档案馆环境监测网络运维：传感器心跳检测与离线节点自动告警

┌─────────────────────────────────────────────────────────────────────┐
│ 为什么节点离线后没有及时告警？                                     │
├─────────────────────────────────────────────────────────────────────┤
│                                                                     │
│  原因1：系统只检测"有没有数据"，不检测"节点是否在线"              │
│  ├── 节点每5分钟上报一次数据                                       │
│  ├── 如果节点离线，系统要等5分钟才能发现"这次没收到数据"           │
│  └── 但系统没有区分"数据延迟"和"节点离线"                         │
│                                                                     │
│  原因2：告警阈值设置不合理                                          │
│  ├── 连续3次没收到数据才告警 → 15分钟延迟                          │
│  ├── 但网络抖动也会导致偶尔丢包 → 频繁误报 → 管理员关闭告警       │
│  └── 结果：真出问题时不告警                                        │
│                                                                     │
│  原因3：告警渠道单一                                                │
│  ├── 只在监控大屏上显示红色标记                                    │
│  ├── 夜间无人值守时无人看大屏                                      │
│  └── 没有短信/电话等主动通知                                       │
│                                                                     │
│  原因4：缺乏分级告警                                                │
│  ├── 单个节点离线 vs 整区节点离线，严重程度不同                    │
│  ├── 但系统用同一种方式处理                                        │
│  └── 管理员无法判断是否需要立即处理                                │
│                                                                     │
│  原因5：没有告警确认和升级机制                                      │
│  ├── 告警发出后，如果管理员没处理，不会升级                        │
│  └── 告警被淹没在大量信息中                                        │
│                                                                     │
└─────────────────────────────────────────────────────────────────────┘

┌──────────┬──────────┬────────────┬──────────────────────────────────┐
│ 偏移     │ 长度     │ 字段       │ 说明                             │
├──────────┼──────────┼────────────┼──────────────────────────────────┤
│ 0        │ 2        │ 帧头       │ 0xAA55（帧同步）                 │
│ 2        │ 1        │ 命令       │ 0x10=心跳请求, 0x11=心跳响应     │
│ 3        │ 1        │ 节点ID     │ 从站地址（1~247）                │
│ 4        │ 1        │ 节点状态   │ Bit0=在线, Bit1=低电量,          │
│          │          │            │ Bit2=传感器故障, Bit3=存储满     │
│ 5        │ 2        │ 运行时间   │ 节点上电后秒数（高位）           │
│ 7        │ 2        │ 软件版本   │ 主版本.次版本                    │
│ 9        │ 1        │ RSSI       │ 无线信号强度（仅无线节点）        │
│ 10       │ 1        │ 保留       │ 预留                             │
│ 11       │ 2        │ CRC16      │ 校验                            │
│ 总计     │ 13字节   │            │                                  │
└──────────┴──────────┴────────────┴──────────────────────────────────┘

{
  "type": "heartbeat",
  "collector_id": "C-001",
  "timestamp": 1705728000,
  "nodes": [
    {
      "node_id": 1,
      "status": "online",
      "last_seen": 1705727995,
      "rssi": -45,
      "uptime": 86400,
      "fw_version": "2.1.3"
    },
    {
      "node_id": 2,
      "status": "offline",
      "last_seen": 1705727400,
      "rssi": null,
      "uptime": null,
      "fw_version": null
    }
  ],
  "collector_status": {
    "cpu_usage": 12,
    "mem_usage": 34,
    "disk_free": 2048,
    "network": "ok"
  }
}

┌──────────────────────────────────────┐
                    │                                      │
                    ▼                                      │
┌───────────┐    ┌───────────┐    ┌───────────┐    ┌───────────┐
│  UNKNOWN  │───▶│   ONLINE  │───▶│  DEGRADED │───▶│   OFFLINE │
│  (未知)   │    │  (在线)   │    │  (降级)   │    │  (离线)   │
└───────────┘    └───────────┘    └───────────┘    └───────────┘
     ▲                │                  │                  │
     │                │                  │                  │
     │                ▼                  ▼                  ▼
     │        连续3次心跳      连续1~3次心跳       连续>3次心跳
     │        正常响应          丢失/超时          丢失/超时
     │                                                  │
     │        自动恢复 ───────────────────────────────────┘
     │        (节点重新上线)
     │
     └── 系统启动初始化

