Netty 全链路精通：从 IO 底层原理到高可用生产实战指南

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 https://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>
    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>3.2.4</version>
        <relativePath/>
    </parent>
    <groupId>com.jam</groupId>
    <artifactId>netty-demo</artifactId>
    <version>1.0.0</version>
    <name>netty-demo</name>
    <properties>
        <maven.compiler.source>17</maven.compiler.source>
        <maven.compiler.target>17</maven.compiler.target>
        <project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
        <netty.version>4.1.112.Final</netty.version>
        <lombok.version>1.18.30</lombok.version>
        <fastjson2.version>2.0.52</fastjson2.version>
        <guava.version>32.1.3-jre</guava.version>
        <mybatis.plus.version>3.5.6</mybatis.plus.version>
        <mysql.version>8.0.36</mysql.version>
        <springdoc.version>2.5.0</springdoc.version>
    </properties>
    <dependencies>
        <dependency>
            <groupId>io.netty</groupId>
            <artifactId>netty-all</artifactId>
            <version>${netty.version}</version>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-validation</artifactId>
        </dependency>
        <dependency>
            <groupId>com.baomidou</groupId>
            <artifactId>mybatis-plus-boot-starter</artifactId>
            <version>${mybatis.plus.version}</version>
        </dependency>
        <dependency>
            <groupId>com.mysql</groupId>
            <artifactId>mysql-connector-j</artifactId>
            <version>${mysql.version}</version>
            <scope>runtime</scope>
        </dependency>
        <dependency>
            <groupId>org.springdoc</groupId>
            <artifactId>springdoc-openapi-starter-webmvc-ui</artifactId>
            <version>${springdoc.version}</version>
        </dependency>
        <dependency>
            <groupId>org.projectlombok</groupId>
            <artifactId>lombok</artifactId>
            <version>${lombok.version}</version>
            <scope>provided</scope>
        </dependency>
        <dependency>
            <groupId>com.alibaba.fastjson2</groupId>
            <artifactId>fastjson2</artifactId>
            <version>${fastjson2.version}</version>
        </dependency>
        <dependency>
            <groupId>com.google.guava</groupId>
            <artifactId>guava</artifactId>
            <version>${guava.version}</version>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-test</artifactId>
            <scope>test</scope>
        </dependency>
    </dependencies>
    <build>
        <plugins>
            <plugin>
                <groupId>org.apache.maven.plugins</groupId>
                <artifactId>maven-compiler-plugin</artifactId>
                <version>3.12.1</version>
                <configuration>
                    <source>17</source>
                    <target>17</target>
                    <encoding>UTF-8</encoding>
                </configuration>
            </plugin>
        </plugins>
    </build>
</project>

package com.jam.demo.protocol;

import lombok.AllArgsConstructor;
import lombok.Data;
import lombok.NoArgsConstructor;

/**
 * 自定义通信协议实体
 * @author ken
 */
@Data
@NoArgsConstructor
@AllArgsConstructor
publicclass CustomProtocol {
    /**
     * 魔数，固定值，用于校验数据包合法性
     */
    publicstaticfinalint MAGIC_NUMBER = 0x12345678;
    /**
     * 协议版本号
     */
    publicstaticfinalbyte VERSION = 1;
    /**
     * 指令类型-业务数据
     */
    publicstaticfinalbyte COMMAND_TYPE_DATA = 0;
    /**
     * 指令类型-心跳请求
     */
    publicstaticfinalbyte COMMAND_TYPE_HEARTBEAT_REQUEST = 1;
    /**
     * 指令类型-心跳响应
     */
    publicstaticfinalbyte COMMAND_TYPE_HEARTBEAT_RESPONSE = 2;
    /**
     * 协议头部固定长度
     */
    publicstaticfinalint HEADER_LENGTH = 10;

