标端口 (以太网14 + IP20 + UDP2 = 偏移36)
# 比较是否等于 502 (0x01F6)

BPF_FILTER = [
    0x28, 0x00, 0x00, 0x0000000C,  # ldh [12] - 加载 EtherType
    0x15, 0x00, 0x05, 0x00000800,  # jeq #0x800 (IP) goto next, else jump 5
    0x30, 0x00, 0x00, 0x00000017,  # ldb [23] - 加载 IP protocol
    0x15, 0x00, 0x03, 0x00000011,  # jeq #17 (UDP) goto next, else jump 3
    0x28, 0x00, 0x00, 0x00000024,  # ldh [36] - 加载 UDP dst_port
    0x15, 0x00, 0x01, 0x000001F6,  # jeq #502 goto next, else jump 1
    0x06, 0x00, 0x00, 0x0000FFFF,  # ret #0xFFFF (接受)
    0x06, 0x00, 0x00, 0x00000000,  # ret #0x0 (拒绝)
]

import ctypes

BpfProg = struct.pack("HL", len(BPF_FILTER), ctypes.addressof(
    (ctypes.c_uint32 * len(BPF_FILTER))(*BPF_FILTER)
))
# 实际使用中建议用 python-bcc 或 pyroute2 库来设置 BPF

import multiprocessing as mp

def worker(queue, worker_id):
    """每个 worker 进程一个 Raw Socket"""
    sock = create_raw_socket()
    # 设置 BPF 过滤
    # ...
    while True:
        data, addr = sock.recvfrom(BUFFER_SIZE)
        queue.put((data, addr))

def collector(queue):
    """汇总进程：解析 + 入库"""
    while True:
        data, addr = queue.get()
        result = parse_pipeline(data)
        if result:
            write_to_influx(result)

def main_mp():
    queue = mp.Queue(maxsize=10000)
    workers = []
    for i in range(4):  # 4 个 CPU 核心
        p = mp.Process(target=worker, args=(queue, i))
        p.start()
        workers.append(p)

    c = mp.Process(target=collector, args=(queue,))
    c.start()
    c.join()

# 1. 用 tshark 同时抓包
tshark -i eth0 -f "udp port 502" -w /tmp/capture.pcap &

# 2. 运行你的 Raw Socket 程序
python3 raw_udp_listener.py &

# 3. 对比计数
# Wireshark 显示 10000 个 UDP/502 报文
# 你的程序也显示 10000 个 Modbus 报文 → 一致 ✓

# 4. 用 Wireshark 解码验证解析正确性
tshark -r /tmp/capture.pcap -Y "modbus" -T fields \
  -e ip.src -e udp.srcport -e modbus.reg16

# 只允许来自传感器子网的报文
iptables -A INPUT -p udp --dport 502 -s 192.168.10.0/24 -j ACCEPT
iptables -A INPUT -p udp --dport 502 -j DROP

import zlib

def verify_udp_checksum(ip_header, udp_header_and_payload):
    """验证 UDP 校验和（可选，多数局域网场景可跳过）"""
    # 构造伪头部
    src_ip = ip_header[12:16]
    dst_ip = ip_header[16:20]
    zero = b'\x00'
    protocol = b'\x11'  # UDP
    udp_len = struct.pack('>H', len(udp_header_and_payload))

    pseudo_header = src_ip + dst_ip + zero + protocol + udp_len
    checksum_data = pseudo_header + udp_header_and_payload

    # 补齐奇数长度
    if len(checksum_data) % 2:
        checksum_data += b'\x00'

    # 计算 16-bit one's complement sum
    total = 0
    for i in range(0, len(checksum_data), 2):
        total += (checksum_data[i] << 8) + checksum_data[i+1]

    while total >> 16:
        total = (total & 0xFFFF) + (total >> 16)

    checksum = ~total & 0xFFFF
    return checksum == 0