┌─────────────────────────────────────────────────────────────────────┐
│ 告警引擎架构                                                       │
│                                                                     │
│  ┌─────────────┐    ┌─────────────┐    ┌─────────────┐            │
│  │ 心跳接收器  │───▶│ 状态评估器  │───▶│ 告警决策器  │            │
│  │ (Collector) │    │ (Evaluator) │    │ (Decider)   │            │
│  └─────────────┘    └─────────────┘    └─────────────┘            │
│         │                  │                  │                     │
│         ▼                  ▼                  ▼                     │
│  ┌─────────────┐    ┌─────────────┐    ┌─────────────┐            │
│  │ 节点状态表  │    │ 告警规则库  │    │ 通知分发器  │            │
│  │ (NodeTable) │    │ (RuleBase)  │    │ (Dispatcher)│            │
│  └─────────────┘    └─────────────┘    └─────────────┘            │
│                                              │                     │
│                                              ▼                     │
│                                    ┌─────────────────┐             │
│                                    │ 通知渠道        │             │
│                                    │ - 短信          │             │
│                                    │ - 邮件          │             │
│                                    │ - 微信/钉钉     │             │
│                                    │ - 语音电话      │             │
│                                    │ - 监控大屏      │             │
│                                    └─────────────────┘             │
└─────────────────────────────────────────────────────────────────────┘

# alert_rules.yaml
rules:
  - name: "单节点离线"
    condition:
      type: "node_offline"
      duration: "5m"          # 连续离线5分钟
      count: 1                # 1个节点
    severity: "warning"
    suppress:
      - "同一节点5分钟内不重复告警"
      - "网络维护窗口期内抑制"
    notify:
      channels: ["email", "dashboard"]
    escalate:
      after: "30m"
      if: "still_offline"
      to: "supervisor"

  - name: "区域节点批量离线"
    condition:
      type: "area_offline"
      area: "库房区A"
      count: ">=3"            # 同一区域≥3个节点
      duration: "3m"
    severity: "critical"
    suppress:
      - "同一区域10分钟内不重复"
    notify:
      channels: ["sms", "email", "voice_call", "dashboard"]
    escalate:
      after: "15m"
      if: "still_offline"
      to: "manager"

  - name: "采集器离线"
    condition:
      type: "collector_offline"
      duration: "2m"
    severity: "critical"
    notify:
      channels: ["sms", "email", "voice_call"]
    escalate:
      after: "10m"
      to: "manager"

  - name: "心跳延迟"
    condition:
      type: "heartbeat_delay"
      latency: ">3s"          # 心跳响应超过3秒
      count: ">=5"            # 连续5次
    severity: "info"
    notify:
      channels: ["dashboard"]

# alert_engine.py
import time
import smtplib
import requests
from datetime import datetime, timedelta
from email.mime.text import MIMEText
from email.mime.multipart import MIMEMultipart
from typing import List, Dict, Optional
from enum import Enum
import yaml

class Severity(Enum):
    INFO = 0
    WARNING = 1
    CRITICAL = 2
    EMERGENCY = 3

class AlertStatus(Enum):
    ACTIVE = 1
    ACKNOWLEDGED = 2
    RESOLVED = 3
    SUPPRESSED = 4

@dataclass
class AlertRule:
    name: str
    condition: Dict
    severity: str
    suppress: List[str]
    notify_channels: List[str]
    escalate_after: Optional[str] = None
    escalate_to: Optional[str] = None