    /**
     * 魔数
     */
    privateint magicNumber;
    /**
     * 版本号
     */
    privatebyte version;
    /**
     * 指令类型
     */
    privatebyte commandType;
    /**
     * 数据长度
     */
    privateint dataLength;
    /**
     * 消息体数据
     */
    privatebyte[] data;
}

package com.jam.demo.codec;

import com.alibaba.fastjson2.JSON;
import com.jam.demo.protocol.CustomProtocol;
import io.netty.buffer.ByteBuf;
import io.netty.channel.ChannelHandlerContext;
import io.netty.handler.codec.MessageToByteEncoder;
import lombok.extern.slf4j.Slf4j;

/**
 * 自定义协议编码器
 * @author ken
 */
@Slf4j
publicclass CustomProtocolEncoder extends MessageToByteEncoder<CustomProtocol> {
    @Override
    protected void encode(ChannelHandlerContext ctx, CustomProtocol msg, ByteBuf out) {
        out.writeInt(msg.getMagicNumber());
        out.writeByte(msg.getVersion());
        out.writeByte(msg.getCommandType());
        out.writeInt(msg.getDataLength());
        if (msg.getDataLength() > 0) {
            out.writeBytes(msg.getData());
        }
        log.debug("协议编码完成，指令类型：{}，数据长度：{}", msg.getCommandType(), msg.getDataLength());
    }
}

package com.jam.demo.codec;

import com.jam.demo.protocol.CustomProtocol;
import io.netty.buffer.ByteBuf;
import io.netty.channel.ChannelHandlerContext;
import io.netty.handler.codec.LengthFieldBasedFrameDecoder;
import lombok.extern.slf4j.Slf4j;

/**
 * 自定义协议解码器
 * 基于LengthFieldBasedFrameDecoder实现，彻底解决半包粘包问题
 * @author ken
 */
@Slf4j
publicclass CustomProtocolDecoder extends LengthFieldBasedFrameDecoder {
    /**
     * 解码器构造函数
     * maxFrameLength：最大帧长度，这里设置为10MB
     * lengthFieldOffset：长度字段偏移量，魔数4+版本1+指令1=6字节
     * lengthFieldLength：长度字段长度，4字节
     * lengthAdjustment：长度调整值，0
     * initialBytesToStrip：跳过的字节数，0，完整保留头部信息
     */
    public CustomProtocolDecoder() {
        super(10 * 1024 * 1024, 6, 4, 0, 0);
    }

    @Override
    protected Object decode(ChannelHandlerContext ctx, ByteBuf in) throws Exception {
        ByteBuf frame = (ByteBuf) super.decode(ctx, in);
        if (frame == null) {
            returnnull;
        }
        try {
            int magicNumber = frame.readInt();
            if (magicNumber != CustomProtocol.MAGIC_NUMBER) {
                log.error("非法数据包，魔数校验失败，远程地址：{}", ctx.channel().remoteAddress());
                ctx.close();
                returnnull;
            }
            CustomProtocol protocol = new CustomProtocol();
            protocol.setMagicNumber(magicNumber);
            protocol.setVersion(frame.readByte());
            protocol.setCommandType(frame.readByte());
            protocol.setDataLength(frame.readInt());
            if (protocol.getDataLength() > 0) {
                byte[] data = newbyte[protocol.getDataLength()];
                frame.readBytes(data);
                protocol.setData(data);
            }
            log.debug("协议解码完成，指令类型：{}，数据长度：{}", protocol.getCommandType(), protocol.getDataLength());
            return protocol;
        } finally {
            frame.release();
        }
    }
}

package com.jam.demo.handler;

import com.jam.demo.protocol.CustomProtocol;
import io.netty.channel.ChannelHandler;
import io.netty.channel.ChannelHandlerContext;
import io.netty.channel.ChannelInboundHandlerAdapter;
import io.netty.handler.timeout.IdleState;
import io.netty.handler.timeout.IdleStateEvent;
import lombok.extern.slf4j.Slf4j;

/**
 * 服务端心跳处理器
 * @author ken
 */
@Slf4j
@ChannelHandler.Sharable
publicclass ServerHeartbeatHandler extends ChannelInboundHandlerAdapter {
    /**
     * 最大空闲次数，超过该次数关闭连接
     */
    privatestaticfinalint MAX_IDLE_COUNT = 3;
    /**
     * 当前空闲次数
     */
    privateint idleCount = 0;

