IM聊天不掉线？生产级WebSocket断线重连、心跳保活实战

class ReconnectingWebSocket {
  constructor(url, options = {}) {
    this.url = url
    this.options = {
      heartbeatInterval: 30000,        // 心跳间隔 30秒
      heartbeatTimeout: 10000,         // 心跳超时 10秒
      reconnectDelay: 1000,            // 初始重连延迟 1秒
      maxReconnectDelay: 30000,        // 最大重连延迟 30秒
      reconnectDecay: 1.5,             // 退避指数
      maxReconnectAttempts: Infinity,  // 最大重试次数
      ...options
    }

    this.ws = null
    this.reconnectAttempts = 0
    this.heartbeatTimer = null
    this.heartbeatTimeoutTimer = null
    this.manualClose = false// 是否手动关闭（手动关不重连）
    this.messageQueue = []            // 重连期间的离线消息队列

    this.listeners = newMap()        // 事件监听器
    this.connect()
  }

  // 建立连接
  connect() {
    this.ws = newWebSocket(this.url)

    this.ws.onopen = (event) => {
      console.log('WebSocket 连接成功')
      this.reconnectAttempts = 0
      this.startHeartbeat()
      this.flushMessageQueue()        // 重连成功后发送队列中的消息
      this.emit('open', event)
    }

    this.ws.onmessage = (event) => {
      // 收到任何消息都重置心跳超时计时器
      this.resetHeartbeatTimeout()
      this.emit('message', event.data)
    }

    this.ws.onclose = (event) => {
      console.warn('WebSocket 连接关闭', event.code, event.reason)
      this.stopHeartbeat()

      if(!this.manualClose) {
        this.scheduleReconnect()
      }
      this.emit('close', event)
    }

    this.ws.onerror = (error) => {
      console.error('WebSocket 错误', error)
      this.emit('error', error)
      // onerror之后通常会触发onclose，所以这里不额外处理重连
    }
  }

  // 启动心跳
  startHeartbeat() {
    this.stopHeartbeat() // 清理旧定时器

    this.heartbeatTimer = setInterval(() => {
      if(this.ws.readyState === WebSocket.OPEN) {
        // 发送心跳包，格式和后端约定好
        this.ws.send(JSON.stringify({ type: 'PING'}))

        // 设置心跳超时定时器
        this.heartbeatTimeoutTimer = setTimeout(() => {
          console.warn('心跳超时，主动断开连接')
          this.ws.close() // 触发onclose，进而触发重连
        }, this.options.heartbeatTimeout)
      }
    }, this.options.heartbeatInterval)
  }

  // 重置心跳超时（收到消息时调用）
  resetHeartbeatTimeout() {
    if(this.heartbeatTimeoutTimer) {
      clearTimeout(this.heartbeatTimeoutTimer)
      this.heartbeatTimeoutTimer = null
    }
  }

  // 停止心跳
  stopHeartbeat() {
    if(this.heartbeatTimer) {
      clearInterval(this.heartbeatTimer)
      this.heartbeatTimer = null
    }
    this.resetHeartbeatTimeout()
  }

  // 指数退避重连调度
  scheduleReconnect() {
    if(this.reconnectAttempts >= this.options.maxReconnectAttempts) {
      console.error('已达最大重连次数，停止重连')
      this.emit('reconnectFailed')
      return
    }

    const delay = Math.min(
      this.options.reconnectDelay * Math.pow(this.options.reconnectDecay, this.reconnectAttempts),
      this.options.maxReconnectDelay
    )

    console.log(`${delay}ms 后尝试第 ${this.reconnectAttempts + 1} 次重连`)

    setTimeout(() => {
      if(!this.manualClose) {
        this.reconnectAttempts++
        this.emit('reconnecting', this.reconnectAttempts)
        this.connect()
      }
    }, delay)
  }

  // 发送消息（支持离线队列）
  send(data) {
    const message = typeofdata === 'string'? data : JSON.stringify(data)

    if(this.ws.readyState === WebSocket.OPEN) {
      this.ws.send(message)
    } else{
      console.warn('连接未就绪，消息进入队列')
      this.messageQueue.push(message)
    }
  }

  // 连接恢复后发送队列中的消息
  flushMessageQueue() {
    while(this.messageQueue.length > 0) {
      const msg = this.messageQueue.shift()
      if(this.ws.readyState === WebSocket.OPEN) {
        this.ws.send(msg)
      }
    }
  }

  // 手动关闭（不再重连）
  close() {
    this.manualClose = true
    this.stopHeartbeat()
    this.ws.close()
  }

  // 事件监听系统
  on(event, callback) {
    if(!this.listeners.has(event)) {
      this.listeners.set(event, newSet())
    }
    this.listeners.get(event).add(callback)
  }

  off(event, callback) {
    this.listeners.get(event)?.delete(callback)
  }

  emit(event, ...args) {
    this.listeners.get(event)?.forEach(cb => cb(...args))
  }
}

// 使用示例
const ws = newReconnectingWebSocket('wss://chat.example.com/ws', {
  heartbeatInterval: 20000,
  maxReconnectAttempts: 10
})

ws.on('open', () => {
  console.log('连接建立，发送鉴权信息')
  ws.send({ type: 'AUTH', token: localStorage.getItem('token') })
})

ws.on('message', (data) => {
  const msg = JSON.parse(data)
  if(msg.type === 'PONG') {
    console.log('收到心跳响应')
  } else{
    // 处理业务消息
    handleChatMessage(msg)
  }
})

ws.on('reconnecting', (attempt) => {
  showToast(`网络不稳定，正在重连... (${attempt}/10)`)
})

ws.on('reconnectFailed', () => {
  showToast('连接失败，请检查网络后刷新页面')
})

// 页面可见性优化示例
document.addEventListener('visibilitychange', () => {
  if(document.hidden) {
    ws.options.heartbeatInterval = 60000 // 后台降频
  } else{
    ws.options.heartbeatInterval = 20000
    if(ws.ws.readyState !== WebSocket.OPEN) {
      ws.connect() // 立即重连
    }
  }
})