@dataclass
class Alert:
    alert_id: str
    rule_name: str
    node_id: Optional[int]
    area: Optional[str]
    severity: Severity
    status: AlertStatus
    message: str
    created_at: float
    acknowledged_at: Optional[float] = None
    resolved_at: Optional[float] = None
    notified_channels: List[str] = field(default_factory=list)
    escalation_level: int = 0

class AlertEngine:
    def __init__(self, config_path: str):
        self.rules = self._load_rules(config_path)
        self.active_alerts: Dict[str, Alert] = {}
        self.alert_history: List[Alert] = []
        self.suppression_cache: Dict[str, float] = {}

    def _load_rules(self, config_path: str) -> List[AlertRule]:
        with open(config_path, 'r') as f:
            data = yaml.safe_load(f)
        rules = []
        for r in data['rules']:
            rules.append(AlertRule(
                name=r['name'],
                condition=r['condition'],
                severity=r['severity'],
                suppress=r.get('suppress', []),
                notify_channels=r['notify']['channels'],
                escalate_after=r.get('escalate', {}).get('after'),
                escalate_to=r.get('escalate', {}).get('to')
            ))
        return rules

    def evaluate(self, node_status: Dict):
        """评估节点状态，决定是否触发告警"""
        for rule in self.rules:
            if self._match_condition(rule.condition, node_status):
                alert_key = self._get_alert_key(rule, node_status)
                if self._is_suppressed(rule, alert_key):
                    continue
                self._trigger_alert(rule, node_status, alert_key)

    def _match_condition(self, condition: Dict, node_status: Dict) -> bool:
        """匹配告警条件"""
        cond_type = condition.get('type')

        if cond_type == 'node_offline':
            duration = condition.get('duration', '5m')
            duration_sec = self._parse_duration(duration)
            if node_status.get('state') == 'OFFLINE':
                offline_time = time.time() - node_status.get('last_seen', 0)
                return offline_time >= duration_sec
            return False

        elif cond_type == 'area_offline':
            area = condition.get('area')
            min_count = condition.get('count', '>=3')
            # 实现略：统计区域内离线节点数
            return False

        elif cond_type == 'collector_offline':
            duration = condition.get('duration', '2m')
            duration_sec = self._parse_duration(duration)
            if node_status.get('type') == 'collector':
                return node_status.get('state') == 'OFFLINE'
            return False

        elif cond_type == 'heartbeat_delay':
            latency = condition.get('latency', '>3s')
            count = condition.get('count', '>=5')
            # 实现略：检查心跳延迟
            return False

        return False

    def _is_suppressed(self, rule: AlertRule, alert_key: str) -> bool:
        """检查是否被抑制"""
        # 检查抑制规则
        for suppress_rule in rule.suppress:
            if '不重复' in suppress_rule:
                # 提取时间窗口
                if '5分钟' in suppress_rule:
                    window = 300
                elif '10分钟' in suppress_rule:
                    window = 600
                else:
                    window = 300

                if alert_key in self.suppression_cache:
                    if time.time() - self.suppression_cache[alert_key] < window:
                        return True

        return False

    def _trigger_alert(self, rule: AlertRule, node_status: Dict, alert_key: str):
        """触发告警"""
        alert_id = f"{rule.name}_{node_status.get('node_id', 'unknown')}_{int(time.time())}"
        severity = Severity[rule.severity.upper()]

        alert = Alert(
            alert_id=alert_id,
            rule_name=rule.name,
            node_id=node_status.get('node_id'),
            area=node_status.get('area'),
            severity=severity,
            status=AlertStatus.ACTIVE,
            message=self._generate_message(rule, node_status),
            created_at=time.time()
        )

        self.active_alerts[alert_id] = alert
        self.suppression_cache[alert_key] = time.time()