    @Override
    public void userEventTriggered(ChannelHandlerContext ctx, Object evt) throws Exception {
        if (evt instanceof IdleStateEvent event) {
            if (event.state() == IdleState.READER_IDLE) {
                idleCount++;
                log.warn("读空闲事件触发，远程地址：{}，当前空闲次数：{}", ctx.channel().remoteAddress(), idleCount);
                if (idleCount >= MAX_IDLE_COUNT) {
                    log.error("连续{}次读空闲，关闭连接，远程地址：{}", MAX_IDLE_COUNT, ctx.channel().remoteAddress());
                    ctx.close();
                }
            }
        } else {
            super.userEventTriggered(ctx, evt);
        }
    }

    @Override
    public void channelRead(ChannelHandlerContext ctx, Object msg) {
        idleCount = 0;
        CustomProtocol protocol = (CustomProtocol) msg;
        if (protocol.getCommandType() == CustomProtocol.COMMAND_TYPE_HEARTBEAT_REQUEST) {
            log.debug("收到客户端心跳请求，远程地址：{}", ctx.channel().remoteAddress());
            CustomProtocol response = new CustomProtocol();
            response.setMagicNumber(CustomProtocol.MAGIC_NUMBER);
            response.setVersion(CustomProtocol.VERSION);
            response.setCommandType(CustomProtocol.COMMAND_TYPE_HEARTBEAT_RESPONSE);
            response.setDataLength(0);
            ctx.writeAndFlush(response);
            return;
        }
        ctx.fireChannelRead(msg);
    }

    @Override
    public void exceptionCaught(ChannelHandlerContext ctx, Throwable cause) {
        log.error("服务端心跳处理器异常，远程地址：{}", ctx.channel().remoteAddress(), cause);
        ctx.close();
    }
}

package com.jam.demo.handler;

import com.jam.demo.protocol.CustomProtocol;
import io.netty.channel.ChannelHandlerContext;
import io.netty.channel.ChannelInboundHandlerAdapter;
import io.netty.handler.timeout.IdleState;
import io.netty.handler.timeout.IdleStateEvent;
import lombok.extern.slf4j.Slf4j;

/**
 * 客户端心跳处理器
 * @author ken
 */
@Slf4j
publicclass ClientHeartbeatHandler extends ChannelInboundHandlerAdapter {
    @Override
    public void userEventTriggered(ChannelHandlerContext ctx, Object evt) throws Exception {
        if (evt instanceof IdleStateEvent event) {
            if (event.state() == IdleState.WRITER_IDLE) {
                log.debug("写空闲事件触发，发送心跳请求到服务端");
                CustomProtocol request = new CustomProtocol();
                request.setMagicNumber(CustomProtocol.MAGIC_NUMBER);
                request.setVersion(CustomProtocol.VERSION);
                request.setCommandType(CustomProtocol.COMMAND_TYPE_HEARTBEAT_REQUEST);
                request.setDataLength(0);
                ctx.writeAndFlush(request);
            }
        } else {
            super.userEventTriggered(ctx, evt);
        }
    }

    @Override
    public void channelRead(ChannelHandlerContext ctx, Object msg) {
        CustomProtocol protocol = (CustomProtocol) msg;
        if (protocol.getCommandType() == CustomProtocol.COMMAND_TYPE_HEARTBEAT_RESPONSE) {
            log.debug("收到服务端心跳响应");
            return;
        }
        ctx.fireChannelRead(msg);
    }

    @Override
    public void exceptionCaught(ChannelHandlerContext ctx, Throwable cause) {
        log.error("客户端心跳处理器异常", cause);
        ctx.close();
    }
}

package com.jam.demo.handler;

import com.alibaba.fastjson2.JSON;
import com.jam.demo.protocol.CustomProtocol;
import io.netty.channel.ChannelHandler;
import io.netty.channel.ChannelHandlerContext;
import io.netty.channel.ChannelInboundHandlerAdapter;
import lombok.extern.slf4j.Slf4j;
import org.springframework.util.StringUtils;

import java.nio.charset.StandardCharsets;
import java.util.Map;