        # 发送通知
        self._dispatch_notifications(alert, rule.notify_channels)

        print(f"Alert triggered: {alert.message}")

    def _dispatch_notifications(self, alert: Alert, channels: List[str]):
        """分发通知到各渠道"""
        for channel in channels:
            try:
                if channel == 'email':
                    self._send_email(alert)
                elif channel == 'sms':
                    self._send_sms(alert)
                elif channel == 'voice_call':
                    self._make_voice_call(alert)
                elif channel == 'dashboard':
                    self._update_dashboard(alert)
                elif channel in ['wechat', 'dingtalk']:
                    self._send_webhook(alert, channel)

                alert.notified_channels.append(channel)
            except Exception as e:
                print(f"Failed to send {channel} notification: {e}")

    def _send_email(self, alert: Alert):
        """发送邮件通知"""
        # 实现略
        pass

    def _send_sms(self, alert: Alert):
        """发送短信通知"""
        # 实现略
        pass

    def _make_voice_call(self, alert: Alert):
        """语音电话通知"""
        # 实现略
        pass

    def _update_dashboard(self, alert: Alert):
        """更新监控大屏"""
        # 实现略
        pass

    def _send_webhook(self, alert: Alert, channel: str):
        """发送Webhook通知（微信/钉钉）"""
        # 实现略
        pass

    def _generate_message(self, rule: AlertRule, node_status: Dict) -> str:
        """生成告警消息"""
        node_id = node_status.get('node_id', 'unknown')
        area = node_status.get('area', 'unknown')
        return f"节点 {node_id} (区域: {area}) 离线超过 {rule.condition.get('duration', 'N/A')}"

    def _get_alert_key(self, rule: AlertRule, node_status: Dict) -> str:
        """生成告警键，用于去重"""
        return f"{rule.name}_{node_status.get('node_id', 'unknown')}"

    def _parse_duration(self, duration: str) -> int:
        """解析持续时间字符串为秒"""
        if duration.endswith('s'):
            return int(duration[:-1])
        elif duration.endswith('m'):
            return int(duration[:-1]) * 60
        elif duration.endswith('h'):
            return int(duration[:-1]) * 3600
        else:
            return 300  # 默认5分钟

    def acknowledge_alert(self, alert_id: str, user: str):
        """确认告警"""
        if alert_id in self.active_alerts:
            alert = self.active_alerts[alert_id]
            alert.status = AlertStatus.ACKNOWLEDGED
            alert.acknowledged_at = time.time()
            print(f"Alert {alert_id} acknowledged by {user}")

    def resolve_alert(self, alert_id: str):
        """解决告警"""
        if alert_id in self.active_alerts:
            alert = self.active_alerts.pop(alert_id)
            alert.status = AlertStatus.RESOLVED
            alert.resolved_at = time.time()
            self.alert_history.append(alert)
            print(f"Alert {alert_id} resolved")

    def get_active_alerts(self, severity: Optional[Severity] = None) -> List[Alert]:
        """获取活跃告警"""
        if severity is None:
            return list(self.active_alerts.values())
        return [a for a in self.active_alerts.values() if a.severity == severity]

    def check_escalation(self):
        """检查告警升级"""
        now = time.time()
        for alert in list(self.active_alerts.values()):
            if alert.escalation_level > 0:
                continue

            # 查找对应的规则
            for rule in self.rules:
                if rule.name == alert.rule_name and rule.escalate_after:
                    escalate_after = self._parse_duration(rule.escalate_after)
                    if now - alert.created_at >= escalate_after:
                        # 升级告警
                        self._escalate_alert(alert, rule)
                        break

    def _escalate_alert(self, alert: Alert, rule: AlertRule):
        """升级告警"""
        alert.escalation_level += 1
        alert.severity = Severity.CRITICAL

        # 重新发送通知
        self._dispatch_notifications(alert, rule.notify_channels)

        print(f"Alert {alert.alert_id} escalated to {alert.severity}")