/**
 * 服务端业务处理器
 * @author ken
 */
@Slf4j
@ChannelHandler.Sharable
publicclass ServerBusinessHandler extends ChannelInboundHandlerAdapter {
    @Override
    public void channelActive(ChannelHandlerContext ctx) {
        log.info("客户端连接成功，远程地址：{}", ctx.channel().remoteAddress());
    }

    @Override
    public void channelInactive(ChannelHandlerContext ctx) {
        log.info("客户端连接断开，远程地址：{}", ctx.channel().remoteAddress());
    }

    @Override
    public void channelRead(ChannelHandlerContext ctx, Object msg) {
        CustomProtocol protocol = (CustomProtocol) msg;
        if (protocol.getCommandType() != CustomProtocol.COMMAND_TYPE_DATA) {
            log.warn("非业务数据指令，忽略处理，指令类型：{}", protocol.getCommandType());
            return;
        }
        String data = new String(protocol.getData(), StandardCharsets.UTF_8);
        log.info("收到客户端业务数据，远程地址：{}，数据内容：{}", ctx.channel().remoteAddress(), data);
        if (!StringUtils.hasText(data)) {
            log.warn("业务数据为空，忽略处理");
            return;
        }
        Map<String, Object> requestMap = JSON.parseObject(data);
        Map<String, Object> responseMap = Map.of("code", 200, "msg", "处理成功", "data", requestMap);
        byte[] responseData = JSON.toJSONString(responseMap).getBytes(StandardCharsets.UTF_8);
        CustomProtocol response = new CustomProtocol();
        response.setMagicNumber(CustomProtocol.MAGIC_NUMBER);
        response.setVersion(CustomProtocol.VERSION);
        response.setCommandType(CustomProtocol.COMMAND_TYPE_DATA);
        response.setDataLength(responseData.length);
        response.setData(responseData);
        ctx.writeAndFlush(response);
    }

    @Override
    public void exceptionCaught(ChannelHandlerContext ctx, Throwable cause) {
        log.error("服务端业务处理器异常，远程地址：{}", ctx.channel().remoteAddress(), cause);
        ctx.close();
    }
}

package com.jam.demo.handler;

import com.alibaba.fastjson2.JSON;
import com.jam.demo.protocol.CustomProtocol;
import io.netty.channel.ChannelHandlerContext;
import io.netty.channel.ChannelInboundHandlerAdapter;
import lombok.extern.slf4j.Slf4j;

import java.nio.charset.StandardCharsets;

/**
 * 客户端业务处理器
 * @author ken
 */
@Slf4j
publicclass ClientBusinessHandler extends ChannelInboundHandlerAdapter {
    @Override
    public void channelActive(ChannelHandlerContext ctx) {
        log.info("成功连接到服务端，服务端地址：{}", ctx.channel().remoteAddress());
    }

    @Override
    public void channelInactive(ChannelHandlerContext ctx) {
        log.info("与服务端的连接断开");
    }

    @Override
    public void channelRead(ChannelHandlerContext ctx, Object msg) {
        CustomProtocol protocol = (CustomProtocol) msg;
        if (protocol.getCommandType() != CustomProtocol.COMMAND_TYPE_DATA) {
            log.warn("非业务数据指令，忽略处理，指令类型：{}", protocol.getCommandType());
            return;
        }
        String data = new String(protocol.getData(), StandardCharsets.UTF_8);
        log.info("收到服务端响应数据：{}", data);
    }