┌─────────────────────────────────────────────────────────────────────┐
│ 档案馆环境监测网络 - 实时拓扑                                      │
│                                                                     │
│  ┌───────────────────────────────────────────────────────────────┐ │
│  │ 监控中心                                                      │ │
│  │  ┌─────────────┐  ┌─────────────┐  ┌─────────────┐          │ │
│  │  │ 主服务器    │  │ 备服务器    │  │ 数据库      │          │ │
│  │  │ [ONLINE]   │  │ [ONLINE]   │  │ [ONLINE]   │          │ │
│  │  └──────┬──────┘  └─────────────┘  └─────────────┘          │ │
│  └─────────┼──────────────────────────────────────────────────────┘ │
│            │                                                        │
│  ┌─────────┼──────────────────────────────────────────────────────┐ │
│  │ 核心交换机                                              [OK]  │ │
│  └─────────┼──────────────────────────────────────────────────────┘ │
│            │                                                        │
│  ┌─────────┼──────────────────────────────────────────────────────┐ │
│  │ 区域A: 库房区 (采集器 C-001)                           [WARN] │ │
│  │  ┌──────┴──────┐                                              │ │
│  │  │ 节点1 [OK]  │ 节点2 [OK]  │ 节点3 [WARN] │ 节点4 [OK]     │ │
│  │  └─────────────┘                                              │ │
│  └─────────────────────────────────────────────────────────────────┘ │
│                                                                     │
│  ┌─────────────────────────────────────────────────────────────────┐ │
│  │ 区域B: 阅览区 (采集器 C-002)                           [OK]   │ │
│  │  ┌──────┬──────┐                                              │ │
│  │  │节点5│节点6│ 节点7 [OK]  │ 节点8 [OK]                       │ │
│  │  └──────┴──────┘                                              │ │
│  └─────────────────────────────────────────────────────────────────┘ │
│                                                                     │
│  ┌─────────────────────────────────────────────────────────────────┐ │
│  │ 区域C: 数字化加工区 (采集器 C-003)                     [ERR]  │ │
│  │  ┌──────┬──────┐                                              │ │
│  │  │节点9│节点10│ 节点11 [OFFLINE] │ 节点12 [OFFLINE]            │ │
│  │  └──────┴──────┘                                              │ │
│  └─────────────────────────────────────────────────────────────────┘ │
│                                                                     │
│  ┌─────────────────────────────────────────────────────────────────┐ │
│  │ 告警面板                                                        │ │
│  │ [CRITICAL] 区域C: 节点11、节点12 离线超过10分钟               │ │
│  │ [WARNING]  区域A: 节点3 心跳延迟                               │ │
│  │ [INFO]     系统运行正常，共监控 48 个节点                       │ │
│  └─────────────────────────────────────────────────────────────────┘ │
└─────────────────────────────────────────────────────────────────────┘

{
  "node_id": 3,
  "area": "库房区A",
  "collector": "C-001",
  "status": "DEGRADED",
  "last_seen": "2025-01-20 14:25:30",
  "uptime": "15天 3小时 22分",
  "firmware": "v2.1.3",
  "signal": {
    "rssi": -62,
    "snr": 8.5,
    "tx_power": 14
  },
  "health": {
    "cpu_temp": 42.3,
    "battery": 85,
    "memory_usage": 45
  },
  "heartbeat": {
    "interval": 30,
    "last_response_time": 2.8,
    "avg_response_time": 1.2,
    "packet_loss": 0.5
  },
  "alerts": [
    {
      "level": "WARNING",
      "message": "心跳响应时间超过阈值 (2.8s > 2.0s)",
      "timestamp": "2025-01-20 14:25:35"
    }
  ]
}

┌────────────┐     ┌────────────┐     ┌────────────┐     ┌────────────┐
│ 检测到节点 │     │ 尝试远程   │     │ 远程重启   │     │ 等待节点   │
│ 离线       │────▶│ 重启       │────▶│ 成功?      │────▶│ 重新上线   │
└────────────┘     └────────────┘     └─────┬──────┘     └─────┬──────┘
                                             │                  │
                                             │ 否               │ 是
                                             ▼                  ▼
                                      ┌────────────┐     ┌────────────┐
                                      │ 标记需要   │     │ 恢复成功   │
                                      │ 人工干预   │     │ 关闭告警   │
                                      └────────────┘     └────────────┘