    @Override
    public void exceptionCaught(ChannelHandlerContext ctx, Throwable cause) {
        log.error("客户端业务处理器异常", cause);
        ctx.close();
    }
}

package com.jam.demo.server;

import com.jam.demo.codec.CustomProtocolDecoder;
import com.jam.demo.codec.CustomProtocolEncoder;
import com.jam.demo.handler.ServerBusinessHandler;
import com.jam.demo.handler.ServerHeartbeatHandler;
import io.netty.bootstrap.ServerBootstrap;
import io.netty.channel.ChannelFuture;
import io.netty.channel.ChannelInitializer;
import io.netty.channel.ChannelOption;
import io.netty.channel.EventLoopGroup;
import io.netty.channel.nio.NioEventLoopGroup;
import io.netty.channel.socket.SocketChannel;
import io.netty.channel.socket.nio.NioServerSocketChannel;
import io.netty.handler.timeout.IdleStateHandler;
import lombok.extern.slf4j.Slf4j;
import org.springframework.stereotype.Component;

import java.util.concurrent.TimeUnit;

/**
 * Netty服务端启动类
 * @author ken
 */
@Slf4j
@Component
publicclass NettyServer {
    /**
     * 服务端监听端口
     */
    privatestaticfinalint PORT = 9000;
    /**
     * 读空闲时间，单位秒
     */
    privatestaticfinalint READER_IDLE_TIME = 10;

    private EventLoopGroup bossGroup;
    private EventLoopGroup workerGroup;

    /**
     * 启动Netty服务端
     */
    public void start() {
        bossGroup = new NioEventLoopGroup(1);
        workerGroup = new NioEventLoopGroup();
        try {
            ServerBootstrap bootstrap = new ServerBootstrap();
            bootstrap.group(bossGroup, workerGroup)
                    .channel(NioServerSocketChannel.class)
                    .option(ChannelOption.SO_BACKLOG, 1024)
                    .option(ChannelOption.SO_REUSEADDR, true)
                    .childOption(ChannelOption.TCP_NODELAY, true)
                    .childOption(ChannelOption.SO_KEEPALIVE, true)
                    .childHandler(new ChannelInitializer<SocketChannel>() {
                        @Override
                        protected void initChannel(SocketChannel ch) {
                            ch.pipeline()
                                    .addLast(new IdleStateHandler(READER_IDLE_TIME, 0, 0, TimeUnit.SECONDS))
                                    .addLast(new CustomProtocolDecoder())
                                    .addLast(new CustomProtocolEncoder())
                                    .addLast(new ServerHeartbeatHandler())
                                    .addLast(new ServerBusinessHandler());
                        }
                    });
            ChannelFuture future = bootstrap.bind(PORT).sync();
            log.info("Netty服务端启动成功，监听端口：{}", PORT);
            future.channel().closeFuture().sync();
        } catch (InterruptedException e) {
            log.error("Netty服务端启动异常", e);
            Thread.currentThread().interrupt();
        } finally {
            shutdown();
        }
    }

    /**
     * 关闭Netty服务端，释放资源
     */
    public void shutdown() {
        if (bossGroup != null && !bossGroup.isShutdown()) {
            bossGroup.shutdownGracefully();
        }
        if (workerGroup != null && !workerGroup.isShutdown()) {
            workerGroup.shutdownGracefully();
        }
        log.info("Netty服务端已关闭，资源释放完成");
    }
}

package com.jam.demo.client;

import com.alibaba.fastjson2.JSON;
import com.jam.demo.codec.CustomProtocolDecoder;
import com.jam.demo.codec.CustomProtocolEncoder;
import com.jam.demo.handler.ClientBusinessHandler;
import com.jam.demo.handler.ClientHeartbeatHandler;
import com.jam.demo.protocol.CustomProtocol;
import io.netty.bootstrap.Bootstrap;
import io.netty.channel.Channel;
import io.netty.channel.ChannelFuture;
import io.netty.channel.ChannelInitializer;
import io.netty.channel.ChannelOption;
import io.netty.channel.EventLoopGroup;
import io.netty.channel.nio.NioEventLoopGroup;
import io.netty.channel.socket.SocketChannel;
import io.netty.channel.socket.nio.NioSocketChannel;
import io.netty.handler.timeout.IdleStateHandler;
import lombok.extern.slf4j.Slf4j;
import org.springframework.stereotype.Component;

import java.nio.charset.StandardCharsets;
import java.util.Map;
import java.util.concurrent.TimeUnit;

/**
 * Netty客户端启动类
 * @author ken
 */
@Slf4j
@Component
publicclass NettyClient {
    /**
     * 服务端地址
     */
    privatestaticfinal String HOST = "127.0.0.1";
    /**
     * 服务端端口
     */
    privatestaticfinalint PORT = 9000;
    /**
     * 写空闲时间，单位秒
     */
    privatestaticfinalint WRITER_IDLE_TIME = 5;
    /**
     * 重连间隔时间，单位秒
     */
    privatestaticfinalint RECONNECT_INTERVAL = 3;

    private EventLoopGroup workerGroup;
    private Channel channel;
    private Bootstrap bootstrap;

    /**
     * 初始化客户端
     */
    public void init() {
        workerGroup = new NioEventLoopGroup();
        bootstrap = new Bootstrap();
        bootstrap.group(workerGroup)
                .channel(NioSocketChannel.class)
                .option(ChannelOption.TCP_NODELAY, true)
                .option(ChannelOption.SO_KEEPALIVE, true)
                .option(ChannelOption.CONNECT_TIMEOUT_MILLIS, 5000)
                .handler(new ChannelInitializer<SocketChannel>() {
                    @Override
                    protected void initChannel(SocketChannel ch) {
                        ch.pipeline()
                                .addLast(new IdleStateHandler(0, WRITER_IDLE_TIME, 0, TimeUnit.SECONDS))
                                .addLast(new CustomProtocolDecoder())
                                .addLast(new CustomProtocolEncoder())
                                .addLast(new ClientHeartbeatHandler())
                                .addLast(new ClientBusinessHandler());
                    }
                });
    }

    /**
     * 连接服务端
     */
    public void connect() {
        if (bootstrap == null) {
            init();
        }
        try {
            ChannelFuture future = bootstrap.connect(HOST, PORT).sync();
            if (future.isSuccess()) {
                channel = future.channel();
                log.info("Netty客户端连接服务端成功，服务端地址：{}:{}", HOST, PORT);
            }
            future.channel().closeFuture().addListener(f -> {
                log.warn("与服务端的连接断开，{}秒后尝试重连", RECONNECT_INTERVAL);
                workerGroup.schedule(this::connect, RECONNECT_INTERVAL, TimeUnit.SECONDS);
            });
        } catch (InterruptedException e) {
            log.error("Netty客户端连接服务端异常", e);
            Thread.currentThread().interrupt();
        }
    }

    /**
     * 发送业务数据到服务端
     * @param data 待发送的业务数据
     */
    public void sendData(Map<String, Object> data) {
        if (channel == null || !channel.isActive()) {
            log.error("与服务端的连接未就绪，无法发送数据");
            return;
        }
        String jsonData = JSON.toJSONString(data);
        byte[] dataBytes = jsonData.getBytes(StandardCharsets.UTF_8);
        CustomProtocol protocol = new CustomProtocol();
        protocol.setMagicNumber(CustomProtocol.MAGIC_NUMBER);
        protocol.setVersion(CustomProtocol.VERSION);
        protocol.setCommandType(CustomProtocol.COMMAND_TYPE_DATA);
        protocol.setDataLength(dataBytes.length);
        protocol.setData(dataBytes);
        channel.writeAndFlush(protocol).addListener(future -> {
            if (future.isSuccess()) {
                log.debug("数据发送成功，数据内容：{}", jsonData);
            } else {
                log.error("数据发送失败", future.cause());
            }
        });
    }

    /**
     * 关闭客户端，释放资源
     */
    public void shutdown() {
        if (channel != null) {
            channel.close();
        }
        if (workerGroup != null && !workerGroup.isShutdown()) {
            workerGroup.shutdownGracefully();
        }
        log.info("Netty客户端已关闭，资源释放完成");
    }
}

package com.jam.demo;

import com.jam.demo.server.NettyServer;
import io.swagger.v3.oas.annotations.OpenAPIDefinition;
import io.swagger.v3.oas.annotations.info.Info;
import lombok.extern.slf4j.Slf4j;
import org.springframework.boot.CommandLineRunner;
import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.context.annotation.Bean;