# self_healing.py
import time
import threading
from typing import Dict, List

class SelfHealingManager:
    """节点自愈管理器"""

    def __init__(self, alert_engine, node_controller):
        self.alert_engine = alert_engine
        self.node_controller = node_controller  # 节点控制器，用于发送重启命令
        self.healing_attempts: Dict[int, int] = {}  # 节点ID -> 已尝试次数
        self.max_attempts = 3
        self.healing_interval = 300  # 两次自愈尝试之间的最小间隔（秒）
        self.last_healing_time: Dict[int, float] = {}

    def handle_node_offline(self, node_id: int, area: str):
        """处理节点离线事件"""
        # 检查是否已经超过最大尝试次数
        if self.healing_attempts.get(node_id, 0) >= self.max_attempts:
            print(f"Node {node_id} has exceeded max healing attempts")
            return

        # 检查是否在冷却时间内
        now = time.time()
        last_time = self.last_healing_time.get(node_id, 0)
        if now - last_time < self.healing_interval:
            print(f"Node {node_id} is in healing cooldown")
            return

        # 启动自愈线程
        healing_thread = threading.Thread(
            target=self._healing_worker,
            args=(node_id, area),
            daemon=True
        )
        healing_thread.start()

    def _healing_worker(self, node_id: int, area: str):
        """自愈工作线程"""
        self.healing_attempts[node_id] = self.healing_attempts.get(node_id, 0) + 1
        self.last_healing_time[node_id] = time.time()

        print(f"Attempting to heal node {node_id} (attempt {self.healing_attempts[node_id]})")

        # 步骤1: 尝试远程重启
        if self.node_controller.reboot_node(node_id):
            print(f"Node {node_id} reboot command sent")

            # 等待节点重新上线
            for i in range(12):  # 等待最多60秒
                time.sleep(5)
                if self.node_controller.is_node_online(node_id):
                    print(f"Node {node_id} is back online after reboot")
                    # 关闭相关告警
                    self.alert_engine.resolve_alert_for_node(node_id)
                    return

            print(f"Node {node_id} did not come back after reboot")
        else:
            print(f"Failed to send reboot command to node {node_id}")

        # 步骤2: 如果远程重启失败，尝试重启采集器端口
        if self.healing_attempts[node_id] >= 2:
            collector_id = self.node_controller.get_collector_for_node(node_id)
            if collector_id:
                print(f"Attempting to reset collector {collector_id} port for node {node_id}")
                self.node_controller.reset_collector_port(collector_id, node_id)

                # 等待节点重新上线
                for i in range(12):
                    time.sleep(5)
                    if self.node_controller.is_node_online(node_id):
                        print(f"Node {node_id} is back online after port reset")
                        self.alert_engine.resolve_alert_for_node(node_id)
                        return

        # 步骤3: 如果所有尝试都失败，标记为需要人工干预
        if self.healing_attempts[node_id] >= self.max_attempts:
            print(f"Node {node_id} requires manual intervention")
            self.alert_engine.escalate_to_manual(node_id, area)

# report_generator.py
from datetime import datetime, timedelta
import csv
import json

class ReportGenerator:
    """运维报表生成器"""

    def __init__(self, alert_engine, node_status_db):
        self.alert_engine = alert_engine
        self.node_status_db = node_status_db

    def generate_daily_report(self, date: datetime) -> Dict:
        """生成日报"""
        start_time = date.replace(hour=0, minute=0, second=0)
        end_time = start_time + timedelta(days=1)