/**
 * Netty Demo项目启动类
 * @author ken
 */
@Slf4j
@SpringBootApplication
@OpenAPIDefinition(info = @Info(title = "Netty Demo API", version = "1.0.0", description = "Netty实战项目API文档"))
publicclass NettyDemoApplication {
    public static void main(String[] args) {
        SpringApplication.run(NettyDemoApplication.class, args);
        log.info("Netty Demo项目启动成功");
    }

    /**
     * 启动Netty服务端
     */
    @Bean
    public CommandLineRunner startNettyServer(NettyServer nettyServer) {
        return args -> new Thread(nettyServer::start, "netty-server-thread").start();
    }
}

package com.jam.demo.controller;

import com.jam.demo.client.NettyClient;
import io.swagger.v3.oas.annotations.Operation;
import io.swagger.v3.oas.annotations.tags.Tag;
import lombok.RequiredArgsConstructor;
import lombok.extern.slf4j.Slf4j;
import org.springframework.web.bind.annotation.PostMapping;
import org.springframework.web.bind.annotation.RequestBody;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RestController;

import java.util.Map;

/**
 * Netty测试接口
 * @author ken
 */
@Slf4j
@RestController
@RequestMapping("/netty")
@RequiredArgsConstructor
@Tag(name = "Netty测试接口", description = "Netty客户端数据发送测试接口")
publicclass NettyTestController {
    privatefinal NettyClient nettyClient;

    /**
     * 发送数据到Netty服务端
     */
    @PostMapping("/send")
    @Operation(summary = "发送数据", description = "通过Netty客户端发送数据到服务端")
    public Map<String, Object> sendData(@RequestBody Map<String, Object> data) {
        nettyClient.sendData(data);
        return Map.of("code", 200, "msg", "数据发送成功");
    }

    /**
     * 初始化并连接Netty客户端
     */
    @PostMapping("/connect")
    @Operation(summary = "连接服务端", description = "初始化Netty客户端并连接服务端")
    public Map<String, Object> connect() {
        nettyClient.init();
        new Thread(nettyClient::connect, "netty-client-thread").start();
        return Map.of("code", 200, "msg", "客户端连接请求已发起");
    }

    /**
     * 关闭Netty客户端
     */
    @PostMapping("/shutdown")
    @Operation(summary = "关闭客户端", description = "关闭Netty客户端并释放资源")
    public Map<String, Object> shutdown() {
        nettyClient.shutdown();
        return Map.of("code", 200, "msg", "客户端已关闭，资源释放完成");
    }
}

CREATE TABLE`netty_heartbeat_log` (
`id`bigintNOTNULL AUTO_INCREMENT COMMENT'主键ID',
`client_address`varchar(128) NOTNULLCOMMENT'客户端地址',
`heartbeat_type`tinyintNOTNULLCOMMENT'心跳类型：1-请求，2-响应',
`create_time` datetime NOTNULLDEFAULTCURRENT_TIMESTAMPCOMMENT'创建时间',
  PRIMARY KEY (`id`),
KEY`idx_client_address` (`client_address`),
KEY`idx_create_time` (`create_time`)
) ENGINE=InnoDBDEFAULTCHARSET=utf8mb4 COLLATE=utf8mb4_0900_ai_ci COMMENT='Netty心跳日志表';

package com.jam.demo.entity;

import com.baomidou.mybatisplus.annotation.IdType;
import com.baomidou.mybatisplus.annotation.TableId;
import com.baomidou.mybatisplus.annotation.TableName;
import lombok.Data;

import java.time.LocalDateTime;

/**
 * Netty心跳日志实体
 * @author ken
 */
@Data
@TableName("netty_heartbeat_log")
publicclass HeartbeatLog {
    @TableId(type = IdType.AUTO)
    private Long id;
    private String clientAddress;
    private Integer heartbeatType;
    private LocalDateTime createTime;
}