        # 查询当天的告警
        alerts = self.alert_engine.get_alerts_by_time_range(start_time, end_time)

        # 查询节点状态统计
        node_stats = self.node_status_db.get_node_stats_by_time_range(
            start_time, end_time
        )

        report = {
            "date": date.strftime("%Y-%m-%d"),
            "summary": {
                "total_nodes": len(node_stats),
                "online_nodes": sum(1 for n in node_stats.values() if n['state'] == 'ONLINE'),
                "offline_nodes": sum(1 for n in node_stats.values() if n['state'] == 'OFFLINE'),
                "total_alerts": len(alerts),
                "critical_alerts": sum(1 for a in alerts if a.severity == Severity.CRITICAL),
                "avg_response_time": self._calc_avg_response_time(node_stats),
                "data_completeness": self._calc_data_completeness(node_stats)
            },
            "alerts_by_area": self._group_alerts_by_area(alerts),
            "node_availability": self._calc_node_availability(node_stats),
            "heartbeat_stats": self._calc_heartbeat_stats(node_stats)
        }

        return report

    def _calc_avg_response_time(self, node_stats: Dict) -> float:
        """计算平均心跳响应时间"""
        response_times = [n.get('avg_response_time', 0) for n in node_stats.values()]
        return sum(response_times) / len(response_times) if response_times else 0

    def _calc_data_completeness(self, node_stats: Dict) -> float:
        """计算数据完整性百分比"""
        total_expected = len(node_stats) * 24 * 60 / 5  # 假设每5分钟一条数据
        total_received = sum(n.get('data_count', 0) for n in node_stats.values())
        return (total_received / total_expected) * 100 if total_expected > 0 else 0

    def _group_alerts_by_area(self, alerts: List[Alert]) -> Dict:
        """按区域分组告警"""
        result = {}
        for alert in alerts:
            area = alert.area or 'unknown'
            if area not in result:
                result[area] = []
            result[area].append({
                'node_id': alert.node_id,
                'severity': alert.severity.name,
                'message': alert.message,
                'created_at': alert.created_at
            })
        return result

    def _calc_node_availability(self, node_stats: Dict) -> Dict:
        """计算节点可用性"""
        result = {}
        for node_id, stats in node_stats.items():
            total_time = 24 * 3600  # 一天的总秒数
            offline_time = stats.get('offline_duration', 0)
            availability = ((total_time - offline_time) / total_time) * 100
            result[node_id] = {
                'availability': availability,
                'offline_count': stats.get('offline_count', 0),
                'total_offline_time': offline_time
            }
        return result

    def _calc_heartbeat_stats(self, node_stats: Dict) -> Dict:
        """计算心跳统计"""
        total_nodes = len(node_stats)
        if total_nodes == 0:
            return {}

        response_times = [n.get('avg_response_time', 0) for n in node_stats.values()]
        packet_losses = [n.get('packet_loss', 0) for n in node_stats.values()]

        return {
            'avg_response_time': sum(response_times) / total_nodes,
            'max_response_time': max(response_times),
            'min_response_time': min(response_times),
            'avg_packet_loss': sum(packet_losses) / total_nodes,
            'nodes_with_packet_loss': sum(1 for p in packet_losses if p > 0)
        }

=== 档案馆环境监测网络运维日报 ===
日期: 2025-01-20

【总体概况】
  监控节点总数: 48
  在线节点: 46 (95.8%)
  离线节点: 2 (4.2%)
  当日告警总数: 5
    严重: 1
    警告: 3
    信息: 1
  平均心跳响应时间: 1.2s
  数据完整性: 99.7%

【按区域统计】
  库房区A: 节点15个, 在线15个, 告警1个
  阅览区: 节点12个, 在线12个, 告警0个
  数字化加工区: 节点12个, 在线10个, 告警4个
  办公区: 节点9个, 在线9个, 告警0个

【离线节点详情】
  节点11 (数字化加工区): 离线2小时15分, 原因: 网络中断
  节点12 (数字化加工区): 离线2小时15分, 原因: 网络中断

【告警详情】
  [CRITICAL] 14:25 数字化加工区 节点11、12 离线
  [WARNING] 10:30 库房区A 节点3 心跳延迟
  [WARNING] 09:15 库房区A 节点7 心跳延迟
  [WARNING] 08:45 阅览区 节点5 心跳延迟
  [INFO] 08:00 系统启动完成

【运维建议】
  - 数字化加工区网络中断已持续2小时，建议立即排查交换机端口
  - 库房区A节点3、7心跳延迟，建议检查无线信号强度
